NANO-LX EPIC SBC
Page 24
SPECIFICATION
1 x IDE
6 x RS-232
1 x RS-422/485
2 x SATA channels
PC/104-Plus Interface
Direct ISA DMA mode operation.
Infrared Support
One Infrared Data Association (IrDA) interface
Real Time Clock
256-byte battery backed CMOS RAM
Hardware Monitoring
CPU temperature and system voltages
Ethernet
10/100BASE-T RTL8100C
BIOS
AWARD
Physical Dimensions
115mm x 165mm
Operating Temperature
Minimum: 0ºC (32°F)
Maximum: 60°C (140°F)
Audio Interfaces
AC’97 Codec Realtek ALC203
Table 1-1: Technical Specifications
1.3 Compatible Operating Systems and Memory Modules
The following sections lists the operating systems (OS) and memory modules that have
passed the test held by IEI. Please consider using these compatible OS and memory
modules with the NANO-LX for the best performance.
1.3.1 Operating System
The compatible operating systems include:
DOS 6.22
Windows XP
