Quick Reference Guide

ProLite E2280HS
The ProLite E2280HS is a 22’’ Full HD 1920 x 1080p LED-backlit monitor.
It features 5ms black-to-black response time and >5 000 000 : 1
Advanced Contrast Ratio assuring very good picture quality. Triple Input
support of Analogue, DVI and HDMI ensures compatibility with the latest
installed graphics cards and embedded Notebook outputs. The monitor is
Energy Star Certified. A reliable solution for both home and office use.
DISPLAY CHARACTERISTICS
Diagonal  21.5"
Panel  TN, LED-Backlit
Display area h x w  268.11 x 476.64 mm; 10.6" x 18.8"
Response time  5 ms
Contrast  1000 : 1 typical
Contrast  5 000 000 : 1 ACR
Brightness  250 cd/m² typical
Viewing zone  horizontal/vertical: 160°/ 160°; right/left:
80°/ 80°; up/down: 80°/ 80°
Viewing zone CR>5  horizontal/vertical: 178°/178°; right/left: 89°/
89°; up/down: 89°/ 89°
Display colour  16.7 million
Pixel pitch h x v  0.2482 x 0.2482 mm
Native resolution  Full HD 1080p, 1920 x 1080 ( 2.1 megapixel)
Horizontal sync  24 - 80 KHz
Vertical sync  56 - 75 Hz
Synchronization  Separate sync
Aspect ratio  16 : 9
POWER MANAGEMENT
Power supply  AC100~240V 50/60Hz
Power Supply Unit  internal
Power usage  21 W typical; max. 0.5 W in Power
management mode
Power management  VESA DPMS, ENERGY STAR®
EPEAT SILVER
EPEAT  EPEAT is a comprehensive environmental
rating that helps identify greener computers
and other electronic equipment. The Silver
certification means the monitor meets all
required criteria plus at least 50% of the
optional requirements. EPEAT Silver is valid
in countries where iiyama registers the
product. Please visit www.epeat.net for the
registration status in your country.
DIMENSIONS & WEIGHT 
Dimensions w x h x d  509.5 x 365.5 x 189.5 mm
Weight  3.3 kg
INTERFACES CONNECTORS
Analog input connector  VGA (D-Sub)
Digital input connector  DVI-D, HDMI
HDCP  yes
 D-Sub, DVI-D, HDMI
SPECIAL FEATURES
Apple - Mac  All iiyama monitors are compatible with
Apple-Macintosh computers.
Plug & Play  VESA DDC2B™
Controls  Via OSD in 9 languages (EN, DE, FR, ES,
IT, PT, Chinese, RU, JP) and 5 front controls
(Power, Menu, + /Volume, - /ECO, Auto)
User controls  luminance (contrast, brightness, ECO, i-style
Colour, ACR), image steup (clock, phase, H.
position, V. position, aspect), colour (gamma,
colour temperature, sRGB), OSD setup (H.
position, V. position, OSD time out, language),
others (reset, signal select, HDMI audio,
information), volume, auto adjust
Speakers  2 x 1 W (Stereo)
Anti-theft-device  Kensington-lock™ prepared
Ergonomics  CE, TUV-GS, CU, TCO 6
Tilt angle  21° up; 5° down
VESA mounting  100 x 100 mm
Colour  Black
ACCESSORIES
Driver  Windows 95 / 98 / 2000 / ME / XP / Vista / 7 /
8
Included accessories  power cable, VGA (D-Sub) cable, DVI-D
cable, audio cable, stand, stand-base, cable
holder, quick start guide, safety guide
Powered by TCPDF (www.tcpdf.org)
All trademarks and registered trademarks acknowledged. E & O E. Specification subject to change without notice. All LCD's comply with ISO-9241-307:2008 in connection with pixel defects.
www.iiyama.com 2013-07-06T21:29:10+02:001/1
