PM-P006UPS DC/DC Converter Module
Page 35
5.4 Exit
To close the IDDUPS application, right click t
he icon in the quick laun
ch toolbar on the
desktop as shown in and select
Exit
(
186H186H198H
Figure 5-15
).
Figure 5-15: Exit IDDUPS Application
