PM-945GSE-N270 User Manual
Page 103
this field and enter the password. After the password has been added, Install appears
next to Change Supervisor Password.
Change User Password
Use the Change User Password to set or change a user password. The default for this
option is Not Installed. If a user password must be installed, select this field and enter the
password. After the password has been added, Install appears next to Change User
Password.
Clear User Password
Use the Clear User Password to clear a user’s password. The default for this option is
Not Installed. If a user password must be cleared, use this option.
Boot Sector Virus Protection [Disabled]
Use the Boot Sector Virus Protection to enable or disable boot sector protection.
Disabled DEFAULT
Disables the boot sector virus protection
Enabled
Enables the boot sector virus protection
5.7 Chipset
Use the Chipset menu (BIOS Menu 19) to access the Video configuration menu.
WARNING!
Setting the wrong values for the Chipset BIOS selections in the Chipset
BIOS menu may cause the system to malfunction.
