NANO-LX EPIC SBC
3.3 Unpacking Checklist
NOTE:
If some of the components listed in the checklist below are missing,
please do not proceed with the installation. Contact the IEI reseller or
vendor you purchased the NANO-LX from or contact an IEI sales
representative directly. To contact an IEI sales representative, please
send an email to
sales@iei.com.tw.
3.3.1 Package Contents
The NANO-LX is shipped with the following components:
Quantity Item and Part Number Image
1 NANO-LX SBC
1 IDE flat cable 44p/44p
(P/N: 32200-000009-RS)
2 RS-232 cables
(P/N: 32200-000049-RS)
1 Audio cable
(P/N: 32000-072100-RS)
1 Power cable
(P/N: 32100-087100-RS)
1 Keyboard/Mouse Y cable
(P/N: 32000-000138-RS)
Page 43
