WAFER-945GSE2 3.5" Motherboard
Page 12
2.3 Packing List
NOTE:
If any of the components listed in the checklist below are missing, do
not proceed with the installation. Contact the IEI reseller or vendor the
WAFER-945GSE2 was purchased from or contact an IEI sales
representative directly by sending an email to 32sales@iei.com.tw.
The WAFER-945GSE2 is shipped with the following components:
Quantity Item and Part Number Image
1 WAFER-945GSE2 motherboard
2 SATA cable
(P/N: 32000-062800-RS)
1 KB/MS Cable
(P/N: 32000-023800-RS)
1 Audio cable
(P/N: 32000-072100-RS)
1 Mini jumper pack (2.0mm)
(P/N:33100-000033-RS)
2 Plastic intermediate pole for PC/104 (15mm)
