BIOS SETUP UTILITY
Advanced
Hardware Health Configuration
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
CPU FAN Mode Setting [Full On mode]
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
CPU Temperature :43ºC/109ºF
System Temperature :33ºC/91ºF
CPU Fan Speed :N/A
CPU Core :1.136 V
+1.05V :1.040 V
+3.30V :3.296 V
+5.00V :4.972 V
+12.0V :12.288 V
+1.5V :1.477 V
+1.8V :1.792 V
5VSB :5.053 V
VBAT :3.184 V
Fan configuration mode
setting
 Select Screen
↑ ↓ Select Item
+ - Change Option
F1 General Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 7: Hardware Health Configuration
 CPU FAN Mode Setting [Full On mode]
Use the CPU FAN Mode Setting option to configure the second fan.

Full On mode D
EFAULT
Fan is on all the time

Automatic mode
Fan is off when the temperature is low
enough. Parameters must be set by the
user.

PWM Manually mode
Pulse width modulation set manually
When the CPU FAN Mode Setting option is in the Automatic mode, the following
parameters can be set.
 CPU Temperature Limit of Off
 CPU Temperature Limit of On
 CPU Fan Start PWM
 Slope PWM
