WAFER-945GSE2 3.5" Motherboard
Page 49
NOTE:
IEI has a wide range of backplanes available. Please contact your
WAFER-945GSE2 vendor, reseller or an IEI sales representative at
2sales@iei.com.tw or visit the IEI website (2http://www.ieiworld.com.tw)
to find out more about the available chassis.
4.5.2 Motherboard Installation
To install the WAFER-945GSE2 motherboard into the chassis please refer to the
reference material that came with the chassis.
4.6 Internal Peripheral Device Connections
This section outlines the installation of peripheral devices to the onboard connectors.
4.6.1 SATA Drive Connection
The WAFER-945GSE2 is shipped with two SATA drive cables . To connect the SATA
drives to the connectors, please follow the steps below.
Step 1: Locate the connectors. The locations of the SATA drive connectors are shown
in Chapter 3.
Step 2: Insert the cable connector. Insert the cable connector into the on-board SATA
drive connector until it clips into place. See
Figure 4-7.
