IOWA-LX-600 Half-size CPU Card
Page 78
NOTE:
Identical baud rate setting musts be set on the host (a management
computer running a terminal softwa re ) a nd the slave
Agent af ter boot [Disabled]
Use the Agent after boot option to keep agent running after bootup.
Disabled
(Default) Stop agent running af ter bootup
Enabled
Keep agent running after bootup
Full Screen LOGO Show [Enabled]
Use the Full Screen LOGO Show option to specify whether to display the full-screen logo
when the system boots.
Disabled
(Default) Full-screen logo does not appear during boot up.
Enabled
Full-screen logo appears during boot up.
Small Logo (EPA) Show [Disabled]
Use the Small Logo (EPA) Show option to specify if the Environmental Protection
Agency (EPA) logo appears during the system boot-up process. If enabled, the boot up
process may be delayed.
Disabled
(Default) EPA logo does not appear during boot up.
Enabled
EPA logo appears during boot up.
