NANO-LX EPIC SBC
1.2.2 Technical Specifications:
NANO-LX SBC technical specifications are listed in Table 1-1. Detailed descriptions of
each specification can be found in Chapter
2.
SPECIFICATION
CPUs Supported
AMD® Geode LX800
Cache Memory
64K I/ 64k D L1 cache, 128K L2 cache
System Chipset
AMD® CS5536
I/O Controller
AMD® CS5536
Memory
One 200-pin DDR 333/400MHz SO-DIMM SDRAM with a
maximum size of 1GB.
PCI Bus Interface
Revision 2.2
Super IO
W83627EHG
Display
CRT integrated in AMD® Geode™ LX800
TTL/ LVDS
24 bit TTL integrated in AMD® LX 800 18 bit LVDS
HDD Interface
One IDE channel supports two Ultra ATA 100/66/33
devices
Power Support
AT/ATX power support
Power Consumption
+12V @ 0.92A (DDR400 256MB)
Power Management
Supports Advanced Configuration and Power Interface
(ACPI) Specifications Revision 2.0
Watchdog Timer
Software programmable supports 1~255 sec. system
reset
I/O Interfaces
1 x FDD
1 x LPT
1 x CFII
