PM-945GSE-N270 User Manual
Page 104
BIOS SETUP UTILITY
Main Advanced PCIPNP Boot Security Chipset Exit
Advanced Chipset Settings
WARNING: Setting wrong values in below section
may cause system to malfunction.
> Northbridge Configuration
> Southbridge Configuration
Select Screen
Select Item
Enter Go to SubScreen
F1 General Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 19: Chipset
5.7.1 Northbridge Chipset Configuration
Use the Northbridge Chipset Configuration menu (BIOS Menu 20) to set the
configuration settings for the flat panel screen connected to the system.
BIOS SETUP UTILITY
Main Advanced PCIPNP Boot Security Chipset Exit
Northbridge Chipset Configuration
Memory Hole [Disabled]
Internal Graphics Mode Select [Enabled, 8 MB]
Boots Graphic Adapter Priority [PCI/IGD]
DVMT Mode Select [DVMT Mode]
DVMT/Fixed Memory [128 MB]
Boot Display Device [Auto]
LVDS Panel Type [1024x768 18b]
Select Screen
Select Item
Enter Go to SubScreen
F1 General Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 20: Video Configuration
