NANO-LX EPIC SBC
Variable Destination Stride Yes
Destination Write Bursting Yes
Selectable BLT Direction Vertical and Horizontal
Alpha BLT
Yes (constant α, α/pix, or sep. α channel)
VGA Support Decodes VGA Register
Pipeline Depth Unlimited
Accelerated Rotation BLT 8, 16, 32 bpp
Color Depth Conversion 5:6:5, 1:5:5:5, 4:4:4:4, 8:8:8:8
Table 2-1: Geode LX Graphics Features
2.4.5 AMD
®
Geode™ LX800 500MHz Power Management
The power management for the 500MHz AMD® Geode™ LX800 is listed below:
1.8W Typical (3.9W TDP) @ 500MHz
GeodeLink active hardware power management
Hardware support for standard ACPI software power management
I/O companion SUSP#/SUSPA# power controls
Lower power I/O
Wakeup on SMI/INTR
2.5 System Chipset
The NANO-LX series motherboards all have a preinstalled AMD® Geode™ CS5536
system chipset. The system chipset features are listed below.
82xx Legacy Devices
System Management Bus (SMB) Controller
8 Multi-Function General Purpose Timers (MFGPTs)
Power Management Controller
ACPI v2.0 compliant
2.5.1 GeodeLink™ Interface Unit
64-bit, 66MHz operation
PCI VSM (Virtual System Module) that makes the interface transparent to
applications software and BIOS
Page 33
