WAFER-945GSE2 3.5" Motherboard
Page 13
Quantity Item and Part Number Image
2 Plastic intermediate pole for PC/104 (20mm)
1 One Key Recovery CD
(P/N: IEI-7B000-000478-RS)
1 Utility CD
1 Quick Installation Guide
Table 2-1: Packing List
2.4 Optional Items
The following are optional components which may be separately purchased:
Item and Part Number Image
Dual USB cable (wo bracket)
(P/N: 32000-070301-RS)
RS-232/422/485 cable
(P/N:32200-026500-RS)
ATX power cable
(P/N: 32100-052100-RS)
SATA power cable
(P/N: 32100-088600-RS)
Table 2-2: Optional Items
