WAFER-945GSE2 3.5" Motherboard
Page 79
Select AT/ATX Power [By HARDWARE]
Sets the behavior of the power.
AT Power
ATX Power
BY HARDWARE D
EFAULT
When the Select AT/ATX Power option is set to ATX Power, the following sub-menus
appear.
ACPI Configuration
APM Configuration
5.3.5.1 ACPI configuration
The ACPI Configuration menu (BIOS Menu 9) configures the Advanced Configuration
and Power Interface (ACPI).
BIOS SETUP UTILITY
Advanced
ACPI Settings
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
Suspend mode [S1 (POS)]
Select the ACPI state
used for System Suspend.
Select Screen
↑ ↓ Select Item
+ - Change Option
F1 General Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 9: ACPI Configuration
Suspend mode [S1 (POS)]
Use the Suspend mode BIOS option to specify the sleep state the system enters when it
is not being used.
