WAFER-945GSE2 3.5" Motherboard
Page 8
1.6 Technical Specifications
The WAFER-945GSE2 technical specifications are listed below.
Specification/Model WAFER-945GSE2
Form Factor
3.5”
System CPU
45 nm 1.6 GHz Intel® Atom™ N270
Front Side Bus
(FSB)
533 MHz
System Chipset
Northbridge: Intel® 945GSE
Southbridge: Intel® ICH7-M
Memory
On-board 533 MHz 1.0 GB DDR2 SDRAM
CompactFlash®
One CompactFlash® Type II socket
Super I/O
ITE IT8718
Display
Intel® Generation 3.5 integrated GFX core (133 MHz)
18-bit dual channel LVDS integrated in Intel® 945GSE
Dual-display supported (VGA and LVDS)
BIOS
AMI BIOS label
Audio
Realtek ALC662 HD Audio codec
LAN
Two Realtek RTL8111E GbE controllers with ASF2.0 support
COM
One RS-232 serial port
One RS-232/422/485 serial port connector
USB 2.0
Six USB 2.0 devices supported:
Four by on-board pin-headers
Two by external connectors
SATA
Two 3.0 Gb/s SATA drives supported
Keyboard/mouse
One internal pin-header connector
Expansion
One PC/104 ISA slot (ISA DMA Mode not supported)
Digital I/O
One 8-bit digital input/output connector; 4-bit input/4-bit output through
the ITE IT8718 super I/O
