Certification Exhibit FCC ID: X32-NSHKG020 IC: 8797A-NSHKG020 FCC Rule Part: 15.231 ISED Canada Radio Standards Specification: RSS-210 Project Number: 72128703 Manufacturer: iKeyless, LLC Model: NSHKL-G02X Manual 5015 B.U.
User Manual Draft for NSHKL-G02X Doug Robertson 2017/11/14 11/14/2017 iKeyless Confidential 1
11/14/2017 iKeyless P/N NSHKL-G020 NSHKL-G021 Description 3 button Nissan RHK, no 4 button Nissan RHK, no manual or packaging manual or packaging iKeyless Confidential 2
Compatibility List 11/14/2017 Model Model Year Range Nissan Rogue 2008-2015 Nissan Versa 2011-2017 Nissan Sentra 2007-2017 Nissan Juke 2011-2014 Nissan Cube 2009-2014 Nissan Note 2014-2016 Nissan NV 2013-2017 Nissan Frontier 2004-2016 Nissan Titan 2012-2015 Nissan Altima 2005-2006 Nissan Armada 2004-2007 Nissan 350Z 2003-2006 Nissan Maxima 2004-2006 Nissan Pathfinder 2005-2013 Nissan Xterra 2006-2015 Nissan Murano 2006-2008 Nissan Quest 2004-2009 iKeyless Confidential
Button Functions Note: Remotes come in 3 & 4 button versions.
Transponder Pairing Instructions Like an original Nissan RK, this product requires a separate procedure for pairing the transponder and the remote to the vehicle. The transponder will program exactly like an original key. The remote will require on-board programming. For help or assistance please contact technical support at 1-844-KEYS-USA with any questions related to the remote functions of this key.
RKE Programming Instructions PLEASE READ CAREFULLY BEFORE TRYING! IF AT ANY TIME YOU MAKE A MISTAKE, START AND STOP YOUR CAR, EXIT THE VEHICLE AND START OVER. THE REMOTE CAN BE ONLY PROGRAMMED WITH A MASTER KEY 1. SIT IN CAR WITH DOORS AND WINDOWS CLOSED. 2. LOCK DOORS WITH POWER DOOR LOCK SWITCH ON DRIVER'S DOOR. 3. PUT IN AND PULL OUT KEY FROM IGNITION APPROX. 8 TIMES OR UNTIL YOU SEE THE HAZARD/TURN SIGNAL LIGHTS FLASH.
Using the Remote After completing the pairing and programming instructions, make sure you are within range of the vehicle before using remote. • Press Lock to lock all doors • Press Unlock to unlock the driver's door • Press Unlock again within 2 seconds to unlock all doors • Press and hold the Trunk button for longer than 0.
Replacing Battery 11/14/2017 iKeyless Confidential 8
Remove small Phillips Screw 11/14/2017 iKeyless Confidential 9
Pry open at slot on side 11/14/2017 iKeyless Confidential 10
Replace battery, keep same orientation of +/- Negative Side Up, Positive side Down 11/14/2017 iKeyless Confidential 11
Reverse steps to reassemble 11/14/2017 iKeyless Confidential 12
Regulatory Statements Warning: Changes or modifications to this device not expressly approved by iKeyless LLC could void the user’s authority to operate the equipment. FCC Regulatory Statement MODEL: NSHKL-G02X FCCID: X32-NSHKG020 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
