WAFER-945GSE 3.5” Motherboard
Page 76
5.5.6 LVDS Voltage Selection
WARNING:
Permanent damage to the screen and WAFER-945GSE may occur if
the wrong voltage is selected with this jumper. Please refer to the user
guide that cam with the monitor to select the correct voltage.
Jumper Label: J_VLVDS1
Jumper Type:
3-pin header
Jumper Settings: See
802HTable 5-7
Jumper Location: See
803HFigure 5-9
The LVDS Voltage Selection jumpers allow the LVDS screen voltages to be set.
J_VLVDS1 sets the voltage connected to LVDS1 and J_VLVDS2 sets the voltage for the
screen connected to LVDS2. The LVDS Voltage Selection jumper settings are shown in
804HTable 5-7.
LCD Voltage Select Description
Short 1-2 +3.3V LVDS Default
Short 2-3 +5V LVDS
Table 5-7: LVDS Voltage Selection Jumper Settings
The LVDS Voltage Selection jumper location. is shown in 805HFigure 5-9.
