BIOS SETUP UTILITY
Chipset
North Bridge Chipset Configuration
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
Memory Hole [Disabled]
Internal Graphics Mode Select [Enabled, 8MB]
Video Function Configuration
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
DVMT Mode Select [DVMT Mode]
DVMT/FIXED Memory [Maximum DVMT]
Boot Display Device [Auto]
LVDS1 Panel Type [800x600 18b]
LVDS1 Backlight Control [Inverted]
Options
Disabled
15MB-16MB
 Select Screen
↑ ↓ Select Item
+ - Change Option
F1 General Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 20: North Bridge Chipset Configuration
 Memory Hole [Disabled]
The Memory Hole reserves the memory space between 15MB and 16MB for ISA
expansion cards that require a specified area of memory to work properly. If an older ISA
expansion card is used, please refer to the documentation that came with the card to see if
it is necessary to reserve the space.

Disabled DEFAULT
Memory is not reserved for ISA expansion cards

15MB-16MB
Memory is reserved for ISA expansion cards
 Internal Graphics Mode Select [Enabled, 8MB]
The Internal Graphic Mode Select option determines the amount of system memory that
can be used by the internal graphics device.

Disabled

Enabled, 1MB
1MB of memory used by internal graphics device

Enabled, 8MB DEFAULT
8MB of memory used by internal graphics device
