WAFER-945GSE 3.5” Motherboard
Page 37
Connector Type Label
Audio connector
10-pin header AUDIO1
ATX enable connector 3-pin wafer ATXCTL1
ATX power connector
4-pin ATX ATXPWR1
Backlight inverter connectors 5-pin wafer INVERTER1
CompactFlash® socket 50-pin CF socket CF1
Digital input/output (DIO) connector
10-pin header DIO1
Fan connector
3-pin wafer CPU_FAN1
Keyboard and mouse connector
6-pin wafer KB_MS1
LED connector 6-pin header LED_C1
LVDS connector
30-pin crimp LVDS1
PCIe Mini Card slot
PCIe Mini Slot CN4
Power Button
2-pin wafer PWRBTN1
Reset button connector 2-pin header RESET1
Serial ATA (SATA) drive connectors
7-pin SATA SATA1
Serial ATA (SATA) drive connectors
7-pin SATA SATA2
RS-232 serial port connector (COM3 – COM6)
40-pin header COM
RS-232/422/485 serial port connector
14-pin header COM2
USB 2.0 connector
8-pin header USB01
USB 2.0 connector
8-pin header USB23
Table 4-1: Peripheral Interface Connectors
4.2.1 External Interface Panel Connectors
770H728HTable 4-2 lists the rear panel connectors on the WAFER-945GSE. Detailed descriptions of
these connectors can be found in Section
771H729H4.4 on page 772H730H57.
