IOWA-LX-600 Half-size CPU Card
Page 7
1.8 Technical Specifications
IOWA-LX-600 technical specifications are listed in table below.
Specification IOWA-LX-600
Form Factor
Half-size
CPU Supported
AMD Geode LX 600 with a 366 MHz FSB and 128KB L2
cache
Express Chipset
AMD Geode CS5536
Memory
On-board 128 MB 200/266 MHz DDR SDRAM
One 200-pin SO-DIMM so ckets support 200/266 MHz DDR
SDRAM SO-DIMMs (system max. 512 MB)
Graphics
VGA integrated in AMD Geode™ LX 600
AMD Geode™ LX 600 24-bit TTL
Display Output
Single HD VOP 2.0 outpu t
1920x1440 CRT output
1600x1200 TFT output
Audio
Realtek ALC203 AC’97 audio codec
LAN
10/100 Mbps Realtek RTL8100C Ethernet Chipset
Super I/O
Winbond W83627EHG
BIOS
Award BIOS
Digital I/O
8-bit digital I/O (4-bit input/4-bit output)
Watchdog Timer
Software programmable supports 1~255 sec. system reset
I/O Interface Connectors
Audio Connector
One internal audio connec tor (10-pin header)
Display Ports
One external VGA port
One internal 24-bit TTL connector (40-pin)
Ethernet
One RJ-45 10/100 Mbps Ethernet port
