NANO-LX EPIC SBC
NOTE:
To disable security, select the password setting in the Main Menu. When
asked to enter a password, don’t type anything, press E
NTER and the
security is disabled. Once the security is disabled, the system boots and
Setup can be accessed.
OS Select For DRAM > 64MB [Non-OS2]
Use the OS Select For DRAM > 64MB option to specify the operating system.
Enabled
Specifies the operating system used as OS/2.
Disabled
(Default) Select this option when not using the OS/2 operating
system.
Video BIOS Shadow [Enabled]
Use the Video Bios Shadow option to enable video BIOS to be copied to RAM.
Disabled
Video BIOS is not copied to RAM.
Enabled
(Default) Video BIOS is copied to RAM.
XXXXX-YYYYY Shadow [Disabled]
Use the XXXXX-YYYYY Shadow option to write the contents of the ROM area
XXXXX-YYYYY to the same address in the system RAM.
Disabled
(Default) Contents from ROM area XXXXX-YYYYY are not written
to the RAM.
Enabled
Contents from ROM area XXXXX-YYYYY are written to
the RAM.
Page 131
