PM-945GSE-N270 User Manual
Page 53
4.1 Anti-static Precautions
WARNING:
Failure to take ESD precautions during the installation of the
PM-945GSE-N270 may result in permanent damage to the
PM-945GSE-N270 and severe injury to the user.
Electrostatic discharge (ESD) can cause serious damage to electronic components,
including the PM-945GSE-N270. Dry climates are especially susceptible to ESD. It is
therefore critical that whenever the PM-945GSE-N270 or any other electrical component
is handled, the following anti-static precautions are strictly adhered to.
Wear an anti-static wristband: Wearing a simple anti-static wristband can
help to prevent ESD from damaging the board.
Self-grounding: Before handling the board, touch any grounded conducting
material. During the time the board is handled, frequently touch any
conducting materials that are connected to the ground.
Use an anti-static pad: When configuring the PM-945GSE-N270, place it
on an antic-static pad. This reduces the possibility of ESD damaging the
PM-945GSE-N270.
Only handle the edges of the PCB: When handling the PCB, hold the PCB
by the edges.
