 Microphone Effect
 General
NOTE:
Not all RealTek Sound Effect Managers have all the above listed options.
The Sound Effect Manager loaded onto the system may only have some of
the options listed above.
Below is a brief description of the available configuration options in the Sound Effects
Manager.
 Sound Effect:- Select a sound effect from the 23 listed options in the drop
down menu. Selected sound effect properties can be edited. To edit the sound
effect click E
DIT.
 Karaoke Mode:- The Karaoke Mode is accessed in the Sound Effect window.
The Voice Cancellation disables the vocal part of the music being played.
The Key adjustment up or down arrow icons enables users to define a key
that fits a certain vocal range.
 Equalizer Selection:- Preset equalizer settings enable easy audio range
settings. Ten frequency bands can be configured.
 Speaker Configuration:- Multi-channel speaker settings are configured in
this menu. Configurable options include:
o Headphone
o Channel mode for stereo speaker output
o Channel mode for 4 speaker output
o Channel mode for 5.1 speaker output
o Synchronize the phonejack switch with speakers settings
 Speaker Test:- Each speaker connected to the system is tested individually
to see if the 4-channel or 6-channel audio operates properly.
 S/PDIF-In & S/PDIF-Out:- These functions are currently not supported.
 Connector Sensing:- Realtek ALC203 detects if an audio device is plugged
into the wrong connector. If an incorrect device is plugged in, a warning
message appears.
