PM-945GSE-N270 User Manual
Page 71
NOTE:
If the installation program doesn't start automatically:
Click "Start->My Computer->CD Drive->autorun.exe"
Step 2: The driver main menu appears (Figure 4-15).
Figure 4-15: Introduction Screen
Step 3: Click PM-945GSE-N270.
Step 4: Select OS.
Step 5: A new screen with a list of available drivers appears (Figure 4-16).
