IOWA-LX-600 Half-size CPU Card
Page 100
N/A (Default)
C800
CC00
D000
D400
D800
DC00PC
5.8 Health Status
The PC Health Status menu (6BIOS Menu 12) has no user configurable options, but
shows system operating parameters that are essential to the stable operation of the
system.
Phoenix - AwardBIOS CMOS Setup Utility
PC Health Status
Current CPU Temperature 19ºC/ 66ºF
Current CPU Fan Speed 0 RPM
Vcore 1.20V
Vmem 2.51V
Vcc3 3.39V
Vcc5 5.02V
Vcc12 12.03V
AVCC 3.34V
VBAT (V) 3.31V
Vcc3SB 3.34V
Item Help
___________________
Menu Level >
↑ ↓:Move Enter:Select +/-/PU/PD:Value F10:Save Esc:Exit F1:General Help
F5=Previous Values F6:Fail-Safe Defaults F7 Optimized Defaults
BIOS Menu 12: PC Health Status
The following system parameters are monitored by the PC Health Status menu.
System Temperature
The following temperature is monito red:
