Operators Manual Owner manual
Table Of Contents
- 1 Introduction
- 2 Safety
- 3 General Specifications
- 4 Sensor Specifications
- 5 Instrument Overview
- 6 System Components
- 7 Probe Setup
- 8 Communication Settings and Calibration
- Connect the Instrument to the Computer
- Connect the Instrument to Win-Situ 5 Software
- First Screen (Data Tab)
- Set Communication Outputs
- Modbus Setup
- SDI-12 Setup
- View and Record Data
- Calibrate and Set Up Sensors
- Set Parameter Units and Sentinel Values
- RDO Sensor Calibration
- Conductivity Calibration
- Pressure/Level
- pH/ORP Calibration
- 9 Controller Requirements and Connections
- 10 Care and Maintenance
- 11 Declaration of Conformity
800-446-1500 9 www.in-situ.com
pH Sensor Specifications
Accuracy ±0.1 pH unit from 0 to 12 pH units
Range 0 to 12 pH units
Resolution 0.01 pH unit
Sensor Type Replaceable pH/ORP combo sensor
Response
Time
<15 sec., pH 7 to pH 4
Units of
Measure
pH units
Methodology Std. Methods 4500-H+ EPA 150.2
Sample Temperature Sensor Specifications (Probe)
Accuracy ±0.1° C
Range -5 to 50° C (23 to 122° F)
Resolution 0.01° C or better
Sensor Type Fixed
Response
Time
<30 sec.
Units of
Measure
Celsius, Fahrenheit
Methodology EPA 170.1
