5.3.5 Power Configuration
The Power Configuration menu (BIOS Menu 8) allows the advanced power
management options to be configured.
BIOS SETUP UTILITY
Main Advanced PCIPNP Boot Security Chipset Exit
Current Jumper Setting [AT Power]
Go into On/Off, or
Suspend when Power
button is pressed
Select Screen
Select Item
Enter Go to SubScreen
F1 General Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 8: APM Configuration
Current Jumper Setting [AT Power]
The Current Jumper Setting BIOS displays the current setting of the AT/ATX power
jumper.
AT Power DEFAULT
The jumper is set to AT power
ATX Power
The jumper is set to ATX power
5.3.6 Remote Access Configuration
Use the Remote Access Configuration menu (BIOS Menu 9) to configure remote
access parameters. The Remote Access Configuration is an AMIBIOS feature and
allows a remote host running a terminal program to display and configure the BIOS
settings.
