Owner manual

01-8
Dimension
Unit: mm
AHP-1070
Cutout: 190 x 144mm
Units:mm
Ordering Information
Optional Accessories
AHP-1070
ARM-DR075-0•
DIN Rail Kit with VESA 75mm Standards
ARM-WK075-0•
Wallmount Kit for VESA 75/100mm Standard Screw Holes
1757904005•
12V 40W Power Adapter w/ 2-pin Terminal Block
1702031802•
Power Cord (US Type)
1702031803•
Power Cord (European Type)
9761107001•
WiFi Kit, 802.11 b/g
Part Number Display Type
Max
Resolution
Luminance
View
Angle
Backlight
MTBF (Hours)
CPU LAN USB RS-232
RS-
485/422/232
Storage RAM Display Expansion
Mount-
ing
Power Temp. Touch
TF-AHP-
1070 HT T-A1-1011
7" TFT-LCD 800 x 480 300 cd/m
2
140(H),
140V
30,000
TI OMAP
- 600MHz
1 2 1 1
128 MB NAND
Flash on board
SD Card x 1 (WinCE
pre-installed)
128MB
onboard
VGA x 1
Mini Card x 1 (USB
Interface only)
VESA 75
/ Panel
DC12V
0°C~50°C
(w/o air)
5-wire
resistive
TF-AHP-
1070 HT T-A 2-1011
7" TFT-LCD 800 x 480 300 cd/m
2
140(H),
140V
30,000
TI OMAP
- 600MHz
1 2 1 1
256 MB NAND
Flash on board
SD Card x 1 (WinCE
pre-installed)
256MB
onboard
VGA x 1
Mini Card x 1 (USB
Interface only)
VESA 75
/ Panel
DC12V
0°C~50°C
(w/o air)
5-wire
resistive
Packing List
Phoenix Power Connector•
Mounting Brackets and Screws•
CD-ROM for Manual (in PDF Format) and Drivers•
AHP-1070•
