UDMA3
Ultra DMA mode 3 selected with a maximum data transfer
rate of 44 MB/s (To use this mode, it is required that an
80-conductor ATA cable is used.)

UDMA4
Ultra DMA mode 4 selected with a maximum data transfer
rate of 66.6 MB/s (To use this mode, it is required that an
80-conductor ATA cable is used.)

UDMA5
Ultra DMA mode 5 selected with a maximum data transfer
rate of 99.9 MB/s (To use this mode, it is required that an
80-conductor ATA cable is used.)
 S.M.A.R.T [Auto]
Use the S.M.A.R.T option to auto-detect, disable or enable Self-Monitoring Analysis and
Reporting Technology (SMART) on the drive on the specified channel. S.M.A.R.T predicts
impending drive failures. The S.M.A.R.T BIOS option enables or disables this function.

Auto DEFAULT
BIOS auto detects HDD SMART support.

Disabled
Prevents BIOS from using the HDD SMART feature.

Enabled
Allows BIOS to use the HDD SMART feature
 32Bit Data Transfer [Enabled]
Use the 32Bit Data Transfer BIOS option to enables or disable 32-bit data transfers.

Disabled
Prevents the BIOS from using 32-bit data transfers.

Enabled DEFAULT
Allows BIOS to use 32-bit data transfers on supported
hard disk drives.
5.3.3 Super I/O Configuration
Use the Super I/O Configuration menu (BIOS Menu 6) to set or change the
configurations for the FDD controllers, parallel ports and serial ports.
