Specification Sheet

ManualsBrandsImperial ManualsDomestic Appliances1930PS-10-8-SS
12
Features
 Lighting: Lighting uses 50 Watt Halogen Spots (PAR20). (Bulbs NOT Included) *Recessed lighting NOT available on 30”
models.
 Heat Sensor: Fire Safety Thermostat with Automatic turn ON when temp. reaches 130 degrees. Not available on T models.
 Filters: Stainless Steel Baffle filters or Aluminum Mesh.
 Custom: Custom sizes available. Call with exact dimensions or pricing and delivery time.
 Optional Duct Cover: Made to your specifications. Provide WIDTH & HEIGHT.
 Rails: Decorative rails available.
 Optional Modified Wiring: Wiring for “remote” switch placement. Includes switches & knobs.
Specifications
 Power: Exclusive Turbo Blower or Flame Retardant Centrifugal Blowers. 395 to 900 CFM.
 Electrical: 115 AC, 60 Hz, 9 Amps. Suggested use with 15 Amp circuit.
 Stainless Steel: Complete Stainless Steel
Construction for Durability and Fire Safety.
 Finishes: Standard: Stainless Steel, White or Black powder coat available. Optional: Over 60 custom color choices available.
 Distance Codes: Check local city, county and cooking appliance specifications. UL tested at 36” above cooking surface.
Optional 30” for T models.
 Installation: Simple, Stress Free installation. Wall Mount application comes with mounting brackets. *Must indicate for wall
application at the time of order.
Warranty
 Warranty: 7 Year, In-Home—Parts & Labor. (Best in the Industry!)
 No “Performance” Warranty when used above BBQ Style Grills/Griddles. Call to discuss.
Select 10
10” High Canopy ~ Wall Mount
MODELS POWER
CFM
MOTOR
TYPE
CONTROLS SONES
LOW - HI
DEPTH LIGHTS DUCT SIZES
1900PSB-10 635 Dual Blowers Variable 1. 5 - 4.6 22-1/8”
Front Panel
Single 7” 30”, 36”, 42” & 48”
1900PSB-10-8 775 Dual Blowers Variable 1. 5 - 4.6 22-1/8”
Front Panel
Single 8” 30”, 36”, 42”, & 48”
1900PS1B-10 540 Single Blower Variable 1. 5 - 4.6 22-1/8”
Front Panel
Single 7” 30”, 36” & 42”
1900TB-10 395 Turbo Blower Variable 1.8 - 4.9 22-1/8”
Front Panel
Single 7” 30”, 36”, & 42”
1900PS-10 750 Dual Blowers Variable 1.5 - 4.6 22-1/8”
Dual
Single 7” 30”, 36”, 42”, & 48”
1900PS-10-8 900 Dual Blowers Variable 1. 5 - 4.6 22-1/8”
Dual
Single 8” 30”, 36”, 42”, & 48”
1900PS1-10 635
Single Blower Variable 1.5 - 4.6 22-1/8”
Dual
Single 7” 30”, 36” & 42”
1900PS1-10-8 775
Single Blower Variable 1.5 - 4.6 22-1/8”
Dual
Single 8” 30”, 36” & 42”
1900T-10 425 Turbo Blower Variable 1.8 - 4.9 22-1/8”
Center Panel
Single 7” 30”, 36”, & 42”
Employee Owned
American Made
Since 1961
