NANO-LX EPIC SBC
CAUTION!
Do not accidentally disconnect the SATA drive cables. Carefully route the
cables within the chassis to avoid system down time.
E.2 Features and Benefits
Supports RAID levels 0, 1, and JBOD
Supports connectivity to two disk drives
Supported Operating Systems include: Windows 98/Me, Windows 2000, and
Windows XP
Windows-based software for RAID management
E.3 Accessing the ALi RAID Utility
The RAID BIOS version and disk drive information should appear after the system POST
screen.
The BIOS disk drive information should look like the following:
ALi RAID BIOS V1.XX
(c) ALi Corporation 2005, All Rights Reserved.
Identifying IDE drives…
Channel 1 Master: Maxtor xxxxxx
Channel 2 Master: Maxtor xxxxxx
Press Ctrl-A to enter ALi RAID BIOS setup utility
Press C
TRL and A keys simultaneously to enter the RAID configuration utility.
Page 215
