Instruction Manual
Table Of Contents
- 1 Introduction
- 2 Unpacking
- 3 Connectors
- 3.1 Peripheral Interface Connectors
- 3.2 Internal Peripheral Connectors
- 3.2.1 12V / 5V Power Connector
- 3.2.2 ATX Power Supply Enable Connector
- 3.2.3 Audio Kit Connector
- 3.2.4 Battery Connector
- 3.2.5 CompactFlash® Connector
- 3.2.6 Fan Connector
- 3.2.7 Digital I/O Connector
- 3.2.8 Keyboard/Mouse Connector
- 3.2.9 LAN Connector
- 3.2.10 LCD Inverter Connector
- 3.2.11 LED and +5V Output Connector
- 3.2.12 PCI-104 Connector
- 3.2.13 Power Button Connector
- 3.2.14 Reset Button Connector
- 3.2.15 RS-232 Serial Port Connectors
- 3.2.16 RS-422/485 Serial Port Connector
- 3.2.17 LVDS LCD Connector
- 3.2.18 SATA Drive Connector
- 3.2.19 SPI Flash Connector
- 3.2.20 USB Connector
- 3.2.21 VGA Connector
- 4 Installation
- 5 BIOS
- A BIOS Options
- B Terminology
- C Watchdog Timer
- D Hazardous Materials Disclosure
PM-945GSE-N270 User Manual
Page 21
Specification/Model PM-945GSE-N270
Form Factor
PCI-104 Module
CPU
Intel® Atom™ N270 1.6 GHz with 533 MHz FSB
Integrated Graphics
Intel® 945GSE
Memory
1 GB DDR2 SDRAM on-board (8 x 64 MB x16)
System Controller Hub Chipset
Intel® ICH7M
BIOS
AMI BIOS
Compatible OS
Microsoft Windows XP SP2
Microsoft Windows Vista Business (32bit)
Linux Ubuntu 8.10
Linux Fedora Core 6
Digital I/O
8-bit digital I/O, 4-bit input/ 4-bit output
Ethernet Controller
Realtek RTL8102E
Super I/O Controller
Fintek F81865
Real Time Clock
256 bytes of battery-backed RAM, 32.768 KHz crystal, 3 V
battery
Watchdog Timer
Software programmable supports 1~255 sec. system reset
Expansion
PCI
One PCI-104
I/O Interface Connectors
Audio
One audio connector supported via optional 5.1 channel
audio kit with Realtek ALC655 AC'97 codec or 7.1 channel
HD audio kit with Realtek ALC883 codec (supports dual
audio streams)
Display
18-bit dual channel LVDS + VGA, dual independent display
supported
Ethernet
One LAN connector
Keyboard/Mouse
One KB/MS connector
