NANO-LX EPIC SBC
7.1 Available Software Drivers
NOTE:
The content of the CD may vary throughout the life cycle of the product and
is subject to change without prior notice. You may visit the IEI website or
contact technical support for the latest updates.
The NANO-LX SBC has five software drivers:
VGA Driver
Audio Driver
LAN Driver
SATA/RAID Driver
ISA Driver
All five drivers can be found on the CD that came with the SBC. To install the drivers
please follow the instructions in the sections below.
Insert the CD into the system that contains the NANO-LX SBC.
NOTE:
If your system does not run the "autorun" program when the CD is inserted, click
the Start button, select Run, then type X:\autorun.exe (replace X with the actual
drive letter for your CD-ROM) to access the IEI Driver CD main menu.
Step 1: From the AMD® LX/GX Driver CD main menu (Figure 7-1), click NANO-LX.
Page 156
