NANO-LX EPIC SBC
E.4 RAID BIOS Setup Utility
The Serial ATA RAID volume can be configured using the RAID Configuration utility
stored within the ALi RAID controller ROM. The BIOS configuration screen is divided into
three major areas: Main Menu, Drive Menu, and a list for the configured RAID arrays.
E.5 RAID Options:
E.5.1 Create RAID0 Striping for Performance
WARNING!
All data previously stored on the member drives of a RAID configuration will
be destroyed during the RAID initialization process. If “used” drives are used
to create a RAID array, make sure the data has been moved or backed up
before creating a RAID array out of the disk drives.
Page 216
