GB FROSTKALL
ENGLISH Please refer to the last page of this manual for the full list of IKEA appointed After Sales Service Provider and relative national phone numbers.
ENGLISH 4
ENGLISH Contents Safety information Safety instructions Installation Product description Operation Daily use 4 5 7 9 10 14 Hints and tips Care and cleaning Troubleshooting Technical data ENVIRONMENTAL CONCERNS IKEA GUARANTEE 18 19 21 25 26 26 Subject to change without notice. Safety information Before the installation and use of the appliance, carefully read the supplied instructions.
ENGLISH 5 Farm houses; staff kitchen areas in shops, offices and other working environments – By clients in hotels, motels, bed and breakfast and other residential type environments Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. Do not damage the refrigerant circuit.
ENGLISH • Do not install the appliance close to radiators or cookers, ovens or hobs. • Do not install the appliance where there is direct sunlight. • Do not install this appliance in areas that are too humid or too cold, such as the construction appendices, garages or wine cellars. • When you move the appliance, lift it by the front edge to avoid scratching the floor. Electrical connection Warning! Risk of fire and electrical shock. • The appliance must be earthed.
ENGLISH 7 must do the maintenance and the recharging of the unit. • Regularly examine the drain of the appliance and if necessary, clean it. If the drain is blocked, defrosted water collects in the bottom of the appliance. Disposal Warning! Risk of injury or suffocation. • Disconnect the appliance from the mains supply. • Cut off the mains cable and discard it. • Remove the door to prevent children and pets to be closed inside of the appliance.
ENGLISH 8 • A - green and yellow: Earth • C - brown: Live • D - blue: Neutral As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: Electrical Connection Caution! Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person. Warning! This appliance must be earthed.
ENGLISH 9 Product description Product overview 1 2 3 4 5 12 1 2 3 4 5 6 7 Vegetable drawer Low temperature compartment Glass shelves No-Frost cooling Bottle rack Control panel Dairy compartment with lid 6 7 8 11 10 8 9 10 11 12 Door balconies Bottle balcony Freezer drawer Freezer drawer Freezer drawer 9
ENGLISH 10 Operation Control panel 1 7 6 5 4 1 Display 2 Bottle Chill and Appliance ON/OFF button 3 Temperature colder button 4 Temperature warmer button 5 Fridge compartment button 6 Freezer compartment button 3 2 7 Mode button It is possible to change the predefined sound of buttons to a louder one by pressing together Mode button and Temperature colder button for approximately 5 seconds. Change is reversible. Display A BC D E M A. B. C. D. E. F. G.
ENGLISH After selection of the fridge or freezer compartment the animation starts After selection of the temperature the animation flashes for a few minutes. Bar indicators The bars guide the user when interacting with the unit and indicate at what level the unit is performing.
ENGLISH When the alarm has returned the alarm indicator goes off. Door open alarm An acoustic alarm will sound if the door is left open for approximately 5 minutes. The door open alarm conditions are indicated by: • flashing alarm indicator; • acoustic buzzer. When normal conditions are restored (door closed), the alarm will stop. During the alarm, the buzzer can be switched off by pressing any button.
ENGLISH Extra Humidity function If you notice that the food stored in the fridge compartment is drying out too quickly, you can stop this process by increasing humidity in the cabinet by activating Extra Humidity function. Extra Humidity can function simultaneously with Shopping Function and Eco Mode. 1. To switch on the function press Mode until the corresponding icon appears. The Extra Humidity indicator goes on. 2.
ENGLISH Daily use Freezing Calendar 1-2 3-4 Freezer blocks 3-6 3-6 3-6 x2 Ice-cube production 3-6 10-12 10-12 10-12 10-12 The symbols show different types of frozen goods. The numbers indicate storage times in months for the appropriate types of frozen goods. Whether the upper or lower value of the indicated storage time is valid depends on the quality of the foods and treating before freezing. Accessories Egg tray This appliance is equipped with tray for the production of ice-cubes. 1.
ENGLISH The freezing process lasts 24 hours: during this period do not add other food to be frozen. When the freezing process is completed, return to the required temperature (see "Fast Freezing function"). In this condition, the refrigerator compartment temperature might drop below 0°C. If this occurs reset the temperature regulator to a warmer setting. depending on the time available for this operation.
ENGLISH 16 At the time of putting it back, slightly lift the front of the basket to insert it into the freezer. Once you are over the end points, push the baskets back in their position. Movable shelves Vegetable Drawer The walls of the refrigerator are equipped with a series of runners so that the safety glass shelves can be positioned as desired. Caution! Do not move the glass shelf above the vegetable drawer to ensure correct air circulation.
ENGLISH The Low Temperature Compartment is equipped with runners. To remove it from the fridge compartment, pull the drawer towards yourself and remove the module by tilting its front downwards. This bottle rack can be tilted to store unsealed bottles. To obtain this result, place front hooks of the rack one level higher than the rear hooks. No-Frost Cooling Bottle rack Place the bottles (with the opening facing front) in the pre-positioned rack.
ENGLISH 18 appliance is turned on. To get the best performance the filter should be replaced once every year. In order to obtain information on the new filter purchase, contact the Authorised Service Centre. The fan stops when you open the door and restarts immediately when you close it. Carbon Air Filter The appliance is equipped with a Carbon Air Filter situated in an air lever drawer of a fan-cooling device.
ENGLISH 19 • Meat (all types): wrap in a suitable packaging and place it on the glass shelf above the vegetable drawer. Store meat for at most 1-2 days. • Cooked foods, cold dishes: cover and place on any shelf. • Fruit and vegetables: clean thoroughly and place in a special drawer. Bananas, potatoes, onions and garlic must not be kept in the refrigerator if not packed.
ENGLISH Cleaning the interior Before using the appliance for the first time, the interior and all internal accessories should be washed with lukewarm water and some neutral soap to remove the typical smell of a brand-new product, then dried thoroughly. Caution! Do not use detergents or abrasive powders, as these will damage the finish.
ENGLISH 21 container at the back of the appliance, over the motor compressor, where it evaporates. when it is in operation, neither on the internal walls nor on the foods. Defrosting the freezer The freezer compartment is frost free. This means that there is no build up of frost Troubleshooting Warning! Refer to Safety chapters. What to do if... Problem Possible cause Solution The appliance does not operate. The appliance is switched off. Switch on the appliance. The appliance does not operate.
ENGLISH Problem 22 Possible cause Solution A square symbol is shown instead of numbers on the temperature display. Temperature sensor problem. Contact the nearest Authorised Service Centre (the cooling system will continue to keep food products cold, but temperature adjustment will not be possible). The lamp does not work. The lamp is in stand-by mode. Close and open the door. The lamp does not work. The lamp is defective. Contact the nearest Authorised Service Centre.
ENGLISH Problem 23 Possible cause Solution Water flows inside the refrigerator. Food products prevent Make sure that food products water from flowing into the do not touch the rear plate. water collector. Water flows on the floor. The melting water outlet is Attach the melting water outlet not connected to the evap- to the evaporative tray. orative tray above the compressor. Temperature cannot be set. The Shopping Function is switched on.
ENGLISH Problem 24 Possible cause Solution The temperature in the appliance is too low/too high. The Shopping Function is switched on. Refer to "Shopping Function". The temperature in the appliance is too low/too high. There is no cold air circula- Make sure that there is cold tion in the appliance. air circulation in the appliance. Side panels of the appliance This is a normal state Make sure that there is at least are warm. caused by operation of the 30 mm of space between each heat exchanger.
ENGLISH 25 Technical data Product category Appliance Type Refrigerator - Freezer Installation Type Freestanding Product dimensions Height 2000 mm Width 595 mm Depth 677 mm Net volume Fridge 250 Litre Freezer 91 Litre Defrost system Fridge auto Freezer auto Star rating Rising time 20 hours Freezing capacity 13 kg/24h Energy consumption 0,452 kWh/24h Noise level 41 dB (A) Energy class A+++ Voltage 230 - 240 V Frequency 50 Hz The technical information is situated in the rating
ENGLISH 26 ENVIRONMENTAL CONCERNS Recycle the materials with the symbol . Put the packaging in applicable containers to recycle it. Help protect the environment and human health and to recycle waste of electrical and electronic appliances. Do not dispose appliances marked with the symbol with the household waste. Return the product to your local recycling facility or contact your municipal office.
ENGLISH discretion, if it is covered under this guarantee. If considered covered, IKEA service provider or its authorized service partner through its own service operations, will then, at its sole discretion, either repair the defective product or replace it with the same or a comparable product. What is not covered under this guarantee? • Normal wear and tear.
ENGLISH • the Assembly Instructions and User Manual Safety Information; The dedicated After Sales Service for IKEA appliances: Please do not hesitate to contact IKEA After Sales Service to: 1. make a service request under this guarantee; 2. ask for clarification on installation of the IKEA appliance in the dedicated IKEA kitchen furniture.
Country Phone number België Belgique 070 246016 Call Fee Opening time Binnenlandse gesprekskosten 8 tot 20 Weekdagen Tarif des appels nationaux 8 à 20. En semaine България 00359888164080 0035924274080 Такса за повикване от страната От 9 до 18 ч в работни дни Česká republika 246 019721 Cena za místní hovor Danmark 70 15 09 09 Landstakst 8 až 20 v pracovních dnech man. - fre. 09.00 - 20.00 lør. 09.00 - 16.00 1 søndag pr.
