(3,1) Foreword GUID-2F2D27F5-65B6-4D66-A0F7-BF158B86DF44 Your INFINITI represents a new way of thinking about vehicle design. It integrates advanced engineering and superior craftsmanship with a simple, refined aesthetic sensitivity associated with traditional Japanese culture. The result is a different notion of luxury and beauty.
(4,1) . . ALWAYS provide information about the proper use of vehicle safety features to all occupants of the vehicle. ALWAYS review this Owner’s Manual for important safety information. ON-PAVEMENT AND OFF-ROAD DRIVING This vehicle will handle and maneuver differently from an ordinary passenger car because it has a higher center of gravity. As with other vehicles with features of this type, failure to operate this vehicle correctly may result in loss of control or an accident.
(5,1) IMPORTANT INFORMATION ABOUT THIS MANUAL GUID-8220D38F-8405-49D1-B820-2C368588F8D7 those above call attention to an item in the illustration. CALIFORNIA PROPOSITION 65 WARNING GUID-89523C99-0885-48CF-BC51-EEC31866614D You will see various symbols in this manual. They are used in the following ways: WARNING WARNING This is used to indicate the presence of a hazard that could cause death or serious personal injury. To avoid or reduce the risk, the procedures must be followed precisely.
(6,1) Bluetooth® is a trademark owned by Bluetooth SIG, Inc. and licensed to Visteon Corporation and Clarion Co., Ltd. SiriusXM® services require a subscription after trial period and are sold separately or as a package. The satellite service is available only in the 48 contiguous USA and DC. SiriusXM® satellite service is also available in Canada: see www.siriusxm.ca INFINITI-13P © 2015 NISSAN MOTOR CO., LTD. All rights reserved.
(7,1) INFINITI CUSTOMER CARE PROGRAM GUID-4A402CC9-0FAB-48DE-A23E-64DA7062EA77 INFINITI CARES ... Both INFINITI and your INFINITI retailer are dedicated to serving all your automotive needs. Your satisfaction with your vehicle and your INFINITI retailer are our primary concerns. Your INFINITI retailer is always available to assist you with all your automobile sales and service needs.
(8,1) Condition: [ Edit: 2015/ 6/ 12 Model: J50-D ]
(1,1) Table of Contents Illustrated table of contents 0 Safety — Seats, seat belts and supplemental restraint system 1 Instruments and controls 2 Pre-driving checks and adjustments 3 Monitor, climate, audio, phone and voice recognition systems 4 Starting and driving 5 In case of emergency 6 Appearance and care 7 Maintenance and do-it-yourself 8 Technical and consumer information 9 Index Condition: 10 [ Edit: 2015/ 6/ 12 Model: J50-D ]
(2,1)
(9,1) 0 Illustrated table of contents Seats, seat belts and Supplemental Restraint System (SRS) ...................................................... ... Exterior front ....................................................... ... Exterior rear ........................................................ ... Passenger compartment ...................................... ... Cockpit................................................................ ... Condition: 0-2 0-3 0-5 0-6 0-7 Instrument panel ..............
(10,1) SEATS, SEAT BELTS AND SUPPLEMENTAL RESTRAINT SYSTEM (SRS) 8. 9. GUID-F3FFAE0C-D43A-43BA-A95E-BC6C67C179DC 10. 11. 12. 13. Rear armrest (P.1-7) Rear seats (P.1-4) — Child restraints (P.1-21) Front seat-mounted side-impact supplemental air bags (P.1-42) Seat belt pretensioner (P.1-53) Occupant classification sensor (pattern sensor) (P.1-47) Front passenger air bag status light (P.1-49) SSI0417 1. 2. 3. 4.
(11,1) EXTERIOR FRONT 7. 8. GUID-C0DAB6C4-2638-4210-92D1-C51ED7B201A0 9. 10. 11. 12. 13. 14. JVC0844X 1. 2. 3. Front view camera (if so equipped) (P.4-31) Hood (P.3-16) Headlights and turn signal lights (P.2-34) — Bulb replacement (P.8-27) 4. 5. 6. — Adaptive Front lighting System (AFS) (if so equipped) (P.2-37) Windshield wiper and washer (P.2-31) — Maintenance (P.8-19) Moonroof (P.2-54) Roof rack (if so equipped) (P.2-50) 15. Power windows (P.2-51) Outside mirrors (P.
(12,1) 16. Side turn signal lights (P.
(13,1) EXTERIOR REAR — Around View ® Monitor (if so equipped) (P.4-31) — Sonar system (if so equipped) (P.5-94) 8. Center sensors (if so equipped) — Sonar system (if so equipped) (P.5-94) 9. Rear combination lights (bulb replacement) (P.8-25) 10. Fuel-filler door (P.3-18) — Fuel information (P.9-3) 11. Child safety rear door locks (P.3-6) GUID-22C3CD44-5E1E-4FA8-BA99-B089AFCA0ADD JVC0845X 1. 2. 3. Rearview camera (P.4-24, P.4-31) Lift gate (P.3-17) — Intelligent Key system (P.
(14,1) PASSENGER COMPARTMENT 8. Map light (P.2-56) 9. Sunglasses holder (P.2-46) 10. Inside rearview mirror (P.3-22) — HomeLink® (if so equipped) (P.2-59) 11. Cargo cover (if so equipped) (P.2-49) 12. Rear cup holders (P.2-45) 13. Console box — Power outlet (P.2-44) — USB memory operation (P.4-83) — iPod® player operation (P.4-92) 14. Front cup holders (P.2-45) GUID-FE9DADD4-463D-4664-925C-6329D4E54F5A SSI0401 1. 2. 3. 4. 0-6 Coat hooks (P.2-48) Seat-mounted jacket hanger (if so equipped) (P.
(15,1) COCKPIT GUID-A35345A9-ABF1-4847-AB93-479406197157 7. 8. 9. 10. 11. 12. SSI0623 1. 2. 3. TRIP/RESET switch for twin trip odometer (P.2-7) Instrument brightness control switch (P.2-38) Headlight, fog light and turn signal switch (P.2-34) 4. 5. 6. Trip computer switch (P.2-26) Windshield wiper and washer switch (P.2-31) Sonar system OFF switch (if so equipped) (P.5-96) or warning systems switch (if so equipped) 13. — Forward Collision Warning (FCW) (P.5-77) — Lane Departure Warning (LDW) (P.
(16,1) 14. Steering wheel — Horn (P.2-39) — Driver supplemental air bag (P.1-42) 15. Steering-wheel-mounted controls (right side) — Cruise control switches (P.5-39) — Intelligent Cruise Control (ICC) switches (if so equipped) (P.5-41) — Lane Departure Prevention (LDP) switch (if so equipped) (P.5-20) — Distance Control Assist (DCA) switch (if so equipped) (P.5-63) 16. Center-console-mounted controls — Heated seat switches (P.2-40) — Rear seat power return switches (if so equipped) (P.
(17,1) INSTRUMENT PANEL GUID-422CC4D1-5AAE-4B93-824E-764A57BE67BE SSI0624 1. 2. 3. 4. 5. 6. Side ventilator (P.4-53) Meters and gauges (P.2-6) Center ventilator (P.4-53) Center display (P.4-3) Clock (P.2-43) Hazard warning flasher switch (P.6-2) 7. Center multi-function control panel — Navigation system* (if so equipped) — Vehicle information and setting buttons (P.4-9) — Bluetooth® Hands-Free Phone Sys- tem (with navigation system) (P.
(18,1) METERS AND GAUGES GUID-3BE4B18C-D795-4C40-8E5B-093AD417BB16 SIC4694 1. 2. 3. 4. 5. Tachometer (P.2-8) Warning/Indicator lights (P.2-10) Speedometer (P.2-7) Engine coolant temperature gauge (P.2-8) Vehicle information display (P.2-20)/ 6. Odometer/twin trip odometer (P.2-7) Fuel gauge (P.
(19,1) ENGINE COMPARTMENT GUID-EF23FE20-8F03-4ECF-8994-21E622466F96 11. Coolant reservoir (P.8-7) SSI0388 VQ37VHR ENGINE GUID-9FE81907-5330-41E6-B1C6-50A7EB4C237F 1. 2. 3. 4. 5. Fuse/fusible link holder (P.8-22) Battery (P.8-15) Radiator filler cap (P.8-7) Engine oil dipstick (P.8-9) Engine oil filler cap (P.8-9) 6. 7. Brake fluid reservoir (P.8-13) Window washer fluid reservoir (P.8-14) 8. Power steering fluid reservoir (P.8-12) 9. Air cleaner (P.8-18) 10. Drive belts (P.
(20,1) WARNING AND INDICATOR LIGHTS GUID-51FCA61D-4AC4-45D9-AAF2-51D6E1DAD39F Warning light Name All-Wheel Drive (AWD) warning light (AWD models) Page 2-11 Warning light Name Page Low washer fluid warning light 2-15 Master warning light 2-15 Anti-lock Braking System (ABS) warning light 2-11 Preview Function warning light (orange) (if so equipped) 2-15 Automatic Transmission check warning light 2-11 Seat belt warning light 2-15 Blind Spot Warning (BSW) system warning light (if so equipped
(21,1) 1 Safety — Seats, seat belts and supplemental restraint system Seats .................................................................. ... 1-2 Front seats ...................................................... ... 1-3 Rear seats....................................................... ... 1-4 Armrest ........................................................... ... 1-7 Head restraints/headrests ................................... ... 1-7 Adjustable head restraint/headrest components ...................
(22,1) SEATS GUID-9A857634-92CF-4F7D-BCEB-B42451D73ADA vehicle and/or its systems, do not leave children, people who require the assistance of others or pets unattended in your vehicle. Additionally, the temperature inside a closed vehicle on a warm day can quickly become high enough to cause a significant risk of injury or death to people and pets. . SSS0133 upright in the seat with both feet on the floor and adjust the seat properly. See “Precautions on seat belt usage” (P.112). WARNING . .
(23,1) FRONT SEATS GUID-A7227AED-0D9E-438D-ADD1-167C5F3D272E Front power seat adjustment GUID-8D8880C3-170A-4BCC-8AA5-9C4A7D6E6645 Operating tips: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 . The power seat motor has an auto-reset overload protection circuit. If the motor stops during operation, wait 30 seconds, then reactivate the switch. . Do not operate the power seat switch for a long period of time when the engine is off. This will discharge the battery. See “Automatic drive positioner” (P.
(24,1) SSS1052 Seat lifter: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 Push the front or rear end of the switch up or down to adjust the angle or height of the seat. SSS0836 SSS1028 Type A (if so equipped) Type A (if so equipped) Type B (if so equipped) Type B (if so equipped) 1 or back * 2 end of the Push the front * switch to adjust the seatback lumbar area. 1 up or down to adjust the Move the lever * seatback lumbar area.
(25,1) . When operating the rear power seatback return, make sure that the vehicle is stopped and the transmission is in the P (Park) position. . Make sure the lid of the rear seat cup holders is closed before folding the rear seatback. position. WARNING . Never allow anyone to ride in the cargo area or on the rear seat when it is in the fold-down position. Use of these areas by passengers without proper restraints could result in serious injury in an accident or sudden stop. .
(26,1) SSS0829 SSS0853 Type B (if so equipped) Luggage room switch (Type B) (if so equipped): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 1 Push the front side of the switch * located on the right side or left side of the luggage room. The corresponding rear seatback will be folded down automatically. 1-6 Center console switch (if so equipped): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 Push and hold the switch located on the center console. The corresponding rear seatback will be returned automatically.
(27,1) HEAD RESTRAINTS/HEADRESTS GUID-B86D195F-8DA5-4362-B2AE-8E6B54D0C827 WARNING SSS0837 ARMREST GUID-C9B51513-CEC7-4852-8B1E-5E0DA04256CF Rear armrest GUID-C0961244-B3C7-45D0-BAD5-2730F0F82436 Pull the tab and draw the armrest forward until it is horizontal. Head restraint/headrest supplement the other vehicle safety systems. They may provide additional protection against injury in certain rear end collisions.
(28,1) . Adjustable head restraints/headrests have multiple notches along the stalk to lock them in a desired adjustment position. . The non-adjustable head restraints/ headrests have a single locking notch to secure them to the seat frame. . Proper Adjustment: — For the adjustable type, align the head restraint/headrest so the center of your ear is approximately level with the center of the head restraint/headrest.
(29,1) SSS1037 REMOVE GUID-C9782491-976A-4F87-BAA1-662E24B1C9CD Use the following procedure to remove the head restraint/headrest. 1. Pull the head restraint/headrest up to the highest position. 2. Push and hold the lock knob. 3. Remove the head restraint/headrest from the seat. 4. Store the head restraint/headrest properly in a secure place so it is not loose in the vehicle. 5. Reinstall and properly adjust the head restraint/headrest before an occupant uses the seating position.
(30,1) SSS1035 JVR0259X For non-adjustable head restraint/headrest Make sure the head restraint/headrest is positioned so the lock knob is engaged in the notch before riding in that designated seating position. Type A (if so equipped) Raise GUID-D8A5A53D-B5B4-47F8-8894-73BB247EAAE5 To raise the head restraint/headrest, pull it up. SSS1037 Type B (if so equipped) To raise the head restraint, push and hold the lock knob. Then pull it up.
(31,1) Active Head Restraints operate only in certain rear-end collisions. After the collision, the head restraints return to their original positions. Adjust the Active Head Restraints properly as described earlier in this section. SSS1036 Lower GUID-2EC86CEC-540F-4B9C-9939-359F5569D155 To lower, push and hold the lock knob and push the head restraint/headrest down.
(32,1) SEAT BELTS GUID-BEB968BC-6620-42F7-8A91-E9D0666C9E43 PRECAUTIONS ON SEAT BELT USAGE GUID-53033382-24C5-452D-A530-C795862757C9 If you are wearing your seat belt properly adjusted, and you are sitting upright and well back in your seat with both feet on the floor, your chances of being injured or killed in an accident and/or the severity of injury may be greatly reduced.
(33,1) WARNING . . Every person who drives or rides in this vehicle should use a seat belt at all times. Children should be properly restrained in the rear seat and, if appropriate, in a child restraint. The seat belt should be properly adjusted to a snug fit. Failure to do so may reduce the effectiveness of the entire restraint system and increase the chance or severity of injury in an accident. Serious injury or death can occur if the seat belt is not worn properly. .
(34,1) PREGNANT GUID-34B1EAA1-81E6-4B34-B00D-1AB9B55FA469 WOMEN INFINITI recommends that pregnant women use seat belts. The seat belt should be worn snug, and always position the lap belt as low as possible around the hips, not the waist, and place the shoulder belt over your shoulder and across your chest. Never run the lap/shoulder belt over your abdominal area. Contact your doctor for specific recommendations.
(35,1) smoothly pull the belt out of the retractor. SSS0292 Fastening the seat belts GUID-EDEF82E3-50C4-46E5-A0B1-4A503AC8324B 1. Adjust the seat. (See “Seats” (P.1-2).) 2. Slowly pull the seat belt out of the retractor and insert the tongue into the buckle until you hear and feel the latch engage. . The retractor is designed to lock during a sudden stop or on impact. A slow pulling motion permits the belt to move, and allows you some freedom of movement in the seat. .
(36,1) some freedom of movement in the seat. The ELR locks the seat belt when the vehicle slows down rapidly or during impacts. . Grasp the shoulder belt and pull forward quickly. The retractor should lock and restrict further belt movement. If the retractor does not lock during this check or if you have any question about seat belt operation, see an INFINITI retailer. The Automatic Locking Retractor (ALR) mode (child restraint mode) locks the seat belt for child restraint installation.
(37,1) WARNING SSS0294A Shoulder belt height adjustment (for front seats) GUID-23A7A0D7-8B4E-44F4-AC03-87AE8E8AAB03 The shoulder belt anchor height should be adjusted to the position best for you. (See “Precautions on seat belt usage” (P.1-12).) A , and then To adjust, push the button * move the shoulder belt anchor to the desired position, so that the belt passes over the center of the shoulder. The belt should be away from your face and neck, but not falling off of your shoulder.
(38,1) CHILD SAFETY GUID-3EBC3DB8-1395-4216-9688-3BD09C97F155 position. See an INFINITI retailer for assistance with purchasing an extender if an extender is required. WARNING . Only INFINITI seat belt extenders, made by the same company which made the original equipment seat belts, should be used with the INFINITI seat belts. . Adults and children who can use the standard seat belt should not use an extender. Such unnecessary use could result in serious personal injury in the event of an accident. .
(39,1) There are three basic types of child restraint systems: . Rear-facing child restraint . Front-facing child restraint . Booster seat The proper restraint depends on the child’s size. Generally, infants up to about 1 year and less than 20 lb (9 kg) should be placed in rear-facing child restraints. Front-facing child restraints are available for children who outgrow rear-facing child restraints and are at least 1 year old.
(40,1) facing child restraint, INFINITI recommends that the child be placed in a commercially available booster seat to obtain proper seat belt fit. For a seat belt to fit properly, the booster seat should raise the child so that the shoulder belt is properly positioned across the chest and the top, middle portion of the shoulder. The shoulder belt should not cross the neck or face and should not fall off the shoulder. The lap belt should lie snugly across the lower hips or upper thighs, not the abdomen.
(41,1) CHILD RESTRAINTS GUID-B60DFF65-A507-4ECD-AFB2-0C7E9D8EA0A3 PRECAUTIONS ON CHILD RESTRAINTS GUID-68368E0F-2E51-4528-A64A-5F7C6BAA3696 WARNING Never let a child stand or kneel on any seat and do not allow a child in the cargo area. The child could be seriously injured or killed in a sudden stop or collision. WARNING .
(42,1) ward-facing child restraint installation using the seat belts” (P.1-34). — Even with the INFINITI Advanced Air Bag System, never install a rearfacing child restraint in the front seat. An inflating air bag could seriously injure or kill a child. A rear-facing child restraint must only be used in the rear seat. . When the child restraint is not in use, keep it secured with the LATCH system or a seat belt. In a sudden stop or collision, loose objects can injure occupants or damage the vehicle.
(43,1) (29.5 kg), use the vehicle’s seat belt (not the lower anchors) to install the child restraint. . Be sure to follow the child restraint manufacturer’s instructions for installation. All U.S. states and Canadian provinces or territories require that infants and small children be restrained in an approved child restraint at all times while the vehicle is being operated.
(44,1) tions over the anchors such as seat belt webbing or seat cushion material. The child restraint will not be secured properly if the lower anchors are obstructed. Child restraint anchorages are designed to withstand only those loads imposed by correctly fitted child restraints. Under no circumstances are they to be used to attach adult seat belts, or other items or equipment to the vehicle. Doing so could damage the child restraint anchorages.
(45,1) SSS0644 LATCH rigid-mounted attachment The child restraint top tether strap must be used when installing the child restraint with the LATCH lower anchor attachments or seat belts. When installing a child restraint, carefully read and follow the instructions in this manual and those supplied with the child restraint. SSS0841 Top tether anchor GUID-885F10F6-0288-4A53-8004-877F6CC82635 WARNING .
(46,1) REAR-FACING CHILD RESTRAINT INSTALLATIONGUID-1088690A-8FC1-46CB-854D-5E32E597080D USING LATCH Refer to all Warnings and Cautions in the “Child safety” (P.1-18) and “Child restraints” (P.1-21) before installing a child restraint. Do not use the lower anchors if the combined weight of the child and the child restraint exceeds 65 lbs (29.5 kg). If the combined weight of the child and the child restraint is greater than 65 lbs (29.
(47,1) all child restraints fit in all types of vehicles. 5. Check to make sure the child restraint is properly secured prior to each use. If the child restraint is loose, repeat steps 1 through 4. SSS0639 Rear-facing — step 3 3. For child restraints that are equipped with webbing-mounted attachments, remove any additional slack from the anchor attachments.
(48,1) air bag and status light” (P.1-49). SSS0100 REAR-FACING CHILD RESTRAINT INSTALLATIONGUID-7659E753-5018-4FA3-A3A6-25C8378555F1 USING THE SEAT BELTS WARNING The three-point seat belt with Automatic Locking Retractor (ALR) must be used when installing a child restraint. Failure to use the ALR mode will result in the child restraint not being properly secured. The restraint could tip over or be loose and cause injury to a child in a sudden stop or collision.
(49,1) Follow these steps to install a rear-facing child restraint using the vehicle seat belts in the rear seats: 1. Child restraints for infants must be used in the rear-facing direction and therefore must not be used in the front seat. Position the child restraint on the seat. Always follow the restraint manufacturer’s instructions. SSS0654 Rear-facing — step 2 2. Route the seat belt tongue through the child restraint and insert it into the buckle until you hear and feel the latch engage.
(50,1) SSS0656 Rear-facing — step 4 4. Allow the seat belt to retract. Pull up on the shoulder belt to remove any slack in the belt. SSS0657 Rear-facing — step 5 5. Remove any additional slack from the seat belt; press downward and rearward firmly in the center of the child restraint to compress the vehicle seat cushion and seatback while pulling up on the seat belt. SSS0658 Rear-facing — step 6 6. After attaching the child restraint, test it before you place the child in it.
(51,1) 7. Check to make sure that the child restraint is properly secured prior to each use. If the seat belt is not locked, repeat steps 1 through 6. After the child restraint is removed and the seat belt fully retracted, the ALR mode (child restraint mode) is canceled. FORWARD-FACING CHILD RESTRAINT INSTALLATION USING LATCH GUID-78711821-34A6-4C85-AE1E-C8314044AFDD Refer to all Warnings and Cautions in the “Child safety” (P.1-18) and “Child restraints” (P.1-21) before installing a child restraint.
(52,1) interfering with the proper child restraint fit, try another seating position or a different child restraint. SSS0646 Forward-facing rigid-mounted — step 2 3. The back of the child restraint should be secured against the vehicle seatback. If necessary, adjust or remove the head restraint to obtain the correct child restraint fit. If the head restraint is removed, store it in a secure place. Be sure to reinstall the head restraint when the child restraint is removed.
(53,1) 7. Check to make sure the child restraint is properly secured prior to each use. If the child restraint is loose, repeat steps 1 through 6. Installing top tether strap GUID-5D245060-3D0D-41FD-9256-6E6B5F89D580 WARNING . Child restraint anchorages are designed to withstand only those loads imposed by correctly fitted child restraints. Under no circumstances are they to be used to attach adult seat belts, or other items or equipment to the vehicle.
(54,1) information. 2. Secure the top tether strap to the tether anchor point on the back of seatback behind the child restraint. 3. Refer to the appropriate child restraint installation procedure steps in this section before tightening the tether strap. If you have any questions when installing a top tether strap, consult your INFINITI retailer for details. JVR0362X The child restraint top tether strap must be used when installing the child restraint with the LATCH lower anchor attachments.
(55,1) Follow these steps to install a forwardfacing child restraint using the vehicle seat belt in the rear seats or in the front passenger seat: interfering with the proper child restraint fit, try another seating position or a different child restraint. 1. If you must install a child restraint in the front seat, it should be placed in a forward-facing direction only. Move the seat to the rearmost position.
(56,1) SSS0651 Forward-facing — step 4 4. Pull the shoulder belt until the belt is fully extended. At this time, the seat belt retractor is in the Automatic Locking Retractor (ALR) mode (child restraint mode). It reverts to Emergency Locking Retractor (ELR) mode when the seat belt is fully retracted. SSS0652 Forward-facing — step 5 5. Allow the seat belt to retract. Pull up on the shoulder belt to remove any slack in the belt. SSS0653 Forward-facing — step 6 6.
(57,1) 9. Check to make sure the child restraint is properly secured prior to each use. If the seat belt is not locked, repeat steps 2 through 8. SSS0676 SSS0641 Forward-facing — step 8 8. After attaching the child restraint, test it before you place the child in it. Push it from side to side while holding the child restraint near the seat belt path. The child restraint should not move more than 1 inch (25 mm), from side to side.
(58,1) Installing top tether strap GUID-20E8C6C6-FE62-4458-873C-E2A95D2FCD20 WARNING . . . Child restraint anchorages are designed to withstand only those loads imposed by correctly fitted child restraints. Under no circumstances are they to be used to attach adult seat belts, or other items or equipment to the vehicle. Doing so could damage the child restraint anchorages.
(59,1) 2. Secure the top tether strap to the tether anchor point on the back of seatback behind the child restraint. a seating position that has a lap/ shoulder belt. 3. Refer to the appropriate child restraint installation procedure steps in this section before tightening the tether strap. If you have any questions when installing a top tether strap, consult your INFINITI retailer for details.
(60,1) Booster seat installation GUID-827C38DF-0EEF-4E3D-9BC3-066A8443028A CAUTION Do not use the lap/shoulder belt Automatic Locking Retractor (ALR) mode when using a booster seat with the seat belts. LRS0453 . Check the booster seat in your vehicle to be sure it is compatible with the vehicle’s seat and seat belt system. . Make sure the child’s head will be properly supported by the booster seat or vehicle seat. The seatback must be at or above the center of the child’s ears.
(61,1) fit, try another seating position or a different booster seat. 4. Position the lap portion of the seat belt low and snug on the child’s hips. Be sure to follow the booster seat manufacturer’s instructions for adjusting the seat belt routing. SSS0640 1. If you must install a booster seat in the front seat, move the seat to the rearmost position. 2. Position the booster seat on the seat. Only place it in a forward-facing direction. Always follow the booster seat manufacturer’s instructions.
(62,1) SUPPLEMENTAL RESTRAINT SYSTEM GUID-0CFB422A-BE20-4892-A60B-B820C66F6C8F PRECAUTIONS ON SUPPLEMENTAL RESTRAINT GUID-2327169E-353B-4122-ABD1-5B7F2479F328 SYSTEM This Supplemental Restraint System (SRS) section contains important information concerning the following systems. SSS0676 7. If the booster seat is installed in the front passenger seat, push the ignition switch to the ON position.
(63,1) WARNING . The front air bags ordinarily will not inflate in the event of a side impact, rear impact, rollover, or lower severity frontal collision. Always wear your seat belts to help reduce the risk or severity of injury in various kinds of accidents. . The front passenger air bag will not inflate if the passenger air bag status light is lit or if the front passenger seat is unoccupied. See “Front passenger air bag and status light” (P.1-49). .
(64,1) . The driver and front passenger seat belt buckles are equipped with sensors that detect if the seat belts are fastened. The Advanced Air Bag System monitors the severity of a collision and seat belt usage then inflates the air bags as needed. Failure to properly wear seat belts can increase the risk or severity of injury in an accident. . The front passenger seat is equipped with an occupant classification sensor (pattern sensor) that turns the front passenger air bag OFF under some conditions.
(65,1) WARNING . Never let children ride unrestrained or extend their hands or face out of the window. Do not attempt to hold them in your lap or arms. Some examples of dangerous riding positions are shown in the illustrations. . Children may be severely injured or killed when the front air bags, side air bags or curtain air bags inflate if they are not properly restrained. Pre-teens and children should be properly restrained in the rear seat, if possible. SSS0099 .
(66,1) SSS0140 curtain air bags are most effective when you are sitting well back and upright in the seat. The side air bags and curtain air bags inflate with great force. Do not allow anyone to place their hand, leg or face near the side air bags on the side of the seatback of the front seat or near the side roof rails. Do not allow anyone sitting in the front seats or rear outboard seats to extend their hand out of the window or lean against the door.
(67,1) 8. 9. 10. 11. Door satellite sensors Air bag Control Unit (ACU) Satellite sensors Seat belt pretensioner INFINITI ADVANCED AIR BAG SYSTEM (front seats) GUID-B58D3611-FF95-4895-8D3A-C3E079E7176F This vehicle is equipped with the INFINITI Advanced Air Bag System for the driver and front passenger seats. This system is designed to meet certification requirements under U.S. regulations. It is also permitted in Canada.
(68,1) dual stage air bag inflators. The system monitors information from the crash zone sensor, the Air bag Control Unit (ACU), the diagnosis sensor unit, seat belt buckle sensors and the occupant classification sensor (pattern sensor). Inflator operation is based on the severity of a collision and seat belt usage for the driver. For the front passenger, the occupant classification sensor is also monitored.
(69,1) of injury in an accident. Status light: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 The front passenger air bag status light is located under the climate controls. After the ignition switch is placed in the ON position, the front passenger air bag status light illuminates for about 7 seconds and then turns off or illuminates depending on the front passenger seat occupied status.
(70,1) as outlined in this manual should not cause the passenger air bag to be automatically turned OFF. For small adults it may be turned OFF, however, if the occupant does not sit in the seat properly (for example, by not sitting upright, by sitting on an edge of the seat, or by otherwise being out of position), this could cause the sensor to turn the air bag OFF. Always be sure to be seated and wearing the seat belt properly for the most effective protection by the seat belt and supplemental air bag.
(71,1) If a malfunction occurs in the front passenger air bag system, the supplemental air bag warning light , located in the meter and gauges area will blink. Have the system checked by an INFINITI retailer. Other supplemental front-impact air bag precautions GUID-F6A2B4A6-0AF4-4627-8243-F5C200B68D33 WARNING . . . Do not place any objects on the steering wheel pad or on the instrument panel. Also, do not place any objects between any occupant and the steering wheel or instrument panel.
(72,1) collision are similar to those of a higher severity side impact. They are designed to inflate on the side where the vehicle is impacted. They may not inflate in certain side collisions on the side where the vehicle is impacted. the air bag system. . * A cracked windshield should be replaced immediately by a qualified repair facility. A cracked windshield could affect the function of the supplemental air bag system.
(73,1) The seat belts should be correctly worn and the driver and passenger seated upright as far as practical away from the side air bags. Rear seat passengers should be seated as far away as practical from the door finishers and side roof rails. The side air bags and curtain air bags inflate quickly in order to help protect the occupants.
(74,1) . If the vehicle becomes involved in a collision but a pretensioner is not activated, be sure to have the pretensioner system checked and, if necessary, replaced by an INFINITI retailer. . No unauthorized changes should be made to any components or wiring of the pretensioner system. This is to prevent damage to or accidental activation of the pretensioners. Tampering with the pretensioner system may result in serious personal injury. . .
(75,1) If any of the following conditions occur, the air bag and/or pretensioner systems need servicing: SSS1016 SUPPLEMENTAL AIR BAG WARNING LABELS GUID-90FD8F2E-5B90-46B9-BF6E-B90D67C31851 Warning labels about the supplemental front-impact air bag systems are placed in the vehicle as shown in the illustration. SRS air bagGUID-D44A9F5A-680D-463F-A825-6C121EE26D8B 1 are located on the The warning labels * surface of the sun visors.
(76,1) REPAIR AND REPLACEMENT PROCEDURE GUID-1C32A04C-3D99-4EFC-A9A7-9CBA15E03C66 The front air bags, side air bags, curtain air bags and pretensioners are designed to activate on a one-time-only basis. As a reminder, unless it is damaged, the supplemental air bag warning light will remain illuminated after inflation has occurred. Repair and replacement of these systems should be done only by an INFINITI retailer.
(77,1) 2 Instruments and controls Cockpit................................................................ ... 2-3 Instrument panel ................................................. ... 2-5 Meters and gauges.............................................. ... 2-6 Speedometer and odometer ............................ ... 2-7 Tachometer ..................................................... ... 2-8 Engine coolant temperature gauge .................. ... 2-8 Fuel gauge ............................................
(78,1) Cargo cover (if so equipped) ......................... ... Roof rack (if so equipped) ............................. ... Windows ........................................................... ... Power windows ............................................. ... Moonroof .......................................................... ... Power moonroof ............................................ ... Welcome light ................................................... ... Battery saver system .....................
(79,1) COCKPIT GUID-D50D6554-A3E9-4B15-AC48-BC6908CCC6C1 7. 8. 9. 10. 11. 12. SSI0623 1. 2. 3. TRIP/RESET switch for twin trip odometer (P.2-7) Instrument brightness control switch (P.2-38) Headlight, fog light and turn signal switch (P.2-34) 4. 5. 6. Trip computer switch (P.2-26) Windshield wiper and washer switch (P.2-31) Sonar system OFF switch (if so equipped) (P.5-96) or warning systems switch (if so equipped) 13. — Forward Collision Warning (FCW) (P.5-77) — Lane Departure Warning (LDW) (P.
(80,1) 14. Steering wheel — Horn (P.2-39) — Driver supplemental air bag (P.1-42) 15. Steering-wheel-mounted controls (right side) — Cruise control switches (P.5-39) — Intelligent Cruise Control (ICC) switches (if so equipped) (P.5-41) — Lane Departure Prevention (LDP) switch (if so equipped) (P.5-20) — Distance Control Assist (DCA) switch (if so equipped) (P.5-63) 16. Center-console-mounted controls — Heated seat switches (P.2-40) — Rear seat power return switches (if so equipped) (P.
(81,1) INSTRUMENT PANEL GUID-0EC59BA9-750D-4844-BDCD-47D6D1842B7F SSI0624 1. 2. 3. 4. 5. 6. Side ventilator (P.4-53) Meters and gauges (P.2-6) Center ventilator (P.4-53) Center display (P.4-3) Clock (P.2-43) Hazard warning flasher switch (P.6-2) 7. Center multi-function control panel — Navigation system* (if so equipped) — Vehicle information and setting buttons (P.4-9) — Bluetooth® Hands-Free Phone Sys- tem (with navigation system) (P.
(82,1) METERS AND GAUGES GUID-C6F284D6-D7CC-4225-A943-62BD4F86D632 to the OFF position. This is not a malfunction. CAUTION . For cleaning, use a soft cloth, dampened with water. Never use a rough cloth, alcohol, benzine, thinner or any kind of solvent or paper towel with a chemical cleaning agent. They will scratch or cause discoloration to the lens. . Do not spray any liquid such as water on the meter lens. Spraying liquid may cause the system to malfunction. SIC4694 1. 2. 3. 4. 5.
(83,1) Changing theGUID-D73A39BF-43C8-459F-9C24-47B7F579C407 display: 3 at Pushing the TRIP A/B RESET switch * the bottom left of the combination meter panel changes the display as follows: TRIP A ? TRIP B ? TRIP A Resetting theGUID-D73A39BF-43C8-459F-9C24-47B7F579C407 trip odometer: 3 for Pushing the TRIP A/B RESET switch * more than 1 second resets the trip odometer to zero.
(84,1) CAUTION JVI0513X TACHOMETER GUID-A297B803-2C3A-462D-9199-AD2D85E7F094 The tachometer indicates engine speed in revolutions per minute (RPM). Do not rev 1 . the engine into the red zone * CAUTION When engine speed approaches the red zone, shift to a higher gear or reduce engine speed. Operating the engine in the red zone may cause serious engine damage.
(85,1) convenient, preferably before the gauge reaches “E”. There will be a small reserve of fuel in the tank when the fuel gauge needle reaches “E”. The indicates that the fuel-filler door is located on the passenger’s side of the vehicle. CAUTION . If the vehicle runs out of fuel, the malfunction indicator light (MIL) may come on. Refuel as soon as possible. After a few driving trips, the light should turn off.
(86,1) WARNING LIGHTS, INDICATOR LIGHTS AND AUDIBLE REMINDERS GUID-6AAEFF3D-0DD3-4C79-B5F3-C17FD9AE3F5E All-Wheel Drive (AWD) warning light (AWD models) Anti-lock Braking System (ABS) warning light Automatic transmission check warning light Exterior light indicator Lane Departure Warning (LDW) indicator light (orange) (if so equipped) Front fog light indicator light Low tire pressure warning light Front passenger air bag status light Low washer fluid warning light High beam indicator light Preview
(87,1) WARNING LIGHTS GUID-6AC34C38-B5BD-4A02-A0CE-95F7C95E6CB0 system from malfunctioning. If the warning light turns off, you can drive again. All-Wheel Drive (AWD) warning light (AWD GUID-020674DF-0D6E-43D6-93CA-BA1DAE13E576 models) — blinks slowly (about once every 2 seconds): The warning light comes on when the ignition switch is pushed to ON. It turns off soon after the engine is started.
(88,1) or Brake warning light GUID-94AD6FCA-DAAE-4E85-8624-D3E39027F22F This light functions for both the parking brake and the foot brake systems. Parking brakeGUID-D73A39BF-43C8-459F-9C24-47B7F579C407 indicator: When the ignition switch is in the ON position, the light comes on when the parking brake is applied. Low brake fluid warning light: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 When the ignition switch is in the ON position, the light warns of a low brake fluid level.
(89,1) If it is not possible to turn on the system or the warning light stays on, it may indicate that the system is malfunctioning. Although the vehicle is still driveable under normal conditions, have the vehicle checked at an INFINITI retailer. See “Distance Control Assist (DCA) system” (P.5-63). light Engine oil pressure warning GUID-F0FEB09B-4AD6-4830-B18D-4CB725F3D547 This light warns of low engine oil pressure.
(90,1) Departure Prevention (LDP) systems” (P.520). light Low tire pressure warning GUID-9C3F8B9E-26C2-4082-BD9B-E29AF583E624 Your vehicle is equipped with a Tire Pressure Monitoring System (TPMS) that monitors the tire pressure of all tires except the spare. The low tire pressure warning light warns of low tire pressure or indicates that the TPMS is not functioning properly. After the ignition switch is pushed ON, this light illuminates for about 1 second and turns off.
(91,1) have the vehicle checked by an INFINITI retailer. . . Since the spare tire is not equipped with the TPMS, when a spare tire is mounted or a wheel is replaced, the TPMS will not function and the low tire pressure warning light will flash for approximately 1 minute. The light will remain on after 1 minute. Contact your INFINITI retailer as soon as possible for tire replacement and/or system resetting.
(92,1) light Supplemental air bag warning GUID-22F43124-6FC8-4834-A28D-0169B9BFB102 After pushing the ignition switch to the ON position, the supplemental air bag warning light will illuminate. The supplemental air bag warning light will turn off after about 7 seconds if the supplemental front air bag and supplemental side air bag, curtain side-impact air bag systems and/or pretensioner seat belt are operational.
(93,1) Automatic transmission position indicator light GUID-4862AE0A-44AC-4FBE-8570-1EFD06235A63 When the ignition switch is pushed to the ON position, the indicator shows the automatic shift position. In the manual shift mode, when the transmission does not shift to the selected gear due to a transmission protection mode, the AT position indicator light will blink and a buzzer will sound. (See “Automatic transmission” (P.5-15).
(94,1) For more details, see “Lane Departure Warning (LDW)/Lane Departure Prevention (LDP) systems” (P.5-20). (MIL) Malfunction Indicator Light GUID-6256237E-853A-4604-8E3D-B884E99E13A6 If the malfunction indicator light comes on steady or blinks while the engine is running, it may indicate a potential emission control malfunction. The malfunction indicator light may also come on steady if the fuel-filler cap is loose or missing, or if the vehicle runs out of fuel.
(95,1) Turn signal/hazard indicator lights GUID-03F65A59-AF9A-4CAE-937B-1BFA717FB4C0 The light flashes when the turn signal switch lever or hazard switch is turned on. Vehicle Dynamic Control (VDC) off indicator light GUID-FD6F2BFB-B634-4CE2-B8F8-10BADA39BBF3 When the ignition switch is in the ON position, the Vehicle Dynamic Control (VDC) off indicator light illuminates and then turns off. The light comes on when the VDC off switch is pushed to OFF.
(96,1) VEHICLE INFORMATION DISPLAY GUID-5A60BB66-370D-4B48-9D29-5C0850D9B3AF — “Driving the vehicle” (P.5-15). . Intelligent Cruise Control (ICC) system — “Intelligent Cruise Control (ICC) system (FULL SPEED RANGE)” (P.5-41). . Distance Control Assist (DCA) system — “Distance Control Assist (DCA) system” (P.5-63). . Intelligent Key system — “Intelligent Key system” (P.3-7). — “Push-button ignition switch” (P.510).
(97,1) JVI0339X Instruments and controls Condition: [ Edit: 2015/ 6/ 12 Model: J50-D ] 2-21
(98,1) INDICATORSGUID-4953EC98-0A90-4524-A10A-4B4DDF3E7778 FOR OPERATION 4. NO KEY warning GUID-C7F01BD8-AF53-49FD-809F-EF981597D56A 1. Engine start operation indicator GUID-2DA2AFA1-C739-4480-951C-105FF0F2842C This warning appears in either of the following conditions. This indicator appears when the shift lever is in the P (Park) position. This indicator means that the engine will start by pushing the ignition switch with the brake pedal depressed. 2.
(99,1) 9. Low fuel GUID-1BA95083-A30B-4841-91E0-F1A2A657F097 warning 13. Loose fuel cap warning GUID-C7375769-D15F-4047-966B-85D2971DD0C7 16. Cruise indicator GUID-FE4B5AB8-091F-4E62-8A47-5836E2777D76 This warning appears when the fuel level in the tank is getting low. Refuel as soon as it is convenient, preferably before the fuel gauge reaches the empty (E) position. This warning appears when the fuel-filler cap is not tightened correctly after the vehicle has been refueled. (See “Fuel-filler cap” (P.
(100,1) INDICATORSGUID-E2331906-D9F2-4D67-8581-079DC98C570F FOR MAINTENANCE The cruise control set indicator (SET) is displayed while the vehicle is controlled by the conventional (fixed speed) cruise control mode of the ICC system. 1. Engine oil replacement indicator GUID-0DA69B6C-E07C-4A8B-AE91-83E6D25ECFCC This indicator appears when the customer set time comes for changing the engine oil. You can set or reset the distance for changing the engine oil. (See “Trip computer” (P.2-26).
(101,1) road conditions affect tire wear and when tires should be replaced. Setting the tire replacement indicator for a certain driving distance does not mean your tires will last that long. Use the tire replacement indicator as a guide only and always perform regular tire checks. Failure to perform regular tire checks, including tire pressure checks could result in tire failure. Serious vehicle damage could occur and may lead to a collision, which could result in serious personal injury or death. 4.
(102,1) A is pushed, the Each time the switch * display will change as follows: Current fuel consumption ? Average fuel consumption and speed ? Elapsed time and trip odometer ? Distance to empty (dte) ? Outside air temperature (ICY) ? Setting ? Warning check 1. Current fuel consumption GUID-0C64924E-9423-4FBE-B06E-3EDAC1782F16 The current fuel consumption mode shows the current fuel consumption.
(103,1) can be driven before refueling. The dte is constantly being calculated, based on the amount of fuel in the fuel tank and the actual fuel consumption. The display is updated every 30 seconds. The dte mode includes a low range warning feature. If the fuel level is low, the warning is displayed on the screen. The outside temperature sensor is located in front of the radiator. The sensor may be affected by road or engine heat, wind directions and other driving conditions.
(104,1) SECURITY SYSTEMS GUID-68FC1081-1656-4C47-8C2B-B8252447F298 than the engine oil, oil filter and tires. The maintenance distance will increase by 250 miles (500 km) up to 18,500 miles (30,000 km). To increase the number by 500 miles (1,000 km), push and hold the switch. DETAIL: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 This item is available only when a warning is displayed. Select this menu to see the details of warnings.
(105,1) VEHICLE SECURITY SYSTEM GUID-87DD9A1C-A96A-4B80-97F8-9699DF2B983A The vehicle security system provides visual and audio alarm signals if someone opens the doors, hood, or lift gate when the system is armed. It is not, however, a motion detection type system that activates when a vehicle is moved or when a vibration occurs. The system helps deter vehicle theft but cannot prevent it, nor can it prevent the theft of interior or exterior vehicle components in all situations.
(106,1) tampered with again. The alarm is activated by: . Unlocking the door or opening the lift gate without using the button on the Intelligent Key, the door handle request switch or the mechanical key. (Even if the door is opened by releasing the door inside lock knob, the alarm will activate.) . Opening the hood.
(107,1) WIPER AND WASHER SWITCH GUID-251E00F1-E71B-4065-BE2B-A19EFFFCA824 If the light still remains on and/or the engine will not start, see an INFINITI retailer for INFINITI Vehicle Immobilizer System service as soon as possible. Please bring all Intelligent Keys that you have when visiting an INFINITI retailer for service. WARNING In freezing temperatures the washer solution may freeze on the window and obscure your vision which may lead to an accident.
(108,1) tank to mix the washer fluid concentrate and water. If the windshield wiper operation is interrupted by snow or ice, the wiper may stop moving to protect its motor. If this occurs, turn the wiper switch to the OFF position and remove the snow or ice that is on and around the wiper arms. In approximately 1 minute, turn the switch on again to operate the wiper. 2 * 3 * (For example, when the vehicle speed is high, the intermittent operation speed will be faster.
(109,1) REAR WINDOW AND OUTSIDE MIRROR DEFROSTER SWITCH GUID-70C29E9A-49AD-4C5F-9A21-B7EEF9AD71A0 * Intermittent (INT) — intermittent opera1 tion (not adjustable) 2 Low (ON) — continuous low speed * operation 3 to operate the Push the switch forward * washer. Then the wiper will also operate several times. Wiper drip wipe system (if so equipped): JVI0967X REAR WINDOW WIPER AND WASHER OPERATIONGUID-BE7E5931-2B30-4C6A-8712-A3F555BE6757 If the rear window wiper operation is interrupted by snow etc.
(110,1) HEADLIGHT AND TURN SIGNAL SWITCH GUID-F39E5805-C881-4ED9-B63E-554EB445040A XENON HEADLIGHTS (if so equipped) GUID-94FAD85B-C538-48C3-98FA-48D5932EC992 WARNING HIGH VOLTAGE . When xenon headlights are on, they produce a high voltage. To prevent an electric shock, never attempt to modify or disassemble. Always have your xenon headlights replaced at an INFINITI retailer. . Xenon headlights provide considerably more light than conventional headlights.
(111,1) The autolight system can turn on the headlights automatically when it is dark and turn off the headlights when it is light. If the ignition switch is pushed to the OFF position and one of the doors is opened and this condition is continued, the headlights remain on for 5 minutes. SAA0642A SIC3268 Autolight system GUID-DEC1CC37-DB21-41AE-9624-D6735779F294 The autolight system allows the headlights to be set so they turn on and off automatically. To set the autolight system: 1.
(112,1) Battery saver system GUID-664B23EC-0053-44E4-A83B-5CAB720E9A9C For automatic headlights off delay setting, see “Light Off Delay” (P.4-20). A chime will sound when the driver side door is opened with the light switch in the or position and the ignition switch in the ACC, OFF or LOCK position.
(113,1) periods of time even if the headlights turn off automatically. Daytime running light system GUID-8B4B2AA8-36EF-492E-A6A0-57F9D51AAED8 The daytime running lights automatically illuminate when the engine is started with the parking brake released. The daytime running lights operate with the headlight switch in the OFF position or in the position. Turn the headlight switch to the position for full illumination when driving at night. However, the daytime running lights will turn off.
(114,1) to the − side. When reaching the minimum brightness, “MIN” appears on the display 3 . However, “MIN” does not appear * during the nighttime. The vehicle information display returns to the normal display under the following conditions: SIC3628 . when the instrument brightness control switch is not operated for more than 5 seconds. . when the or switch on the right side of the combination meter panel is pushed.
(115,1) HORN GUID-C6C817FB-584B-4062-BC70-F1B765B266F9 SIC3271 TURN SIGNAL SWITCH GUID-E1C56177-E1D2-4496-9D69-2D8E1B7E7D8C FOG LIGHT GUID-33BDF6EA-9062-427F-9AB6-3D01A86E20DC SWITCH 1 Turn signal * GUID-7FB756C8-9FF5-4189-A427-429D0445578E To turn the fog lights on, turn the headlight switch to the position, then turn the switch to the position. To turn them off, turn the switch to the OFF position. Move the lever up or down to signal the turning direction.
(116,1) HEATED SEATS GUID-5C770BAF-6029-499C-A3AA-7389CE1B7123 WARNING Do not use or allow occupants to use the seat heater if you or the occupants cannot monitor elevated seat temperatures or have an inability to feel pain in those body parts in contact with the seat. Use of the seat heater by such people could result in serious injury. . Any liquid spilled on the heated seat should be removed immediately with a dry cloth. .
(117,1) WARNING SYSTEMS SWITCH (if so equipped) GUID-3516DC6E-9566-4A0B-B66F-0C326A5AC4A3 mirrors, when the radar sensors detect a vehicle in the detection zone. If the turn signal is activated in the direction of the detected vehicle, a chime sounds twice and the side indicator light will flash. (See “Blind Spot Warning (BSW) system” (P.529).) 3. To turn off the heater, return the knob 3 . Make sure that to the OFF position * the indicator light turns off.
(118,1) SNOW MODE SWITCH GUID-1B76D948-A232-4DD1-85F0-9D8D60470EE3 INTELLIGENT BRAKE ASSIST (IBA) OFF SWITCH (if so equipped) GUID-7AEE2596-75BE-4DC0-AAD8-3BA40F09793D when the engine is started. If this procedure is repeated, the default status will return to ON. SIC3602 For driving or starting the vehicle on snowy roads or slippery areas, turn on the SNOW 1 on the mode switch. The indicator light * switch will illuminate.
(119,1) VEHICLE DYNAMIC CONTROL (VDC) OFF SWITCH CLOCK GUID-4A0D3F39-AF2F-448B-9337-BBB3943DF054 GUID-7DA31BFA-F3D3-4D04-8BAF-031A5FF806AF the engine to turn on the system. (See “Vehicle Dynamic Control (VDC) system” (P.5-102).) SIC3325 JVS0033X The vehicle should be driven with the Vehicle Dynamic Control (VDC) system on for most driving conditions. If the power supply is disconnected, the clock will not indicate the correct time. Readjust the time.
(120,1) POWER OUTLET GUID-CA7378E6-B4AD-4D7B-8E72-A03EB7B30A7F The power outlet is used for powering electrical accessories such as cellular telephones. . When not in use, be sure to close the cap. Do not allow water or any liquid to contact the outlet. CAUTION JVI1315X Center console SIC3631 Front . The outlet and plug may be hot during or immediately after use. . Do not use with accessories that exceed a 12 volt, 120W (10A) power draw.
(121,1) STORAGE GUID-49609C7E-DC47-4D85-99B7-F417C15D56DC CUP HOLDERS GUID-09F367FC-58FD-4B2C-A8B0-927B08014322 CAUTION . Avoid abrupt starting and braking when the cup holder is being used to prevent spilling the drink. If the liquid is hot, it can scald you or your passenger. . Use only soft cups in the cup holder. Hard objects can injure you in an accident. SIC3633 Rear The cup holders for rear passengers are located on the rear center armrest. To open the cup holder, pull the lid.
(122,1) . Do not leave glasses in the sunglasses holder while parking in direct sunlight. The heat may damage the glasses. SIC3246 SUNGLASSES HOLDER GUID-7444FFC3-1180-4DA0-889A-EF22DA69B8A8 WARNING 1 . * CAUTION . GLOVE BOXGUID-CB86453A-F160-47C9-9B7D-A973522418C0 WARNING Keep the sunglasses holder closed while driving to avoid obstructing the driver’s view and to help prevent an accident. To open the sunglasses holder, push SIC3866 Do not use for anything other than glasses.
(123,1) JVI1316X CONSOLE BOX GUID-B150A550-AB45-489D-9213-ED647E052637 To open the console box, push the button 1 . * To close, push the lid down until latched. The inner tray (if so equipped) can be 2 . Make positioned to the front or rear * sure that the arrow mark on the tray points A are toward the front and the bosses * aligned in the slits. SIC3663 CARD HOLDER GUID-2B53986B-319B-492D-BDF6-23C7429E7EDF 1 and slide a card Pull the sun visor down * A .
(124,1) CAUTION Do not apply a total load of more than 22 lb (10 kg) to a single hook. There are 4 or 5 hooks in the cargo area, depending on the model. SIC3248 COAT HOOKS GUID-967014A4-B654-44F1-A0BC-FAC4FD4136DC JVI1317X LUGGAGE HOOKS GUID-901A4A86-EDAC-4B5B-90D1-45F288B31AFE The coat hooks are equipped beside the rear personal lights. CAUTION Do not place items which are more than 2 lb (1 kg) on the hook. WARNING . Always make sure that the cargo is properly secured.
(125,1) SIC3636 CARGO COVER (if so equipped) GUID-65D26526-8166-408E-BEBD-409EC13418BC The cargo cover keeps the contents in the cargo area hidden from the outside. To use the cargo cover, pull it out and hang 1 . both sides on the hooks * SIC3637 To stow the cargo cover, remove it from the hooks and hold until it is retracted. Make sure that the cargo cover is snapped into 2 the holders * to keep it from moving around while driving.
(126,1) M.S.S. certification label (located on the driver’s door pillar). For more information regarding GVWR and GAWR, see “Vehicle loading information” (P.9-12). straps to help prevent it from sliding or shifting. Do not place cargo higher than the seatbacks. In a sudden stop or collision, unsecured cargo could cause personal injury. . . .
(127,1) WINDOWS GUID-C17FF611-9489-44AF-8A8E-A9D7C6C3FC14 CAUTION Use care when placing or removing items from the roof rack. If you cannot comfortably lift the items onto the roof rack from the ground, use a ladder or stool. POWER WINDOWS GUID-35444917-F6B2-409B-B28D-E33DAD3F2551 the windows is canceled. WARNING . Make sure that all passengers have their hands, etc. inside the vehicle while it is in motion and before closing the windows.
(128,1) Locking passengers’ windows GUID-FDFC977F-A9D1-4206-BC7E-F510D4B2D629 C is pushed in, only When the lock button * the driver side window can be opened or closed. Push it in again to cancel. SIC3640 1. 2. 3. 4. 5.
(129,1) Auto reverse function GUID-E1134449-3D1F-4777-AD24-71D309A5C49B WARNING There are some small distances immediately before the closed position which cannot be detected. Make sure that all passengers have their hands, etc., inside the vehicle before closing the window. SIC3285 Automatic operation (for front door windows) GUID-076BDDA9-6A3F-4D13-8169-6A98C70146CF To fully open or close the window, completely push down or pull up the switch and release it; it need not be held.
(130,1) MOONROOF GUID-36CBB3A9-507A-49BD-95E0-991B2A8C1DB4 WARNING . In an accident you could be thrown from the vehicle through an open moonroof. Always use seat belts and child restraints. . Do not allow anyone to stand up or extend any portion of their body out of the moonroof opening while the vehicle is in motion or while the moonroof is closing. POWER MOONROOF GUID-1E35E90B-4C54-407D-9665-69E54D000E95 The moonroof only operates when the ignition switch is in the ON position.
(131,1) WELCOME LIGHT GUID-A579FFF2-EC26-4993-A6B0-EF88F413337E moonroof switch and release it; it need not be held. The roof will automatically open or close all the way. To stop the roof, push the switch once more while it is opening or closing. Auto reverse function GUID-4D977CB7-F919-4D6B-B645-C2A1897B97E1 WARNING There are some small distances immediately before the closed position which cannot be detected. Make sure that all passengers have their hands, etc.
(132,1) INTERIOR LIGHTS GUID-830CFA4B-7BC2-4EB5-B729-3DEBD5B2F404 4. A chime sounds when the setting is completed. Once the welcome light function is active, A the puddle light * and the passenger cabin illumination will illuminate when you approach the vehicle with the Intelligent Key (within approximately 3.3 feet (1 m) of the antenna built inside the door handles) and the following conditions are met. . All doors are closed and locked. . The ignition switch is in the LOCK or OFF position. .
(133,1) SIC3250 SIC3251 PERSONAL GUID-427C090A-E791-4E67-B530-6B20EBFA79D8 LIGHTS INTERIOR LIGHT CONTROL SWITCH GUID-D0E2EF38-2D5D-4501-AA23-4F24DD8B41E1 Rear The interior light control switch has three positions: ON, DOOR and OFF. GUID-53C24D15-30C9-4180-BE68-488250E97CB0 Push the button as illustrated to turn the light on or off. ON position GUID-59FCC4C9-B087-423C-A637-EDC3922142A0 1 When the switch is in the ON position * the map lights and rear personal lights will illuminate.
(134,1) VANITY MIRROR LIGHTS CARGO LIGHT GUID-E3368CF8-A3EF-4DAC-9176-8558DF7C9907 GUID-65B14C49-101C-46AA-9AC8-BE69E9C5943F — remain on while the door is opened. When the door is closed, the lights go off. OFF position GUID-54D68F81-4C9B-4125-B4D4-08360530DF65 3 , When the switch is in the OFF position * the lights will not illuminate, regardless of the condition. CAUTION Do not use for extended periods of time with the engine stopped. This could result in a discharged battery.
(135,1) HomeLink® UNIVERSAL TRANSCEIVER (if so equipped) GUID-BBDE6354-59FD-4B7D-831F-DCCDCD8C2E6F The HomeLink® Universal Transceiver provides a convenient way to consolidate the functions of up to three individual handheld transmitters into one built-in device. features as required by federal safety standards. (These standards became effective for opener models manufactured after April 1, 1982).
(136,1) customers and gate openers” (P.2-61). JVI0428X 2. Using both hands, simultaneously press and hold the desired HomeLink® button and handheld transmitter button. DO NOT release until the 1 flashes HomeLink® indicator light * slowly and then rapidly. When the indicator light flashes rapidly, both buttons may be released. (The rapid flashing indicates successful programming.
(137,1) stand on your vehicle to perform the next steps. HomeLink® web site at: www. homelink.com or call 1-800-355-3515. 4. At the receiver located on the garage door opener motor in the garage, locate the “learn” or “smart” button (the name and color of the button may vary by manufacturer but it is usually located near where the hanging antenna wire is attached to the unit). If there is difficulty locating the button, reference the garage door opener’s manual.
(138,1) mitted. 3515. For convenience, the hand-held transmitter of the device may also be used at any time. CLEARING THE PROGRAMMED INFORMATIONGUID-E19425B0-012C-4DD3-97E8-55080D791B47 PROGRAMMING TROUBLESHOOTING GUID-97CF8886-10E7-4D65-ACF3-98574F97B33F If the HomeLink® does not quickly learn the hand-held transmitter information: . replace the hand-held transmitter batteries with new batteries. . position the hand-held transmitter with its battery area facing away from the HomeLink® surface. .
(139,1) FCC Notice: For USA: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
(140,1) MEMO 2-64 Instruments and controls Condition: [ Edit: 2015/ 6/ 12 Model: J50-D ]
(141,1) 3 Pre-driving checks and adjustments Keys .................................................................... ... 3-2 Intelligent Key ................................................. ... 3-2 Valet hand-off ................................................. ... 3-3 Doors .................................................................. ... 3-4 Locking with mechanical key ........................... ... 3-4 Opening and closing windows with the mechanical key ........................................
(142,1) KEYS GUID-EA126302-6FAF-4C72-BECE-5E088F00D216 A key number plate is supplied with your keys. Record the key number and keep it in a safe place (such as your wallet), not in the vehicle. If you lose your keys, see an INFINITI retailer for duplicates by using the key number. INFINITI does not record any key numbers so it is very important to keep track of your key number plate. vehicle.
(143,1) — Do not change or modify the Intelligent Key. CAUTION — Do not use a magnet key holder. Always carry the mechanical key installed in the Intelligent Key. — Do not place the Intelligent Key near an electric appliance such as a television set or personal computer. VALET HAND-OFF GUID-A099C12D-9FC8-46D0-B227-F50EC3E02AAF — Do not allow the Intelligent Key to come into contact with water or salt water, and do not wash it in a washing machine. This could affect the system function. .
(144,1) DOORS GUID-11122824-7934-4DF7-86A9-789D6D5A76D9 . You can switch the lock system to the mode that allows you to open all the doors when the key is turned once. (See “How to use SETTING button” (P.4-13).) WARNING . Always have the doors locked while driving. Along with the use of seat belts, this provides greater safety in the event of an accident by helping to prevent persons from being thrown from the vehicle.
(145,1) Lockout protection GUID-45A339AC-C8C7-402C-8A35-F91E660BF6D7 When the power door lock switch (driver or front passenger) is moved to the lock position with the Intelligent Key in the port and any door open, all doors will lock and unlock automatically. With the Intelligent Key left in the vehicle (not in the Intelligent Key port) and any door open, all doors will unlock automatically and a chime will sound after the door is closed.
(146,1) CHILD SAFETY REAR DOOR LOCKS GUID-7AF8CF4F-8984-4F1B-86CF-38E6A6F2CFAE 3. Within 20 seconds of performing Step 2, push and hold the power door lock switch to the position (UNLOCK) for more than 5 seconds. Child safety rear door locks help prevent doors from being opened accidentally, especially when small children are in the vehicle. 4. When activated, the hazard indicator will flash twice. When deactivated, the hazard indicator will flash once.
(147,1) INTELLIGENT KEY SYSTEM GUID-86E379A8-3249-491E-918A-8533FABDF9A9 WARNING . . Radio waves could adversely affect electric medical equipment. Those who use a pacemaker should contact the electric medical equipment manufacturer for the possible influences before use. The Intelligent Key transmits radio waves when the buttons are pushed. The FAA advises that the radio waves may affect aircraft navigation and communication systems. Do not operate the Intelligent Key while on an airplane.
(148,1) CAUTION . Do not allow the Intelligent Key, which contains electrical components, to come into contact with water or salt water. This could affect the system function. . Do not drop the Intelligent Key. . Do not strike the Intelligent Key sharply against another object. . Do not change or modify the Intelligent Key. . Wetting may damage the Intelligent Key. If the Intelligent Key gets wet, immediately wipe until it is completely dry. .
(149,1) SPA2326 SPA2074 INTELLIGENT KEY OPERATING RANGE GUID-855379CF-D1BD-456D-888E-F458F01E0186 The Intelligent Key functions can only be used when the Intelligent Key is within the specified operating range from the request 1 . switch * When the Intelligent Key battery is discharged or strong radio waves are present near the operating location, the Intelligent Key system’s operating range becomes narrower, and the Intelligent Key may not function properly. The operating range is within 31.
(150,1) you carry the key with you and then lock the doors. . Do not pull the door handle before pushing the door handle request switch. The door will be unlocked but will not open. Release the door handle once and pull it again to open the door. . The Intelligent Key system (opening/ closing doors with the door handle request switch) can be set to remain inactive. (See “Vehicle information and settings” (P.4-9).
(151,1) you, you can lock or unlock all doors by pushing the door handle request switch A or the lift (driver’s or front passenger’s) * B within the range of gate request switch * operation. When you lock or unlock the doors or the lift gate, the hazard indicator will flash and the horn (or the outside chime) will sound as a confirmation. For details, see “Setting hazard indicator and horn mode” (P.3-14).
(152,1) TROUBLESHOOTING GUIDE GUID-EED2B883-4100-4320-B819-2F375972BB23 Symptom The SHIFT P warning appears on the display When pushing the ignition switch and the inside warning chime sounds conto stop the engine tinuously. Action to take The shift lever is not in the P (Park) position. Shift the shift lever to the P (Park) position. The ignition switch is in the ACC position. Push the ignition switch to the OFF position. The Intelligent Key is in the Intelligent Key port.
(153,1) REMOTE KEYLESS ENTRY SYSTEM GUID-15E71DED-7DD0-411C-86F6-371302C7A6CA WARNING The Intelligent Key transmits radio waves when the buttons are pushed. The FAA advises that the radio waves may affect aircraft navigation and communication systems. Do not operate the Intelligent Key while on an airplane. Make sure that the buttons are not operated unintentionally when the unit is stored for a flight.
(154,1) 3. Push the LOCK Intelligent Key. button 1 * on the 4. All the doors, the lift gate and fuel-filler door will lock. 5. The hazard indicator flashes twice and the horn chirps once. *: Doors will lock with the Intelligent Key while the ignition switch is in the ACC or ON position. Unlocking doors and fuel-filler door GUID-CC8A76D2-67AD-47FD-971C-B7968A47AF43 2 on the 1. Push the UNLOCK button * Intelligent Key once. 2. The hazard indicator flashes once.
(155,1) indicator nor the horn operates.
(156,1) HOOD Switching procedure: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 To switch the hazard indicator and horn 1 (chime) operation, push the LOCK * 2 buttons on the Inteland UNLOCK * ligent Key simultaneously for more than 2 seconds. GUID-E67931F1-ABB7-43D4-A257-B87998011086 . When the hazard indicator mode is set, the hazard indicator flashes 3 times. . When the hazard indicator and horn mode is set, the hazard indicator flashes once and the horn chirps once. JVP0392X 1 1.
(157,1) LIFT GATE GUID-E3048FED-A620-48C7-BF89-696E3D4A8243 WARNING . Always be sure the lift gate has been closed securely to prevent it from opening while driving. . Do not drive with the lift gate open. This could allow dangerous exhaust gases to be drawn into the vehicle. See “Precautions when starting and driving” (P.5-4) for exhaust gas. JVP0393X . The power door lock system allows you to lock or unlock all doors including the lift gate simultaneously. A and pull the .
(158,1) FUEL-FILLER DOOR GUID-11622BF7-507F-4195-AC95-8F3201F81940 . Push the power door lock switch to the UNLOCK position. To lock, close the fuel-filler door securely and lock all doors by operating the door handle request switch, the LOCK button on the Intelligent Key, the mechanical key or the power door lock switch. result in a serious malfunction and possible injury. It could also cause the malfunction indicator light to come on. .
(159,1) . Insert the cap straight into the fuel-filler tube, then tighten the fuel-filler cap until a single click is heard. Failure to tighten the fuel-filler cap properly may cause the malfunction indicator light (MIL) to illuminate. If the light illuminates because the fuel-filler cap is loose or missing, tighten or install the cap and continue to drive the vehicle. The light should turn off after a few driving trips.
(160,1) TILT/TELESCOPIC COLUMN GUID-695691CE-370F-4FAB-AE66-9B452F6CD973 tightening the fuel-filler cap. WARNING . Do not adjust the steering wheel while driving. You could lose control of your vehicle and cause an accident. . Do not adjust the steering wheel any closer to you than is necessary for proper steering operation and comfort. The driver’s air bag inflates with great force.
(161,1) SUN VISORS GUID-58FC6E62-285C-40C0-8870-719830BE27DC For more information, see “Automatic drive positioner” (P.3-25). SPA2456 ELECTRIC OPERATION (if so equipped) GUID-C8665475-E2E5-4845-AE04-1DA59654EDD1 Tilt or telescopic operation GUID-F6CB52A9-EF0D-4F84-9D5B-1FED3050920A Move the lever to adjust the steering wheel up or down, forward or rearward to the desired position.
(162,1) MIRRORS GUID-F58E3F40-6078-40DC-8F8F-3D5B2C2042D5 2. To block glare from the side, remove the main sun visor from the center mount and swing the visor to the side 2 . * 3. Slide the sun visor needed. 3 * in or out as SPA2447 INSIDE MIRROR GUID-A1DA0342-E5E5-465C-B41A-399CC7C4DFA3 Adjust the height and the angle of the inside mirror to the desired position.
(163,1) indicator light will turn off. Push the “I” D to turn the system on. switch * Do not allow any object to cover the E sensors * or apply glass cleaner on them. Doing so will reduce the sensitivity of the sensor, resulting in improper operation. For the HomeLink® Universal Transceiver operation, see “HomeLink ® Universal Transceiver” (P.2-59).
(164,1) Adjusting outside mirrors GUID-6C519BF8-54BC-460D-83D7-1D8A28A51396 3. Choose the right or left outside mirror by operating the outside mirror control switch. The outside mirror control switch is located on the armrest. 4. The selected outside mirror surface moves downward. The outside mirror will operate only when the ignition switch is in the ACC or ON position. When one of the following conditions has occurred, the selected outside mirror surface will return to its original position.
(165,1) AUTOMATIC DRIVE POSITIONER (if so equipped) GUID-86283F29-CBF9-4BB2-9CC4-1D76F06E52D1 The automatic drive positioner system has the following features: . Entry/exit function . Seat synchronization function . Memory storage SIC3869 VANITY MIRROR GUID-FD6B884E-5A21-4735-8A2D-20B5FF91BB0F To use the front vanity mirror, pull down the sun visor and pull up the cover.
(166,1) The seat synchronization function operates under the following conditions: The entry/exit function will be activated. JVP0230X SEAT SYNCHRONIZATION FUNCTION GUID-9C62EB27-3C7E-4058-AC3B-D9D8EE82055C The seat synchronization function automatically adjusts the positions of the steering wheel and outside mirrors when the seat is adjusted using the power seat switches. However, the steering wheel and outside mirrors will not move if the seat is adjusted over the maximum thresholds.
(167,1) seconds while the ignition switch is in the ACC position. mately 5 seconds after pushing the switch. The indicator lights on the memory switches (1 and 2) will blink once when the function is canceled, and the indicator lights will blink twice when the function is activated. When the memory is stored in the memory switch (1 or 2), a buzzer will sound. MEMORY STORAGE GUID-1C3A99E4-375E-45E2-BED3-7CC50A6635A6 If memory is stored in the same memory switch, the previous memory will be deleted.
(168,1) . . Push the memory switch (1 or 2) fully for at least 1 second. Within 45 seconds of opening the driver’s door, push the memory switch (1 or 2) fully for at least 1 second. The driver’s seat, steering column and outside mirrors will move to the memorized position or to the exit position when the entry/exit function is set to active with the indicator light flashing, and then the light will stay on for approximately 5 seconds.
(169,1) 4 Monitor, climate, audio, phone and voice recognition systems Safety note.......................................................... ... 4-3 Center multi-function control panel...................... ... 4-3 How to use INFINITI controller ......................... ... 4-5 How to use touch screen (models with navigation system) .......................................... ... 4-5 Menu options (models with navigation system) .......................................... ...
(170,1) Operating tips ............................................... ... 4-60 In-cabin microfilter ........................................ ... 4-60 Servicing climate control ............................... ... 4-61 Audio system .................................................... ... 4-61 Audio operation precautions ......................... ... 4-61 FM-AM-SAT radio with Compact Disc (CD) player .................................................... ...
(171,1) SAFETY NOTE CENTER MULTI-FUNCTION CONTROL PANEL GUID-4B3FA76A-56D9-437D-9826-FD414C1230E8 GUID-A1350C3E-4827-46B4-848A-A53966DEBE30 WARNING . Do not disassemble or modify this system. If you do, it may result in accidents, fire, or electric shock. . Do not use this system if you notice any abnormality, such as a frozen screen or lack of sound. Continued use of the system may result in accident, fire or electric shock. .
(172,1) SAA1524 Models without navigation system 1. “AUX” button (P.4-61) If you use the system with the engine not 2. “RADIO AM·FM” band select button running (ignition ON or ACC) for a long (P.4-61) time, it will use up all the battery power, and the engine will not start. 3. INFINITI controller (P.4-5) 4. “ OFF” brightness control and display ON/OFF button (P.4-9) 5. “INFO” vehicle information button (P.4-9) 6. “DISC” selector button (P.4-61) 7. “STATUS” status display button (P.4-9) 8.
(173,1) HOW TO USE INFINITI CONTROLLER GUID-034896B8-60D4-4480-8908-7F8AFFD52666 Choose an item on the display using the 2 (or additional main directional buttons * 6 directional buttons * with navigation 3 , and push the system) or center dial * 1 for operation. ENTER button * 4 before the If you push the BACK button * setup is completed, the setup will be canceled and/or the display will return to the previous screen. This button can also be used to delete characters that have been input.
(174,1) SAA2473 Touch screen operation GUID-AF81D239-00F7-412D-AF25-A1CA5191D2E0 With this system, the same operations as those for the INFINITI controller are possible using the touch screen operation. Selecting theGUID-D73A39BF-43C8-459F-9C24-47B7F579C407 item: Touch an item to select it. To select the “Audio” settings, touch the “Audio” area 1 on the screen. * SAA2474 Adjusting an GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 item: 1 or − * 2 button to adjust the Touch the + * settings.
(175,1) . Delete: Deletes the last character that has been input with one touch. Push and hold the button to delete all of the characters. . OK: Completes character inputs. Touch screen maintenance GUID-CEEDE718-B557-40FA-AAB2-922D39EF717A If you clean the display screen, use a dry, soft cloth. If additional cleaning is necessary, use a small amount of neutral detergent with a soft cloth. Never spray the screen with water or detergent. Dampen the cloth first, and then wipe the screen.
(176,1) HOW TO SELECT MENUS ON THE SCREEN GUID-34F77A0B-1A8F-4CD3-A977-14B6223CE977 about the menu selection currently highlighted. Vehicle functions are viewed on the display screen in menus. To select each key item, highlight the preferred item using the INFINITI controller and push the ENTER button. Whenever a menu selection is made or menu item is highlighted, different areas on the screen provide you with important information. See the following for details.
(177,1) VEHICLE INFORMATION AND SETTINGS GUID-740504CB-8D84-4DF0-A3A3-7B0B7C1E1029 HOW TO USE STATUS BUTTON GUID-1976C9F3-F619-456F-82C5-5199A15E815E You can check information related to the audio, climate control system, fuel consumption and navigation system (if so equipped) by pushing the STATUS button repeatedly.
(178,1) 1. Push the INFO button on the control panel. 2. Select an item from the INFO menu. 3. After viewing or adjusting the information on the following screens, push the BACK button to return to the INFO menu. See the separate Navigation System Owner’s Manual for the following items: . . . . . .
(179,1) Fuel Economy information GUID-0C6200B4-86B3-470B-9A7A-5B84D712C89E The approximate distance to empty, average fuel economy and current fuel economy will be displayed for reference. To reset the average fuel economy (Avg Fuel Econ), select the “Reset Fuel Eco” or “Reset” key. If the “Fuel Eco History” or “View” key is selected, the average fuel consumption history will be displayed in graph form along with the average for the previous Reset-to-Reset period.
(180,1) Maintenance information GUID-B0CE4DD0-ABB6-4371-8E37-69C394B69C0B button” (P.4-13).) The maintenance intervals can be displayed for the engine oil, oil filter, tire and other reminders. To set a maintenance interval, select a preferred item from the list. You can also set to display a message to remind you that the maintenance needs to be performed. The following example shows how to set the engine oil maintenance information. Use the same steps to set the other maintenance information.
(181,1) HOW TO USE SETTING BUTTON GUID-040D1EFC-1D7E-41AF-BAD0-28FB0E97C46F The display as illustrated will appear when the SETTING button is pushed. For navigation settings, refer to the separate Navigation System Owner’s Manual. SAA2483 Others information (models with navigation system) GUID-9EB8F3F0-6FA2-4D77-80B2-7757E207A583 SAA2484 Models with navigation system The Others information display will appear when pushing the INFO button and selecting the “Others” key.
(182,1) Audio settings GUID-57225899-0F38-4259-B7F8-B113BC842F48 The display as illustrated will appear when pushing the SETTING button and selecting the “Audio” key. Bass/Treble/Balance/Fade: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 To adjust the speaker tone quality and sound balance, select the “Bass”, “Treble”, “Balance” or “Fade” key and adjust it with the INFINITI controller. These items can also be adjusted by pushing and turning the AUDIO knob. SAA2485 Models with navigation system Surround Vol.
(183,1) Phone settings (models with navigation system) GUID-88871DFB-9AEB-4F6F-843E-66985C858DDE Guidance Volume: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 To adjust the guidance voice volume louder or softer, select the “Guidance Volume” and adjust it with the INFINITI controller. For details of the “Phone” settings, see “Bluetooth® Hands-Free Phone System (models with navigation system)” (P.4-99).
(184,1) Driver assistance settings (if so equipped) GUID-EFA2CD44-027E-4867-A69B-DDD5E96F6185 For the details of the “Driver Assistance” settings, see the following items: . “Lane Departure Warning (LDW)/Lane Departure Prevention (LDP) systems” (P.5-20). . “Distance Control Assist (DCA) system” (P.5-63).
(185,1) To turn on the screen, set this item to the “ON” position or push the “ OFF” button. When any mode button is pushed with the screen off, the screen turns on for further operation. The screen will turn off automatically 5 seconds after the operation is finished.
(186,1) This clock will indicate the time almost exactly because it is always adjusted by the GPS system. Clock Format GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 (24h): When this item is turned to ON, the 24hour clock is displayed. When this item is not turned to ON, the 12-hour clock is displayed.
(187,1) Corner Sonar Sensitivity: Adjust the sensitivity level of the corner sonar higher (right) or lower (left). Center Sonar Sensitivity: Adjust the sensitivity level of the center sonar higher (right) or lower (left). JVH0142M SONAR settings (if so equipped) GUID-629DF5DB-3B8F-4792-8ABD-7AB91A95C265 The “Sonar” screen will appear when pushing the “SETTING” button, selecting the “Sonar” key with the INFINITI controller and pushing the ENTER button.
(188,1) Lift Steering Wheel on Exit (if so equipped): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 When this item is turned on, the steering wheel moves upward for easy exit if the ignition switch is in the LOCK position and the driver’s door is opened. After getting into the vehicle and pushing the ignition switch to the ACC position, the steering wheel moves to the previous position.
(189,1) Language & Units settings GUID-EB399EBE-AB93-480C-A2F4-B5FADEB4AA46 Selective Door Unlock: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 When this item is turned on, only the driver’s door is unlocked first after the door unlock operation. When the door handle request switch on the driver’s or front passenger’s side door is pushed to be unlocked, only the corresponding door is unlocked first. All the doors can be unlocked if the door unlock operation is performed again within 60 seconds.
(190,1) images, stop the vehicle in a safe location and apply the parking brake. system (models with navigation system)” (P.4-124). SAA2491 Image Viewer (models with navigation system)GUID-638099F4-6351-46FB-82A7-57169F1C6E32 The image files in the USB memory will be displayed. To display the Image Viewer, push the SETTING button, select the “Other” key and then select the “Image Viewer” key. The image of the selected file is displayed on the right side of the screen.
(191,1) file. . (Previous) Select the “ ” key to display the previous file. Setting the Image Viewer: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 The Image Viewer setting display will appear when selecting the “Settings” key on the full screen display. The following settings are available for the full screen display. SAA2492 Full Screen Display: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 The full screen display will appear when selecting the “Full Screen Display” key.
(192,1) REARVIEW MONITOR (if so equipped) GUID-2717A83B-BC83-4D32-B3E1-639C5D78F734 WARNING Failure to follow the warnings and instructions for proper use of the RearView Monitor system could result in serious injury or death. . The RearView Monitor is a convenience but it is not a substitute for proper backing. Always turn and look out the windows, and check mirrors to be sure that it is safe to move before operating the vehicle. Always back up slowly. .
(193,1) Vehicle width guide lines 5 : * Indicate the vehicle width when backing up. Predictive course lines SAA1896 HOW TO READ THE DISPLAYED LINES GUID-03B5E1E8-FBE1-4330-949B-2F63E5D564F3 Guiding lines which indicate the vehicle width and distances to objects with referA are displayed ence to the bumper line * on the monitor. Distance guide lines: HOW TO PARK WITH PREDICTIVE COURSE LINES GUID-C5446C81-6120-4FA2-B555-777ED71FA8E5 6 : * Indicate the predictive course when backing up.
(194,1) referring to the predictive course lines. 5. When the vehicle is parked in the space completely, move the shift lever to the P (Park) position and apply the parking brake. Difference between predictive and actual distances GUID-3499FB08-D1D0-4961-BF79-70F42E162429 The displayed guidelines and their locations on the ground are for approximate reference only.
(195,1) JVH1159X Backing up on a steep uphill: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 When backing up the vehicle up a hill, the distance guide lines and the vehicle width guide lines are shown closer than the actual distance. Note that any object on the hill is farther than it appears on the monitor.
(196,1) actual backing up course. ADJUSTING GUID-1BA2FF0E-226F-4B4D-965F-A24421734E81 THE SCREEN 1. Push the SETTING button while the RearView Monitor screen is displayed. 2. Select the “Display” key. 3. Select a preferred item. Display ON/ OFF, Brightness, Tint, Color, Contrast and Black Level of the RearView Monitor can be adjusted. 4. Adjust the selected item using the INFINITI controller. SAA2606 NOTE: Do not adjust any of the display settings of the RearView Monitor while the vehicle is moving.
(197,1) REARVIEW MONITOR SYSTEM LIMITATIONS GUID-920C4F40-67DE-408B-88D9-A6D61603B6B1 . Use the displayed lines as a reference. The lines are highly affected by the number of occupants, fuel level, vehicle position, road conditions and road grade. Listed below are the system limitations for RearView Monitor. Failure to operate the vehicle in accordance with these system limitations could result in serious injury or death. . Make sure that the lift gate is securely closed when backing up. .
(198,1) If dirt, rain or snow accumulates on the 1 , RearView Monitor may not camera * display objects clearly. Clean the camera by wiping it with a cloth dampened with a diluted mild cleaning agent and then wiping it with a dry cloth. JVH1158X SYSTEM MAINTENANCE GUID-B070409C-95D6-4256-A064-26AE34FBF051 CAUTION . Do not use alcohol, benzine or thinner to clean the camera. This will cause discoloration.
(199,1) AROUND VIEW® MONITOR (if so equipped) GUID-9F356AD4-8F49-4908-BFCC-9727E4C0EC76 The four corners of the vehicle in particular, are areas where objects do not always appear in the bird’s-eye, front, or rear views. Always check your surroundings to be sure that it is safe to move before operating the vehicle. Always operate the vehicle slowly. Always look out the windows and check mirrors to be sure that it is safe to move. .
(200,1) Available views: . Front view An approximately 150-degree view of the front of the vehicle. . Rear view An approximately 150-degree view of the rear of the vehicle. . Bird’s-eye view The surrounding view of the vehicle from above. . Front-side view The view around and ahead of the front passenger’s side wheel. . Front-wide view An approximately 180-degree view of the front of the vehicle. . Rear-wide view An approximately 180-degree view of the rear of the vehicle.
(201,1) AROUND VIEW® MONITOR SYSTEM OPERATIONGUID-FD1966A0-218B-4C86-A1CD-1C9065731C6E With the ignition switch in the ON position, move the shift lever to the “R” (Reverse) position or press the CAMERA button to operate the Around View® Monitor. . When driving the vehicle up a hill, objects viewed in the monitor are further than they appear. When driving the vehicle down a hill, objects viewed in the monitor are closer than they appear. .
(202,1) Front and rearview: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 Guiding lines that indicate the approximate vehicle width and distances to objects with A , are reference to the vehicle body line * displayed on the monitor. Distance guide lines: Indicate distances from the vehicle body. 1 : approx. 1.5 ft (0.5 m) . Red line * 2 : approx. 3 ft (1 m) . Yellow line * 3 : approx. 7 ft (2 m) . Green line * 4 : approx. 10 ft (3 m) .
(203,1) eye view is displayed. It will be shown only the first time after the ignition switch is placed in the “ON” position. The driver can check the approximate direction and angle of the tire on the 3 when driving the display by tire icon * vehicle forward or backward. the predictive course lines are shown at back of the vehicle. WARNING . Objects in the bird’s-eye view will appear further than the actual distance. .
(204,1) Front-wide/rear-wide view: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 The front-wide/rear-wide view shows a wider area on the entire screen and allows the checking of the blind corners on the right and left sides. The front-wide/rearwide view displays an approximately 180degree area while the front view and the rear view display an approximately 150degree area. The predictive course lines are not displayed when using the front-wide/ rear-wide view.
(205,1) JVH1159X Backing up on a steep uphill: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 When backing up the vehicle up a hill, the distance guide lines and the vehicle width guide lines are shown closer than the actual distance. Note that any object on the hill is farther than it appears on the monitor.
(206,1) actual backing up course. JVH1144X How to switch the display GUID-82BB86F8-BD77-4DA3-8C85-190F14A5F1A2 SAA1980 The Around View® Monitor can display two split views as well as a single view of the front-wide view or rear-wide view. Push the CAMERA button, change the shift lever position, or select the “Change View” key 1 to switch between the available views.
(207,1) HOW TO ADJUST THE SCREEN VIEW GUID-345480AB-4BCA-4DBA-8271-6568E4007873 Camera View Priority: The display settings such as Display ON/ OFF, Brightness, Tint, Color, Contrast and Black Level of the Around View® Monitor can be adjusted. The view shown on the screen at the beginning of Around View® Monitor operation can be selected in order of priority. Non-viewable Area Reminder: 1. Push the SETTING button with the Around View® Monitor turned on.
(208,1) Sonar Sensitivity: around the cameras. Otherwise, water may enter the camera unit causing water condensation on the lens, a malfunction, fire or an electric shock. See “Camera aiding sonar function (models with Around View® Monitor)” (P.4-43). AROUND VIEW® MONITOR SYSTEM LIMITATIONS GUID-2DA02995-3AB7-4D45-BDB9-0A940591D11E WARNING Listed below are the system limitations for Around View® Monitor.
(209,1) camera viewing areas will not appear in the 2 . monitor * JVH0270X System temporarily unavailable GUID-E6A4C604-56BE-4BB7-A51D-FF155CB0E7FC JVH0791X When the “!” icon is displayed on the screen, there will be abnormal conditions in the Around View® Monitor. This will not hinder normal driving operation but the system should be inspected by an INFINITI retailer. There are some areas where the system will not show objects and the system does not warn of moving objects.
(210,1) If dirt, rain or snow accumulates on any of ® 1 , the Around View Monitor the cameras * may not display objects clearly. Clean the camera by wiping with a cloth dampened with a diluted mild cleaning agent and then wiping with a dry cloth. JVH0271X When the “[X]” icon is displayed on the screen, the camera image may be receiving temporary electronic disturbances from surrounding devices.
(211,1) CAMERA AIDING SONAR FUNCTION (models with Around View® Monitor) GUID-FC1D8BC0-B7EF-4DA7-8582-54AD75267399 WARNING Failure to follow the warnings and instructions for proper use of the sonar function as outlined in this section could result in serious injury or death. . The sonar is a convenience feature. It is not a substitute for proper parking. . This function is designed as an aid to the driver in detecting large stationary objects to help avoid damaging the vehicle. .
(212,1) SONAR SYSTEM OPERATION GUID-6F3B483B-D8EF-4FE2-A414-7283930CCD94 The system gives the tone for front objects when the shift lever is in the “D” (Drive) position and both front and rear objects when the shift lever is in the “R” (Reverse) position. seconds when an object is detected by only the corner sonar and the distance does not change. The tone will stop when the object is no longer near the vehicle.
(213,1) In the below cases, the sonar will be turned back on automatically: . When the shift lever is placed in the “R” (Reverse) position. . When the CAMERA button is pressed and a screen other than the camera view is shown on the display. . When vehicle speed decreases below approximately 6 MPH (10 km/h). . When the ignition switch is placed in the “OFF” position and turned back to the “ON” position again. To prevent the sonar system from activating altogether, use the “Camera” menu.
(214,1) turned to OFF (indicator turns off), the front and rear sonar is deactivated. The amber markers are displayed at the corners of the vehicle icon and the sonar icon will disappear from the . The next time the ignition switch is placed in the “ON” position, “Sonar is OFF” is displayed briefly.
(215,1) — Fluffy objects such as snow, cloth, cotton, grass or wool. — Thin objects such as rope, wire or chain. — Wedge-shaped objects. . If your vehicle sustains damage to the bumper fascia, leaving it misaligned or bent, the sensing zone may be altered causing inaccurate measurement of objects or false alarms.
(216,1) MOVING OBJECT DETECTION (MOD) (if so equipped) GUID-21F0C0E6-E1A3-4876-B7B3-814F3BD11F87 objects surrounding the vehicle. When maneuvering, always use the outside mirror and rearview mirror and turn and check the surrounding to ensure it is safe to maneuver. . The system is deactivated at speeds above 6 MPH (10 km/h). It is reactivated at lower speeds. . The MOD system is not designed to detect the surrounding stationary objects.
(217,1) MOD SYSTEM OPERATION GUID-21A55817-E686-49C1-8F4E-828F71369104 The MOD system will turn on automatically under the following conditions: . When the shift lever is in the “R” (Reverse) position. . When the CAMERA button is pushed to activate the camera view on the display. . When vehicle speed decreases below approximately 5 MPH (8 km/h) and the camera screen is displayed. . When the ignition switch is placed in the OFF position and then back to the ON position.
(218,1) While the sonar is beeping, the MOD system does not chime. 3 is displayed in the A blue MOD icon * view where the MOD system is operative. A 3 is displayed in the view gray MOD icon * where the MOD system is not operative. If the MOD system is turned off, the MOD 3 is not displayed. icon * moving objects in the rear view or rear-wide view. The MOD system will not operate if the lift gate is open. The MOD system does not detect moving objects in the front-side view.
(219,1) MOD function setting GUID-4112DA4B-BEF9-433F-8656-E19E4B4418FF MOD SYSTEM LIMITATIONS GUID-812BECA8-975F-49A9-87D8-6AFB4472D659 To activate or deactivate the MOD function, push the SETTING button, select “Others” key, select the “Camera” key on the center display, and then select the “Moving Object Detection (MOD)” key. WARNING JVH0269X When this item is turned on, the MOD is activated. When this item is turned off (indicator turns off), the MOD system is deactivated.
(220,1) If dirt, rain or snow accumulates on any of 1 , the MOD system may not the cameras * operate properly. Clean the camera by wiping with a cloth dampened with a diluted mild cleaning agent and then wiping with a dry cloth. — When the position of the moving objects in the display is not changed. . The MOD system might detect flowing water droplets on the camera lens, white smoke from the muffler, moving shadows, etc. .
(221,1) VENTILATORS HEATER AND AIR CONDITIONER GUID-BECDE132-14C5-4F77-9E0E-024F840E756E GUID-2CBC633B-3181-4B45-843B-015E2459B253 WARNING SAA1981 Center ventilators SAA1982 The air conditioner cooling function operates only when the engine is running. . Do not leave children or adults who would normally require the support of others alone in your vehicle. Pets should not be left alone either.
(222,1) You can individually set the driver and front passenger side temperature using each temperature control button. the passenger compartment. This should help reduce odors inside the vehicle. When the “STATUS” button is pushed, the automatic climate control status screen will appear. (See “How to use STATUS button” (P.4-9).
(223,1) inside temperature, air flow distribution and fan speed after the preferred temperature is set manually. 1. Push the “AUTO” button on. (The indicator on the button will illuminate and AUTO will be displayed.) 2. Turn the temperature control dial (driver side) to set the desired temperature. . The temperature can be set within the following range. — For U.S.: 60 to 908F SAA1527 1. 2. 3. 4. 5. 6. 7.
(224,1) 4. To turn off the climate control system, push the “OFF” button. A visible mist may be seen coming from the ventilators in hot, humid conditions as the air is cooled rapidly. This does not indicate a malfunction. DehumidifiedGUID-D73A39BF-43C8-459F-9C24-47B7F579C407 defrosting or defogging: 1. Push the “ ” front defroster button. (The indicator light on the button will come on.) 2. Turn the temperature control dial to set the desired temperature. .
(225,1) manually. To turn off the heater and air conditioner, push the “OFF” button. Cooling and dehumidified heating: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 1. Push the “AUTO” button. (The AUTO indicator light will illuminate and “AUTO” will appear on the display.) 2. If the A/C indicator light does not illuminate, push the “A/C” button. (The A/C indicator light will illuminate.) SAA3568 1. 2. 3. 4. 5. 6. 7.
(226,1) . . temperature. (The DUAL indicator light will illuminate and “DUAL” will appear on the display.) To set separate desired temperatures for the driver and front passenger, push the “DUAL” button, the indicator light illuminates, and then turn the corresponding temperature control dial. To cancel the separate temperature setting, push the “DUAL” button, the indicator light turns off, and the driver’s side temperature setting will be applied to both the driver’s and front passenger’s sides.
(227,1) Ion control: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 This unit generates highly concentrated Plasmacluster® ions into the air blown from the ventilators and reduces odor absorbed into the interior trim. ment. The indicator light on the “ “ ” side will turn off. ” side and Automatic intake air control: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 In the AUTO mode, the intake air will be controlled automatically. To manually control the intake air, push the intake air control button.
(228,1) the system then automatically changes from the outside air circulation mode to the recirculation mode. When the intake air control button is pushed under the following conditions, the indicator light on the “ ” side will illuminate and the exhaust gas/outside odor detecting sensor will turn on. OPERATING GUID-7F1136F1-D18D-4E73-9301-8F9963EF4A1E TIPS When the engine coolant temperature and outside air temperature are low, the air flow from the foot outlets may not operate.
(229,1) AUDIO SYSTEM GUID-ABF87D78-8829-4773-ACF7-DAEA86432C0D conditioner. A natural grape seed polyphenol filter (if so equipped) collects and neutralizes dirt, pollen, dust, etc. AUDIO OPERATION PRECAUTIONS GUID-E7C451BC-E948-4A20-ADA7-3F0A01A2B788 SERVICING GUID-0A376F08-096E-438A-9B04-868EA390BEE5 CLIMATE CONTROL Push the ignition switch to the ACC or ON position and push the radio band select button to turn on the radio.
(230,1) from a station transmitter, the signals will tend to fade and/or drift. Static and flutter: During signal interference from buildings, large hills or due to antenna position, usually in conjunction with increased distance from the station transmitter, static or flutter can be heard. This can be reduced by lowering the treble setting to reduce the treble response.
(231,1) SAA0480 Compact Disc (CD) player GUID-BD6BD44F-C8DA-444D-AE28-82B356B99D86 . Do not force a compact disc into the CD insert slot. This could damage the CD and/or CD changer/player. . Trying to load a CD with the CD door closed could damage the CD and/or CD changer. . During cold weather or rainy days, the player may malfunction due to the humidity. If this occurs, remove the CD and dehumidify or ventilate the player completely. . The player may skip while driving on rough roads. .
(232,1) . . . . . LHA0484 DVD (Digital Versatile Disc) player (models with navigation system) GUID-4D508F5D-FA8E-49D6-A9E2-6F8E76C17033 . Do not force a compact disc into the CD/ DVD insert slot. This could damage the CD/DVD player. . During cold weather or rainy days, the player may malfunction due to humid- . ity. If this occurs, remove the CD/DVD and dehumidify or ventilate the player completely. The player may skip while driving on rough roads.
(233,1) temperature of the player returns to normal. If the error persists, consult your INFINITI retailer. Unplayable File: — The file may be copy protected. — The file is not MP3, WMA, AAC, M4A or DivX® type. Region Invalid: — The DVD is not for region 1 or all regions. Use DVDs with a region code “1”, “ALL” or “1 included” for your DVD entertainment system. A (The region code * is displayed as a small symbol printed on the top B .
(234,1) The vehicle is not equipped with a USB device. USB devices should be purchased separately as necessary. This system cannot be used to format USB devices. To format a USB device, use a personal computer. In some states/area, the USB device for the front seats plays only sound without images for regulatory reasons, even when the vehicle is parked. This system supports various USB memory devices, USB hard drives and iPod ® players. Some USB devices may not be supported by this system. .
(235,1) . AAC/M4A — Advanced Audio Coding (AAC) is a lossy audio compression format. Audio files that have been encoded with AAC are generally smaller in size and deliver a higher quality of sound than MP3. . Bit rate — Bit rate denotes the number of bits per second used by a digital music file. The size and quality of a compressed digital audio file is determined by the bit rate used when encoding the file. .
(236,1) . The playback order is the order in which the files were written by the writing software, so the files might not play in the desired order. . Music playback order of compressed audio files is as illustrated.
(237,1) Specification GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 chart: Supported media CD, CD-R, CD-RW, DVD-ROM *5, DVD±R*5, DVD±RW*5, DVD±R DL*5, USB2.0 CD, CD-R, CD-RW, DVD-ROM*5, DVD±R*5, DVD±RW*5, DVD±R DL*5: ISO9660 LEVEL1, ISO9660 LEVEL2, Romeo, Joliet * ISO9660 Level 3 (packet writing) is not supported. * Files saved using the Live File System component (on a Windows Vista-based computer) are not supported. UDF Bridge (UDF1.02+ISO9660), UDF1.5, UDF2.0 * VDF1.5/VDF2.
(238,1) *3 *4 *5 Available codes depend on what kind of media, versions and information are going to be displayed. When VBR files are played, the playback time may not be displayed correctly.
(239,1) Troubleshooting guide: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 Symptom Cause and Countermeasure Check if the disc or USB device was inserted correctly. Check if the disc is scratched or dirty. Check if there is condensation inside the player, and if there is, wait until the condensation is gone (about 1 hour) before using the player. If there is a temperature increase error, the player will play correctly after it returns to the normal temperature.
(240,1) Compressed Video Files (models with navigation system) GUID-E2445A26-4CDB-4384-A0C2-18D86B23258C mined by the bit rate used when encoding the file. Explanation of terms: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 . DivX® - DivX® refers to the DivX® codec owned by DivX, Inc. used for a lossy compression of video based on MPEG4. . AVI - AVI stands for Audio Video Interleave. It is a standard file format originated by Microsoft Corporation. A “.divx” encoded file can be saved into the “.
(241,1) Requirement for Supporting Video Playback: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 Media File Systems CD, CD-R, CD-RW, DVD, DVD±R, DVD±RW, DVD±RW DL, USB 2.0 Memory ISO9660 LEVEL1, ISO9660 LEVEL2, Romeo, Joliet, UDF Bridge (UDF1.02 CD, +ISO9660), UDF1.5, UDF2.0 CD-R, - ISO9660 Level 3 (packet writing) is not supported. CD-RW, - Files saved using the Live File System component (on a Windows VistaDVD, based computer) are not supported. DVD±R, - VDF1.5/VDF2.0 (packet writing) is not supported.
(242,1) module to prevent tone quality degradation and wireless connection disruption. . While an audio device is connected through a Bluetooth® wireless connection, the battery power of the device may discharge quicker than usual. . This system supports the Bluetooth® Audio Distribution Profile (A2DP, AVRCP). . Wireless LAN (Wi-Fi) and the Bluetooth® functions share the same frequency band (2.4 GHz).
(243,1) FM-AM-SAT RADIO WITH COMPACT DISC (CD) PLAYER GUID-0DB4181C-381F-4082-9A30-C481558366B4 No satellite radio reception is available unless a SiriusXM Satellite Radio subscription is active. The audio control buttons are also located on the center multi-function control panel. JVH0132X 1. 2. Models with navigation system AM·FM·SAT band select button DISC·AUX button SAA2922 Models without navigation system 1. AUX/Satellite radio band select button 2. RADIO AM·FM band select button 3.
(244,1) list will be automatically updated in the radio. Push the ignition switch from LOCK to ACC to update the channel list. (P.4-13). Audio mainGUID-E0255B26-FC35-4652-89E7-8756B7322814 operation . Speed Sensitive Vol. For more details, see “How to use SETTING button” (P.4-13). Head unit: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 The auto loudness circuit enhances the low and high frequency ranges automatically in both radio reception and CD playback.
(245,1) radio (SAT) band select (if so equipped): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 Push the satellite band select button to select the satellite radio mode XM1, XM2 or XM3. TUNE (Tuning): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 . For AM and FM radio Turn the radio tuning knob for manual tuning. . For SiriusXM Satellite Radio Turn the radio tuning knob to seek channels from all of the categories when any category is not selected.
(246,1) Menu (SiriusXM Satellite Radio) (models with navigation system): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 When the “Menu” key on the display is selected while the SiriusXM Satellite Radio is being played, the menu list will be displayed. The following items are available. . Preset List Displays the preset channel list. If 1 of the 6 preset stations listed is touched and held, the current station will be stored as the new preset. .
(247,1) — 1 Track Repeat — 1 Disc Random — 1 Folder Random (for CD with compressed audio files) Text (models GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 without navigation system): When the “Text” key is selected in the screen using the INFINITI controller and then the ENTER button is pushed while the CD is being played, the music information below will be displayed on the screen. CD: . Disc title . Track title CD with compressed audio files: . . . . .
(248,1) WARNING . The driver must not attempt to operate the DVD system or wear the headphones while the vehicle is in motion so that full attention may be given to vehicle operation. . Do not attempt to modify the system to display a movie on the front screen while the vehicle is being driven. Doing so may distract the driver and may cause a collision and serious personal injury or death. functionality of all VIDEO-CD formats.
(249,1) matically after a period of time. To turn it on again, push the DISC·AUX button again. DVD operation keys: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 When the DVD is playing without the operation screen being shown, you may use the touch screen to select items from the displayed video. You may also use the INFINITI controller to select an item from the displayed video. When the operation screen is being shown, use the INFINITI controller or touch screen to select an item from the displayed menus.
(250,1) Hide: Hide the operation key. Title Menu (DVD-VIDEO): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 Some menus specific to each disc will be shown. For details, see the instructions on the disc. Title Search (DVD-VIDEO, DVD-VR): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 The scene with the specified title will be displayed each time the “+” side or “−” side is selected.
(251,1) WARNING Do not connect, disconnect or operate the USB device while driving. Doing so can be a distraction. If distracted you could lose control of your vehicle and cause an accident or serious injury. CAUTION JVH1208X . USB (Universal Serial Bus) CONNECTION PORT GUID-4D3D2CD8-DF18-4970-951F-8FC1ED347AF7 Audio mainGUID-54C82475-9591-4C45-A670-94000A61ECFB operation Open the console lid and connect a USB 1 as illustrated.
(252,1) Audio file operation GUID-435F6144-8A1A-4BF6-8750-BFB28E8300D9 or PLAY: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 When the DISC·AUX or AUX button is pushed with the system off and the USB memory inserted, the system will turn on. If another audio source is playing and a USB memory is inserted, push the DISC·AUX or AUX button repeatedly until the center display changes to the USB memory mode.
(253,1) ing to the movie playback mode. . Play Mode Select the preferred play mode. Text (models GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 without navigation system): When the “Text” key is selected on the screen using the INFINITI controller and then the ENTER button is pushed while a USB memory is being played, the music information listed below will be displayed on the screen. . . . . .
(254,1) mode. Operation keys: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 To operate the USB memory, select the desired key displayed on the operation screen using the INFINITI controller. Pause ” key to pause the movie Select the “ file. To resume playing the movie file, select the “ ” key.
(255,1) . . SAA2504 . Example Settings: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 Select the “Settings” key to adjust the following settings. . Audio File Playback Switch to the audio playback mode. This item is displayed only when the USB memory contains the audio files. . Play Mode Select the “Normal” or “1 Track Repeat” play mode. . 10 Key Search Select the “10 Key Search” key to open the number entry screen. . . Input the number to be searched and select the “OK” key.
(256,1) nication and cause undesired noise. It is recommended that you turn off the wireless LAN (Wi-Fi) when using the Bluetooth® functions. Regulatory GUID-B047BAF2-A970-4950-9F6B-340AF867E66E information FCC Regulatory information: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 . CAUTION: To maintain compliance with FCC’s RF exposure guidelines, use only the supplied antenna. Unauthorized antenna, modification, or attachments could damage the transmitter and may violate FCC regulations. .
(257,1) SAA2506 2. Select the “Connect Bluetooth” key. SAA2507 3. A confirmation screen will be displayed. Select “No”. Note: Selecting “Yes” will only connect the hands free phone portion of a Bluetooth® device. SAA3005 4. Choose a PIN code to use with the compatible Bluetooth® audio device using the number input screen. The PIN code will need to be entered into the Bluetooth® audio device after step 5. Select the “OK” key.
(258,1) DISC·AUX button: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 When the DISC·AUX button is pushed with the system off and the Bluetooth® audio device connected, the system will turn on. If another audio source is playing and the Bluetooth® audio device is connected, push the DISC·AUX button repeatedly until the display changes to the Bluetooth® audio mode. SAA3006 5. The standby message screen will appear. Operate the compatible Bluetooth® audio device.
(259,1) When the REW button is pushed for less than 1.5 seconds after 3 seconds from when the current track started playing, the beginning of the current track will be played. Pause Select the “ ” key to pause the Bluetooth® audio device. Select this key again to resume playing. The INFINITI controller can also be used to select tracks when the Bluetooth® audio play mode screen is shown on the display. (“Bluetooth audio” will be indicated on the header of the screen.
(260,1) Connected Devices: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 Registered devices are shown on the list. Select a Bluetooth® device from the list, the following options will be available. see “Bluetooth® Hands-Free Phone System (models with navigation system)” (P.4-99). . Select Select “Select” to connect the selected device to the vehicle. If there is a different device currently connected, the selected device will replace the current device. .
(261,1) * iPod® is a trademark of Apple Inc., registered in the U.S. and other countries. WARNING Do not connect, disconnect or operate the USB device while driving. Doing so can be a distraction. If distracted you could lose control of your vehicle and cause an accident or serious injury. CAUTION . . . Do not force the USB device into the USB port. Inserting the USB device tilted or up-side-down into the port may damage the port. Make sure that the USB device is connected correctly into the USB port.
(262,1) or PLAY: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 When the DISC·AUX or AUX button is pushed with the system off and the iPod® connected, the system will turn on. If another audio source is playing and the iPod® is connected, push the DISC·AUX or AUX button repeatedly until the center display changes to the iPod® mode. Interface: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 The interface for iPod® operation shown on the vehicle center display is similar to the iPod® interface.
(263,1) trial use. . A new disc may be rough on the inner and outer edges. Remove the rough edges by rubbing the inner and outer edges with the side of a pen or pencil as illustrated. USB memory GUID-75DB6F6B-D249-4682-9973-CE51C11FA858 SAA0451 CD/DVD/USB MEMORY CARE AND CLEANING GUID-8EE92BA6-29D1-4D00-A1CD-06AA6F4B3729 CD/DVD GUID-AE827974-76A8-4315-B7EB-8B210DB6923A . Handle a CD/DVD by its edges. Never touch the surface of the disc. Do not bend the disc. .
(264,1) 1. 2. 3. 4. Audio source switch Menu control switch (models with navigation system) or audio tuning switch (models without navigation system) Volume control switch Back switch STEERING-WHEEL-MOUNTED CONTROLS FORGUID-1F1450BB-2D2C-4477-A859-B65C752945DA AUDIO Menu control switch (models with navigation system) or audio tuning switch (models without navigation system) GUID-198F7519-A1E2-4B29-974B-F1E9FBDCB0C3 next station. . Pushing the menu control switch will show the list of preset stations.
(265,1) Bluetooth® Audio (models with navigation system): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 . Tilting up/down for less than 1.5 seconds will scroll up or down through the track number. ANTENNA The antenna pattern is printed inside the rear window. BACK GUID-53FBAD19-30D7-4BB5-97D9-86904D9A8CE5 switch (if so equipped) Push this switch to go back to the previous screen or cancel the selection if it is not completed. CAUTION .
(266,1) CAR PHONE OR CB RADIO GUID-401A908F-1B98-4BBA-86C8-B829C89D2BEE — The vehicle enters an automatic car wash. — The vehicle enters a garage with a low ceiling. — The vehicle is covered with a car cover. . Always properly tighten the antenna rod during installation. Otherwise, the antenna rod may break during vehicle operation.
(267,1) Bluetooth® HANDS-FREE PHONE SYSTEM (models with navigation system) GUID-AC70EB75-705F-4108-A5C4-01E69DCA937E WARNING . Use a phone after stopping your vehicle in a safe location. If you have to use a phone while driving, exercise extreme caution at all times so full attention may be given to vehicle operation. . If you find yourself unable to devote full attention to vehicle operation while talking on the phone, pull off the road to a safe location and stop your vehicle before doing so.
(268,1) . Do not place the cellular phone in an area surrounded by metal or far away from the in-vehicle phone module to prevent tone quality degradation and wireless connection disruption. . While a cellular phone is connected through the Bluetooth® wireless connection, the battery power of the cellular phone may discharge quicker than usual. . If the Bluetooth® Hands-Free Phone System seems to be malfunctioning, please visit www.InfinitiUSA.com/bluetooth for troubleshooting help. .
(269,1) SAA2219 1) 2) TALK button PHONE SEND button CONTROL BUTTONS GUID-438D5F45-E486-45D2-9801-DCF9AA79B27B JVH0473X CONNECTING PROCEDURE GUID-D1888070-CBE2-48DB-821D-3E4934992692 1. Push the button, and select the “Connect Phone” key. SAA2520 2. When a PIN code appears on the screen, operate the compatible Bluetooth® cellular phone to enter the PIN code. If you have the phone corresponding to Bluetooth® Secure Simple Pairing, select MY-CAR on the cellular phone device searching screen. .
(270,1) lar phone varies according to each cellular phone. See the cellular phone Owner’s Manual for the details. You can also visit www.InfinitiUSA.com/bluetooth or call INFINITI Consumer Affairs Department for instructions on pairing INFINITI recommended cellular phones. When the connection process is completed, the screen will return to the Phone menu display.
(271,1) options instead of “Enter Number by Keypad” in step 3. JVH0475X JVH0476X 3. Choose the method for entering the Quick Dial entry. For this example, select “Enter Number by Keypad”. 5. Select the “Voicetag” key to record a name to speak when using the INFINITI Voice Recognition system. 4. Enter the digits and select the “OK” key. (See “How to use touch screen (models with navigation system)” (P.45).) 6. Select the “Store” key and prepare to speak the name after the tone. .
(272,1) tags allow easy dialing using the INFINITI Voice Recognition system. (See “INFINITI Voice Recognition system (models with navigation system)” (P.4124).) To delete an entry, select the “Delete” key at step 3. JVH0477X Editing theGUID-D29BB946-9A25-489B-930D-95D0AE600133 Quick Dial 1. Push the button and select the “Quick Dial” key. 2. Select the desired entry from the displayed list. 3. Select the “Edit” key. 4. Select the desired item to change.
(273,1) system)” (P.4-124).) JVH0479X MAKING A CALL GUID-D3E00526-410A-4E9F-AB53-B9100533FB33 To make a call, follow this procedure. button on the steering 1. Push the wheel. The “PHONE” screen will appear on the display. 2. Select the “Phonebook” key on the “PHONE” menu. 3. Select the desired entry from the list. 4. Confirm the correct entry by selecting for the correct number from the list. JVH0495X There are different methods to make a call.
(274,1) . Hold Call Put an incoming call on hold. . Reject Call Reject an incoming call. To finish the call, perform one of the following procedures listed below. 1. Select the “Hang up” key. 2. Push the wheel. button on the steering SAA2525 SAA3587 RECEIVING A CALL GUID-6F43A1A1-EE11-4E04-8279-8274439D20B9 DURING A CALL GUID-C90FAF40-A6F9-4C1C-9015-FD63D3B860F0 When you hear a phone ring, the display will change to the incoming call mode.
(275,1) . Cancel Mute This will appear after “Mute” is selected. Mute will be canceled. . Switch Call* Select “Switch Call” to answer another incoming call. By selecting “Hang up”, you can end a call and can speak to a caller who is on hold again. * This function may not be usable, depending on the model of phone.
(276,1) Auto Downloaded GUID-6BE175E2-470A-49F6-829E-A01260966EB1 When this item is activated, the phonebook of a hands-free phone is automatically downloaded at the same time that the hands-free phone is connected.
(277,1) TROUBLESHOOTING GUIDE GUID-8D414043-EC6F-40FA-AE71-118BDCAEF252 The system should respond correctly to all voice commands without difficulty. If problems are encountered, try the following solutions. Where the solutions are listed by number, try each solution in turn, starting with number 1, until the problem is resolved. Symptom Solution 1. Ensure that the command is valid. (See “INFINITI Voice Recognition system (models with navigation system)” (P.4-124).) 2.
(278,1) Bluetooth® HANDS-FREE PHONE SYSTEM (models without navigation system) GUID-E8B794AB-1D34-4031-873C-C179EAC9E932 WARNING . Use a phone after stopping your vehicle in a safe location. If you have to use a phone while driving, exercise extreme caution at all times so full attention may be given to vehicle operation. . If you find yourself unable to devote full attention to vehicle operation while talking on the phone, pull off the road to a safe location and stop your vehicle before doing so.
(279,1) . Immediately after the ignition switch is pushed to the ON position, it may be impossible to receive a call for a short period of time. . Do not place the cellular phone in an area surrounded by metal or far away from the in-vehicle phone module to prevent tone quality degradation and wireless connection disruption. . While a cellular phone is connected through the Bluetooth® wireless connection, the battery power of the cellular phone may discharge quicker than usual. .
(280,1) VOICE RECOGNITION SYSTEM GUID-5F71B0CA-D9EA-4D2D-857A-80C28F02800C Bluetooth trademark: You can also use the Bluetooth® handsfree phone system with Voice Recognition System. Bluetooth® is a trademark owned by Bluetooth SIG, Inc., and licensed to Visteon Corporation. INFO SAA2642 CONTROL BUTTONS GUID-63652779-89CA-4B8E-9C76-4E7CBD5CCC5D 1. 2. 4-112 Condition: PHONE SEND button Push the button to initiate a Voice Recognition (VR) session or answer an incoming call.
(281,1) . Keep the interior of the vehicle as quiet as possible. Close the windows to eliminate the surrounding noises (traffic noises, vibration sounds, etc.), which may prevent the system from recognizing the voice commands correctly. . Wait until a tone sounds before speaking a command. . Speak a voice command within 5 seconds after the beep sound. If no voice command is given, the system will ask you for a number. If no further command is given, the session ends. .
(282,1) command recognition mode . 4. The system acknowledges the command and announces the next set of available commands. 5. After the tone sounds, speak the phone number. 6. When you have finished speaking the phone number, the system repeats it back and announces the available commands. 7. After system responds, speak “Dial” and the system dials the spoken numbers. Operating tips: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 . Voice commands cannot be accepted when the icon is . .
(283,1) cent Calls, Connect Phone or Help”. 3. Give your instructions to the system by saying: “Dial John” for example (“John” must have been previously set as a voice tag for John’s phone number) or “Dial One” if John is classified as one in the phonebook. and then perform the first procedure of voice command. If the system cannot understand your command, repeat it according to the recommendations mentioned in “Using system” (P.4-112). 4.
(284,1) List of voice commands: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 COMMAND ACTION “Call/Dial” “” Dials the specified . “Call/Dial” “Redial” Dials the last number. “Call” “” Dials the specified . “Phonebook” “” Displays the specified in the phonebook. “Phonebook” “List Names” Displays all the names in the phonebook. “Phonebook” “Transfer Entry” Transfers the phonebook data to the system.
(285,1) SAA2575 PAIRING PROCEDURE GUID-505E2AB8-A505-45F5-ADCE-027E4A52E197 Up to 5 cellular phones can be registered. button on the steering 1. Push the wheel. The system announces the available commands. 2. Speak: “Connect Phone”. The system acknowledges the command and announces the next set of available commands. SAA2576 3. Speak: “Add Phone”. The system acknowledges the command and asks you to initiate connecting from the phone handset.
(286,1) book. SAA2578 5. The system asks the user to speak a name for the phone. Speak: “Yes”. The system acknowledges the command and registers the cellular phone. If the name is too long or too short, the system tells the user, then prompts the user for a name again. Also, if more than one phone is connected and the name sounds too much like a name already used, the system tells the user, then prompts the user for name again.
(287,1) call. 5. Once the call has ended, press the button on the steering wheel. RECEIVING GUID-43C21EB8-312B-4748-B3E5-5FA3BA571EBB A CALL When the ring tone is heard, press the button on the steering wheel. Once the call has ended, press the button on the steering wheel. NOTE: SAA2580 If you do not wish to take the call when you hear the ringtone, press the button on the steering wheel to reject the call.
(288,1) call. . “Mute on/off” — Use the Mute command to mute the user’s voice so the other party cannot hear it. Use the mute command again to unmute the user’s voice. . “Transfer Handset” — Use the Transfer Handset command to transfer the call from the Bluetooth® Hands-Free Phone System to a cellular phone when privacy is desired. The system announces, “Transfer Handset. The call is transferred to the handset only.” The system then ends the VR session.
(289,1) SAA2583 PhonebookGUID-0AF353C7-38B5-4F94-B147-D88EC0170C69 . (a name) Use the name command to seek the name and locations registered in the phonebook in alphabetical order. When the system acknowledges the alphabet the user spoke, the system announces all registered names and locations beginning with that alphabet. Playback of the list can be stopped at any time by pressing a button on the steering wheel. The system ends the VR session. .
(290,1) . Callback Use the Callback command to dial the last incoming call. . Help The system announces the available commands. SAA2584 SAA2585 Recent CallsGUID-505A1727-5086-48F5-8514-99C72377AE94 Connect Phone GUID-FBD19F46-9065-404A-B841-91E1AA085596 . Incoming Use the Incoming command to make a call viewing the list of incoming calls. . Missed Use the Missed command to make a call viewing the list of missed calls. .
(291,1) existing phone. If the user tries to connect a phone that has already been connected to the vehicle system, the system announces the name that the phone is already using. The connecting procedure will then be cancelled. The Add Phone command is not available when the vehicle is moving. . Select Phone Use the Select Phone command to select a phone of lesser priority when two or more phones connected with Bluetooth® Hands-Free Phone System are in the vehicle at the same time.
(292,1) INFINITI VOICE RECOGNITION SYSTEM (models with navigation system) GUID-0BDB2017-A08A-4CB1-A128-9719487DE6B5 2. Sit in the driver’s seat with the engine running, the parking brake on, and the transmission in Park. 3. Press the button. 4. Speak: “Help”. The system acknowledges the command and announces the next set of available commands. 5. Speak: "Voice Adaptation". The system acknowledges the command and displays the voice adaptation mode screen. ter your name. 11.
(293,1) when Alternate Command Mode is active, try using the Speaker Adaptation Function available in that mode. Otherwise, it is recommended that Alternate Command Mode be turned off and Standard Mode be used for the best recognition performance. For the voice commands for the navigation system, refer to the Navigation System Owner’s Manual of your vehicle.
(294,1) SAA2531 1. Push the INFO button on the instrument panel. 2. Select the “Others” key. 3. Select the “Voice Recognition” key. 4. Select the “User Guide” key. 5. Select a preferred item. . Let’s Practice Mode that allows practicing by following the instructions of the system voice. . Using the Address Book Tutorial for entering a destination by using the Address Book. . Finding a Street Address (if so equipped) Tutorial for entering a destination by street address. .
(295,1) Voice Recognition. SAA2534 SAA2533 Let’s Practice GUID-CEB24665-1937-41AD-8E91-E94C0E5C3181 Useful tips GUID-C9E09F86-96F6-4B3F-AA7F-ECCEF1C7D699 for correct operation This mode helps learn how to use the INFINITI Voice Recognition system. You can display useful speaking tips to help the system recognize your voice commands correctly. 1. Select the “Let’s Practice” key. 2. After the message screen appears, push the TALK switch on the steering wheel.
(296,1) USING THEGUID-5C6975DD-FEFF-4469-A81D-6B1128DD1C3E SYSTEM Initialization GUID-84EB02E8-7C3C-43A1-BC47-E7E511BA17A5 When the ignition switch is pushed to the ON position, INFINITI Voice Recognition is initialized, which may take up to one minute. When completed, the system is ready to accept voice commands. If the TALK switch is pushed before the initialization completes, the display will show the message: “System not ready.” or a beep sounds. .
(297,1) completed. Selecting the “Help” key can display the detailed information of the each command. Operating tips: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 . Say a command after the tone. . Commands that are available are always shown on the display and spoken through voice menu prompts. Commands other than those that are displayed are not accepted. Please follow the prompts given by the system. . If the command is not recognized, the system announces, “Please say again”.
(298,1) Command GUID-3DE47269-AFF5-4CA3-8B76-5D0AAEBC112C List Category Command: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 Command Action Call (Optional) Makes a call to a contact that is stored in either phonebook. Please say "Call" followed by a stored name. Phone Operates the Phone function Navigation Operates the Navigation function Information Displays the vehicle Information function Audio Operates the Audio function. Displays User Guide Help .
(299,1) Command Action Address Book Searches for stored information in the Address Book. Sets a route to a previous destination. Previous Destinations . Information Command: Command Action Fuel Economy Displays fuel economy information. Maintenance Displays maintenance information. Traffic Information Where am I? Displays the [Info On Route] screen when a route to the destination is set. Displays the [Nearby Traffic Info.] screen when a route to the destination is not set.
(300,1) Voice command examples GUID-EE13DCC8-0C1B-4B52-BC3B-BC0301FD3E8D To use the INFINITI Voice Recognition function, speaking one command is sometimes sufficient, but at other times it is necessary to speak two or more commands. As examples, some additional basic operations by voice commands are described here. For navigation system commands, see the separate Navigation System Owner’s Manual.
(301,1) SAA2537 4. Speak “8 0 0”. Selecting the “Manual Controls” key switches the screen to the keypad to input the phone number manually. SAA2538 5. The system announces, “Please say the next three digits or dial, or say change number.” SAA2539 7. The system announces, “Please say the last four digits” or say change number. 8. Speak “6 2 0 0”. 6. Speak “6 6 2”.
(302,1) SAA2540 9. The system announces, “Dial or Change Number?” 10. Speak “Dial”. 11. The system makes a call to 800-6626200. . You can only say a phone number using the 3-3-4 grouping, 7 digits, and 10 digits using this command. Please use the “International Call” command for all other formats. . If you say “Change Number” during phone number entry, the system will automatically request that you repeat the number using the 3-3-4 format.
(303,1) JVH0481X 3. Speak “International Call”. SAA2541 4. Speak “011811112223333”. SAA2542 5. Speak “Dial”. 6. System makes a call to 011-81-111222-3333. NOTE: Any digit input format is available in the International Number input process.
(304,1) INFINITI VOICE RECOGNITION ALTERNATE COMMAND MODE GUID-D2C0E233-A584-4E53-8320-7CBFF245904C Activating Alternate Command Mode GUID-9775577A-205B-41F8-BBC3-DDD40B78C94A The following section is applicable when Alternate Command Mode is activated. When the Standard Mode is active, perform the following steps to switch to the Alternate Command Mode. When Alternate Command Mode is activated, an expanded list of commands can be used after pressing the TALK switch.
(305,1) SAA2544 1. Push the INFO button on the instrument panel. 2. Select the “Others” key. 3. Select the “Voice Recognition” key. 4. Select the “Command List” key. SAA2545 5. Select a category from the list. JVH0483X 6. Select an item. 7. If necessary, scroll the screen using the INFINITI controller to view the entire list. 8. Press the BACK button to return to the previous screen.
(306,1) Command List GUID-4E59F906-B7C4-464E-A1C7-F3380543C508 Phone Commands: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 Command Action Dial Number Makes a call to a spoken phone number. Quick Dial Makes a call to a contact that is stored in the Quick Dial. Phonebook Call History Makes a call to a contact that is stored in the mobile phone. Incoming Calls Makes a call to the incoming call number. Outgoing Calls Makes a call to the dialed number.
(307,1) Navigation Commands: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 Command Action Destination Home Sets a route to your home that is stored in the Address Book. Address Searches for a location by the street address specified, and sets a route to the location. Places Sets a route to a facility near the current vehicle location. Address Book Searches for stored information in the Address Book. Previous Destinations Sets a route to a previous destination.
(308,1) Information Commands: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 Command Action Fuel Economy Displays fuel economy information. Maintenance Displays maintenance information. Where am I? Displays your current location. Traffic Information Displays the [Info On Route] screen when a route to the destination is set. Displays the [Nearby Traffic Info.] screen when a route to the destination is not set. Weather Information Weather Map 4-140 Condition: Displays weather information.
(309,1) Audio Commands: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 Command Action CD Starts to play a CD. FM Turns to the FM band, selecting the station last played. AM Turns to the AM band, selecting the station last played. XM Turns to the SiriusXM Satellite Radio band, selecting the channel last played. USB Turns on the USB memory. Turns on the Bluetooth® audio player.
(310,1) Help Commands: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 Command Command List Phone Commands Displays the phone command list. Audio Commands Displays the audio command list. Information Commands Displays the information command list. Help Commands User Guide Speaker Adaptation 4-142 Condition: Action Navigation Commands Displays the navigation command list. Displays the help command list. Displays the User Guide. The system can memorize the voices of up to three persons.
(311,1) General Commands: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 Command Go back Exit Action Corrects the last recognition result to return to the previous screen Cancels Voice Recognition Monitor, climate, audio, phone and voice recognition systems Condition: [ Edit: 2015/ 6/ 12 Model: J50-D ] 4-143
(312,1) 4. Highlight the “User Guide” key using the INFINITI controller and push the ENTER button. 5. Highlight an item using the INFINITI controller and push the ENTER button. SAA2547 Displaying user guide GUID-AD6524E6-709F-4D5F-97EE-08BC44964377 You can confirm how to use voice commands by accessing a simplified User Guide, which contains basic instructions and tutorials for several voice commands. 1. Push the INFO button on the instrument panel. 2.
(313,1) . When the air conditioner is in the AUTO mode, the fan speed decreases automatically for easy recognition. . Wait until a tone sounds before speaking a command. . Speak in a natural voice without pausing between words. steering wheel. . If the command is not recognized, the system announces, “Please say again”. Repeat the command in a clear voice. . Push the BACK button once to return to the previous screen. . If you want to cancel the command, push and hold the TALK switch for 1 second.
(314,1) Phone numbers Speak phone numbers according to the following examples: . 1-800-662-6200 — “Dial one eight zero zero six six two six two zero zero.” Note 1: For the best voice recognition phone dialing results, say phone numbers as single digits. the digits that have been recognized will be read out. . If you press the ENTER button on the steering wheel or on the INFINITI controller, the selected digits will be sent. Note 2: You cannot say 555-6000 as “five five five six thousands”.
(315,1) SAA2550 4. Select the user whose voice is memorized by the system. 5. Select the “Start Speaker Adaptation Learning” key. SAA2551 SAA2552 6. Select a category to be learned by the system from the following list. . Phone Commands . Navigation Commands . Information Commands . Audio Commands . Help Commands The voice commands in the category are displayed. 8. The system requests that you repeat a command after a tone. 7. Select a voice command and then push the ENTER button.
(316,1) Minimize voice feedback (for Alternate Command Mode) GUID-5C39B88D-DE77-4190-B9CF-92B436BE565B “None” to “Stored”. To minimize the voice feedback from the system, perform the following steps. 1. Push the SETTING button on the instrument panel. 2. Select the “Others” key. 3. Select the “Voice Recognition” key. 4. Select the “Minimize Voice Feedback” key. SAA2553 Speaker Adaptation function settings: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 Edit User Name 5.
(317,1) TROUBLESHOOTING GUIDE GUID-EDF04FF9-20BA-44F0-8A2B-4FC70A2F5096 The system should respond correctly to all voice commands without difficulty. If problems are encountered, follow the solutions given in this guide for the appropriate error. Where the solutions are listed by number, try each solution in turn, starting with number one, until the problem is resolved. Symptom/error message The system fails to interpret the command correctly. Solution 1.
(318,1) MEMO 4-150 Condition: Monitor, climate, audio, phone and voice recognition systems [ Edit: 2015/ 6/ 12 Model: J50-D ]
(319,1) 5 Starting and driving Precautions when starting and driving ................. ... 5-4 Exhaust gas (carbon monoxide) ....................... ... 5-4 Three-way catalyst .......................................... ... 5-4 Tire Pressure Monitoring System (TPMS) ......... ... 5-5 Avoiding collision and rollover ........................ ... 5-7 On-pavement and off-road driving precautions ......................................... ... 5-8 Off-road recovery ............................................ ...
(320,1) Intelligent Cruise Control (ICC) system (FULL SPEED RANGE) (if so equipped) ................ ... How to select the cruise control mode........... ... Vehicle-to-vehicle distance control mode ....... ... Conventional (fixed speed) cruise control mode................................................. ... Preview function (for Intelligent Cruise Control system equipped models) ................. ... Distance Control Assist (DCA) system (if so equipped) ...................................................
(321,1) Driving on snow or ice ................................ ... 5-104 Engine block heater (if so equipped) ........... ...
(322,1) PRECAUTIONS WHEN STARTING AND DRIVING GUID-EBA1CF7C-59DD-4B69-93FF-F13B511CFD44 WARNING . . Do not leave children or adults who would normally require the support of others alone in your vehicle. Pets should not be left alone either. They could accidentally injure themselves or others through inadvertent operation of the vehicle. Also, on hot, sunny days, temperatures in a closed vehicle could quickly become high enough to cause severe or possibly fatal injuries to people or animals. death.
(323,1) TIRE PRESSURE MONITORING SYSTEM (TPMS)GUID-68E51C46-B72B-4976-850C-3C364D669985 cause a fire. CAUTION . Do not use leaded gasoline. Deposits from leaded gasoline seriously reduce the three-way catalyst’s ability to help reduce exhaust pollutants. . Keep your engine tuned up. Malfunctions in the ignition, fuel injection, or electrical systems can cause overrich fuel flow into the three-way catalyst, causing it to overheat.
(324,1) Additional information GUID-EB545C2D-FE9B-4A5F-B78A-AF95258155FA . Since the spare tire is not equipped with the TPMS, the TPMS does not monitor the tire pressure of the spare tire. . The TPMS will activate only when the vehicle is driven at speeds above 16 MPH (25 km/h). Also, this system may not detect a sudden drop in tire pressure (for example a flat tire while driving). . The low tire pressure warning light does not automatically turn off when the tire pressure is adjusted.
(325,1) ing light will flash for approximately 1 minute. The light will remain on after 1 minute. Contact your INFINITI retailer as soon as possible for tire replacement and/or system resetting. . Replacing tires with those not originally specified by INFINITI could affect the proper operation of the TPMS. . Do not inject any tire liquid or aerosol tire sealant into the tires, as this may cause a malfunction of the tire pressure sensors. CAUTION .
(326,1) vehicle, a loss of control could result in a collision with other vehicles or objects, or cause the vehicle to rollover, particularly if the loss of control causes the vehicle to slide sideways. Be attentive at all times, and avoid driving when tired. Never drive when under the influence of alcohol or drugs (including prescription or over-thecounter drugs which may cause drowsiness). Always wear your seat belt as outlined in the “Seat belts” (P.1-12), and also instruct your passengers to do so.
(327,1) RAPID AIR GUID-FAB045C9-866E-493D-B21B-BC98003ABEC1 PRESSURE LOSS Rapid air pressure loss or a “blow-out” can occur if the tire is punctured or is damaged due to hitting a curb or pothole. Rapid air pressure loss can also be caused by driving on under-inflated tires. Rapid air pressure loss can affect the handling and stability of the vehicle, especially at highway speeds.
(328,1) PUSH-BUTTON IGNITION SWITCH GUID-C86B284B-F3F3-47C2-93C6-0AB824C0BC4E Don’t drive if your ability to operate your vehicle is impaired by alcohol, drugs, or some other physical condition. ALL-WHEEL DRIVE (AWD) DRIVING SAFETY PRECAUTIONS (for AWD models) GUID-25A67C86-AA78-45D6-8FD5-9236974638FE any D (Drive) or R (Reverse) position with the engine running. Doing so may result in drivetrain damage or unexpected vehicle movement which could result in serious vehicle damage or personal injury. .
(329,1) someone who does not carry the Intelligent Key, to push the ignition switch to start the engine. SSD0436 OPERATING RANGE FOR ENGINE START FUNCTION GUID-439DD11C-0380-4D8D-BD6D-92F39F8462AB The Intelligent Key can only be used for starting the engine when the Intelligent Key is within the specified operating range 1 .
(330,1) to LOCK until the shift lever is moved to the P (Park) position. When the ignition switch cannot be switched toward the LOCK position, proceed as follows: 1. Move the shift lever into the P (Park) position. 2. Push the ignition switch to the OFF position. The ignition switch position indicator will not illuminate. 3. Open the door. The ignition switch will change to the LOCK position.
(331,1) BEFORE STARTING THE ENGINE GUID-4508F0EE-4A42-483C-B149-FD42797AB45B To remove the Intelligent Key from the port, push the ignition switch to the OFF position and pull the Intelligent Key out of the port. NOTE: The Intelligent Key port does not charge the Intelligent Key battery. If you see the low battery indicator in the vehicle information display, replace the battery as soon as possible. (See “Intelligent Key battery replacement” (P.8-23).
(332,1) STARTING THE ENGINE GUID-0AE7B80B-3691-46EB-81C6-6EA51A317529 1. Apply the parking brake. 2. Move the shift lever to the P (Park) or N (Neutral) position. (P is recommended.) The starter is designed not to operate unless the shift lever is in either of the above positions. 3. Push the ignition switch to the ON position. Depress the brake pedal and push the ignition switch to start the engine.
(333,1) DRIVING THE VEHICLE GUID-71F46DAD-4823-4809-8DBF-DEAC5C4FAF92 AUTOMATIC GUID-96F58384-9762-4456-83B9-8383EAF1114F TRANSMISSION 7 speed automatic transmission GUID-767705CB-AB0C-432E-B16D-AE6DA46FF2C4 The automatic transmission in your vehicle is electronically controlled by a transmission control module to produce maximum efficiency and smooth operation. Shown on the following pages are the recommended operating procedures for this transmission.
(334,1) WARNING Apply the parking brake if the shift lever is in any position while the engine is not running. Failure to do so could cause the vehicle to move unexpectedly or roll away and result in serious personal injury or property damage. SSD0712 Shift lever To move the shift lever, : : : Push the button while depressing the brake pedal, Push the button, Just move the shift lever.
(335,1) DS (Drive Sport) mode GUID-E4BFE274-2035-4524-B4DA-26B94CA9FCE5 Move the shift lever from D (Drive) to the left into the manual shift gate. The transmission position indicator in the meter shows “DS”. In the DS (Drive Sport) mode, the transmission changes to the “sporty” driving shift operation, creating a more aggressive acceleration feeling than the D (Drive) mode and providing a gear change sensation when the driver accelerates quickly.
(336,1) range. 4. Push down the shift lock illustrated. Accelerator downshift — In D (Drive) position — GUID-93807100-1D43-49C5-8CFC-4D536E807C39 Push the ignition switch to the ON position. Now the vehicle may be moved to the desired location. GUID-C50D28FF-08A5-4AC3-97EE-F21FD367AC96 When the fail-safe operation occurs, note that the transmission will be locked in any of the forward gears according to the condition.
(337,1) PARKING BRAKE GUID-5A3847FC-E9B5-4396-AB95-CD0C8AD1757D Control on downhill roads: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 The adaptive shift control system shifts to a low gear that suits the degree of the slope, and uses the engine braking to reduce the number of times that the brake must be used.
(338,1) LANE DEPARTURE WARNING (LDW)/LANE DEPARTURE PREVENTION (LDP) SYSTEMS (if so equipped) GUID-468CFE5F-DB32-4212-9F4A-E439631FCEC8 WARNING Failure to follow the warnings and instructions for proper use of the LDW and LDP systems could result in serious personal injury or death. . The LDW and LDP systems will not steer the vehicle or prevent loss of control.
(339,1) JVS0635X A The LDW and LDP systems use a camera * installed behind the windshield to monitor the lane markers of your traveling lane.
(340,1) LDW SYSTEM OPERATION GUID-D4624CFA-B7DC-4FE1-85ED-50D6D8D5BDEE The LDW system operates above approximately 45 MPH (70 km/h) and the lane markings are clear. If the vehicle approaches either the left or right side of the traveling lane, the LDW indicator light (orange) on the instrument panel will flash and a warning chime will sound. NOTE: The LDW system is not designed to warn when you operate the lane change signal and change traveling lanes in the direction of the signal.
(341,1) TURNING THE LDW SYSTEM ON/OFF GUID-2757BCF3-A806-4E14-BB9F-3EC82C3365F8 LDP SYSTEM OPERATION GUID-3D7CC8EC-FEAA-46B8-8375-3CFD19F544D6 The LDW system is automatically turned on when the engine is started and the warning 3 illuminates systems ON indicator light * on the switch. You can turn the LDW system off by pushing the warning systems switch 2 on the instrument panel. This switch * will turn on and off the LDW, BSW and FCW systems at the same time.
(342,1) TURNING THE LDP SYSTEM ON/OFF GUID-6C152E97-BC77-4316-91B8-7D15D85583EE To turn on the LDP system, push the 3 on dynamic driver assistance switch * the steering wheel after starting the engine. The LDP ON indicator light (green) 1 on the instrument panel will illuminate. * Push the dynamic driver assistance switch 3 again to turn off the LDP system. The * 1 will turn off. LDP ON indicator light * 3 is The dynamic driver assistance switch * used for both the LDP and DCA systems.
(343,1) HOW TO ENABLE/DISABLE THE LDP SYSTEM GUID-45E88008-AD93-4698-A49D-638FBDA77AC9 LDW/LDP GUID-CED30F5D-E2CD-4017-A5F7-1BBE9CCCCAC6 SYSTEM LIMITATIONS WARNING Perform the following steps to enable or disable the LDP system. 1 button and high1. Push the SETTING * light the “Driver Assistance” key on the display using the INFINITI controller. (See “How to use INFINITI controller” 2 (P.4-5).) Then push the ENTER * button. SSD0884 2.
(344,1) — When there is a lane closure due to road repairs. — On roads where there are sharp curves. — When driving in a makeshift or temporary lane. — On roads where there are sharply contrasting objects, such as shadows, snow, water, wheel ruts, seams or lines remaining after road repairs. (The LDW and LDP systems could detect these items as lane markers.) — When driving on roads where the lane width is too narrow.
(345,1) SYSTEM TEMPORARILY UNAVAILABLE GUID-5FBCEB88-38A5-4BBA-8F16-D2282607A4CD Condition A: Under the following conditions, a beep will sound and the LDP system will be canceled automatically. The LDP ON indicator light 1 will blink in green, and the LDP system * cannot be activated: . When the VDC system (except TCS function) or ABS operates. . When the VDC system is turned off. . When the SNOW mode switch is turned on. Action to take: When the above conditions no longer exist, turn off the LDP system.
(346,1) LDP system: If the vehicle is parked in direct sunlight under high temperature conditions (over approximately 1048F (408C)) and then the LDP system is turned on, the LDP system will be turned off automatically, a beep will sound and the 1 LDP ON indicator light * will blink in green. Action to take: Stop the vehicle in a safe location, place the vehicle in the P (Park) position, turn the engine off and restart the engine.
(347,1) BLIND SPOT WARNING (BSW) SYSTEM (if so equipped) GUID-633A2A06-B4BF-4D8B-8999-4075CB243B99 era unit’s capability of detecting the lane markers. . Do not strike or damage the areas around the camera unit. Do not touch the camera lens or remove the screw located on the camera unit. If the camera unit is damaged due to an accident, contact an INFINITI retailer. WARNING .
(348,1) SSD1030 Detection zone The radar sensors can detect vehicles on either side of your vehicle within the detection zone shown as illustrated. This detection zone starts from the outside mirror of your vehicle and extends approximately 10 ft (3.0 m) behind the rear bumper, and approximately 10 ft (3.0 m) sideways.
(349,1) BSW SYSTEM OPERATION GUID-D26FC703-F4D3-488B-B916-CEA9BB2ECCDB The BSW system operates above approximately 20 MPH (32 km/h). Illustration 1: If the radar sensors detect a vehicle in the detection zone, the side 1 illuminates. indicator light * SSD1026 Illustration 1 Illustration 2: If the turn signal is then activated, the system chimes (twice) and the side indicator light flashes. The side indicator light continues to flash until the detected vehicles leaves the detection zone. NOTE: .
(350,1) NOTE: If you continue to push the warning systems switch from off to on for over 4 seconds, a chime will sound. This will change the default status of the LDW, BSW and FCW systems to OFF so that these systems will not automatically turn on when the engine is started. If this procedure is repeated, the default states will return to ON. BSW SYSTEM LIMITATIONS GUID-21377D06-B3B4-4D7F-B4FD-38C150393CC3 WARNING Listed below are the system limitations for the BSW system.
(351,1) — Oncoming vehicles. — Severe weather — A vehicle merging into an adjacent lane at a speed approximately the same as your vehicle. — Road spray — Ice build-up on the vehicle — Frost build-up on the vehicle — A vehicle approaching rapidly from behind. — A vehicle which your vehicle overtakes rapidly. — Dirt build-up on the vehicle . Do not attach stickers (including transparent material), install accessories or apply additional paint near the radar sensors.
(352,1) SSD1036 OvertakingGUID-7437FC2C-54B7-4DC9-9C9D-488FCBB024DA several vehicles SSD1026 Illustration 1 – Approaching from behind When overtaking several vehicles in a row, the vehicles after the first vehicle may not be detected if they are traveling close together.
(353,1) Another vehicle approaching from behind GUID-490379CE-CDAB-457B-A9CF-8701D65B5884 OvertakingGUID-EE01BDE7-9A26-4B69-BD04-9E9C33AF93BA another vehicle Illustration 3: The side indicator light illuminates if you overtake a vehicle and that vehicle stays in the detection zone for approximately 3 seconds. Illustration 1: The side indicator light illuminates if a vehicle enters the detection zone from behind in an adjacent lane.
(354,1) Entering from the side GUID-109094CC-831D-4899-B1EA-BDA306596FC5 Illustration 5: The side indicator light illuminates if a vehicle enters the detection zone from either side. Illustration 6: If the driver activates the turn signal, then the system chimes (twice) and the side indicator light flashes. SSD1037 Illustration 5 – Entering from the side NOTE: . The radar sensors may not detect a vehicle which is traveling at about the same speed as your vehicle when it enters the detection zone. .
(355,1) radar sensors. Action to take: When the above conditions no longer exist, the system will resume automatically. 1 If the BSW system warning light * continues to blink, have the system checked by an INFINITI retailer. SYSTEM MALFUNCTION GUID-0EFDC80E-8536-4A6D-AF6C-5B8E1B9BD823 When the system malfunctions, it will be turned off automatically, a beep will sound and the BSW system warning light will illuminate.
(356,1) Do not attach stickers (including transparent material), install accessories or apply additional paint near the radar sensors. Do not strike or damage the area around the radar sensors. Consult an INFINITI retailer if the area around the radar sensors is damaged due to a collision.
(357,1) CRUISE CONTROL GUID-8C625891-A812-4771-84FE-11A407420BB3 PRECAUTIONS ON CRUISE CONTROL GUID-CC69504F-BF04-4CFA-8CDA-FD9F86D182B0 . If the cruise control system malfunctions, it will cancel automatically. The SET indicator on the vehicle information display will then blink to warn the driver. . If the engine coolant temperature becomes excessively high, the cruise control system will be canceled automatically. .
(358,1) COAST/SET switch and release it. (The CRUISE SET indicator will come on in the instrument panel.) Take your foot off the accelerator pedal. Your vehicle will maintain the set speed. . To pass another vehicle, depress the accelerator pedal. When you release the pedal, the vehicle will return to the previously set speed. . The vehicle may not maintain the set speed on winding or hilly roads. If this happens, drive without the cruise control. To cancel the preset speed, follow any of these methods: 1.
(359,1) INTELLIGENT CRUISE CONTROL (ICC) SYSTEM (FULL SPEED RANGE) (if so equipped) GUID-9A2D29A7-0451-4C8D-B1D8-968265CE0E59 WARNING . ICC is not a collision avoidance or warning device. For highway use only and not intended for congested areas or city driving. Failure to apply the brakes could result in an accident. . Always observe posted speed limits and do not set the speed over them. . Always drive carefully and attentively when using either cruise control mode.
(360,1) system back on and select the desired cruise control mode. Always confirm the setting in the Intelligent Cruise Control system display. For the vehicle-to-vehicle distance control mode, see “Vehicle-to-vehicle distance control mode” (P.5-43). For the conventional (fixed speed) cruise control mode, see “Conventional (fixed speed) cruise control mode” (P.5-59).
(361,1) JVS0636X SSD0899 HOW TO SELECT THE CRUISE CONTROL MODEGUID-625B294B-2643-45B8-908D-1FF7A9BE5364 Selecting the vehicle-to-vehicle distance control mode GUID-5901B1D5-0DC4-4911-BB96-CD95905DF94B To choose the vehicle-to-vehicle distance 1 , quickly push and release control mode * A .
(362,1) Vehicle-to-vehicle distance control mode operation GUID-3E0A4B53-4CBC-44DE-AA04-74580CD76B3A above the maximum set speed. The vehicle-to-vehicle distance control mode is designed to maintain a selected distance and reduce the speed to match the slower vehicle ahead. The system will decelerate the vehicle as necessary and if the vehicle ahead comes to a stop, the vehicle decelerates to a standstill. However, the ICC system can only apply up to 40% of the vehicle’s total braking power.
(363,1) the set speed. 4. MAIN (ON·OFF) switch: Master switch to activate the system 5. DISTANCE switch: Changes the vehicle’s following distance: . Long . Middle . Short SSD0900 SSD0606 Vehicle-to-vehicle distance control mode switches GUID-92130138-55BB-4980-B6A1-E260C9B787A0 Vehicle-to-vehicle distance control mode display and indicators GUID-AD8D2FA1-FA5A-4530-83F6-F9A519F6FCDA The system is operated by a MAIN switch and four control switches, all mounted on the steering wheel.
(364,1) 4. Indicates your vehicle 5. Set vehicle speed indicator: Indicates the set vehicle speed. For Canadian models, the speed is displayed in km/h. 6. Intelligent Cruise Control system warning light (orange): The light comes on if there is a malfunction in the ICC system. SSD0607 When the ignition switch is pushed to the ON position, the indicators come on as illustrated to check for a burned-out bulb, and it turns off when the engine is started.
(365,1) SSD0902 To set cruising speed, accelerate your vehicle to the desired speed, push the COAST/SET switch and release it. (Vehicle ahead detection indicator, set distance indicator and set vehicle speed indicator come on.) Take your foot off the accelerator pedal. Your vehicle will maintain the set speed. SSD0784 When the COAST/SET switch is pushed under the following conditions, the system cannot be set and the ICC indicators will blink for approximately 2 seconds: .
(366,1) Push the MAIN switch to turn off the ICC system and reset the ICC switch by pushing the MAIN switch again.) For details about the VDC system, see “Vehicle Dynamic Control (VDC) system” (P.5-102). . When ABS or VDC (including the traction control system) is operating . When driving into a strong light (for example, sunlight) . When a wheel is slipping (To use the ICC system, make sure the wheels are no longer slipping.
(367,1) How to change the set vehicle speed GUID-796798D8-A099-453E-8F33-44A3D72BE6C9 speed and selected distance. Vehicle aheadGUID-D73A39BF-43C8-459F-9C24-47B7F579C407 not detected: When a vehicle is no longer detected ahead, the ICC system gradually accelerates your vehicle to resume the previously set vehicle speed. The ICC system then maintains the set speed.
(368,1) To reset at a slower cruising speed, use one of the following methods: . Lightly tap the brake pedal. When the vehicle attains the desired speed, push the COAST/SET switch and release it. . Push and hold the COAST/SET switch. The set vehicle speed will decrease by approximately 5 MPH (5 km/h for Canada). . Push, then quickly release the COAST/ SET switch. Each time you do this, the set speed will decrease by approximately 1 MPH (1 km/h for Canada).
(369,1) Approach warning GUID-A4EB4C01-19D7-4B1B-8DAD-BF4D1F9A9881 If your vehicle comes closer to the vehicle ahead due to rapid deceleration of that vehicle or if another vehicle cuts in, the system warns the driver with the chime and ICC system display. Decelerate by depressing the brake pedal to maintain a safe vehicle distance if: . The chime sounds. . The vehicle ahead detection and set distance indicator blink.
(370,1) Also, the sensor sensitivity can be affected by vehicle operation (steering maneuver or driving position in the lane) or traffic or vehicle condition (for example, if a vehicle is being driven with some damage). Automatic cancellation GUID-15069D6C-9D6B-4E7F-BCA5-B2475A344694 A chime sounds under the following conditions and the control is automatically canceled.
(371,1) matically accelerates or decelerates your vehicle according to the speed of the vehicle ahead. Depress the accelerator pedal to properly accelerate your vehicle when acceleration is required for a lane change. Depress the brake pedal when deceleration is required to maintain a safe distance to the vehicle ahead due to its sudden braking or if a vehicle cuts in. Always stay alert when using the ICC system. solely on the ICC system.
(372,1) . Oncoming vehicles in the same lane . Motorcycles traveling offset in the travel lane The sensor generally detects the signals returned from the reflectors on a vehicle ahead. Therefore, if the sensor cannot detect the reflector on the vehicle ahead, the ICC system may not maintain the selected distance. The following are some conditions in which the sensor cannot detect the signals: . When the reflector of the vehicle ahead is positioned high on the vehicle (trailer, etc.) .
(373,1) SSD0252 The detection zone of the ICC sensor is limited. A vehicle ahead must be in the detection zone for the vehicle-to-vehicle distance detection mode to maintain the selected distance from the vehicle ahead. and sounding the chime. The driver may have to manually control the proper distance away from vehicle traveling ahead. A vehicle ahead may move outside of the detection zone due to its position within the same lane of travel.
(374,1) SSD0254 SSD0253 When driving on some roads, such as winding, hilly, curved, narrow roads, or roads which are under construction, the ICC sensor may detect vehicles in a different lane, or may temporarily not detect a vehicle traveling ahead. This may cause the ICC system to decelerate or accelerate the vehicle. The detection of vehicles may also be affected by vehicle operation (steering maneuver or traveling position in the lane, etc.) or vehicle condition.
(375,1) SSD0614 System temporarily unavailable GUID-2802F0F0-0ACC-4531-8CF8-5765824F9A45 Condition A: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 Under the following conditions, the ICC system is automatically canceled. The chime will sound and the system will not be able to be set. JVS0625X * 2 * 1 Warning light and display (example) MAIN (ON·OFF) switch . When the VDC system is turned off . When the VDC or ABS (including the traction control system) operates . When a tire slips .
(376,1) Action to take: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 When the conditions listed above are no longer present, turn the system off using 2 . Turn the ICC system the MAIN switch * back on to use the system. SSD0615 SSD0621 Condition B: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407 When the sensor window is dirty, making it impossible to detect a vehicle ahead, the ICC system is automatically canceled.
(377,1) INFINITI retailer. . Do not attach a sticker (including transparent material) or install an accessory near the sensor. This could cause failure or malfunction. an INFINITI retailer. CONVENTIONAL (fixed speed) CRUISE CONTROL MODE GUID-36DB00B5-F45A-45E5-8D61-1D8EDE4B46BD This mode allows driving at a speed between 25 to 90 MPH (40 to 144 km/h) without keeping your foot on the accelerator pedal.
(378,1) under the following conditions: — when it is not possible to keep the vehicle at a set speed — in heavy traffic or in traffic that varies in speed — on winding or hilly roads — on slippery roads (rain, snow, ice, etc.) — in very windy areas . Doing so could cause a loss of vehicle control and result in an accident. SSD0904 Conventional (fixed speed) cruise control switch GUID-D62DE7D2-8B6F-4B4E-8E41-91100C332695 1. ACCELERATE/RESUME switch: Resumes set speed or increases speed incrementally. 2.
(379,1) set your desired cruising speed. Pushing the MAIN switch again will turn the system completely off. 3. Cruise system warning light: Comes on if there is a malfunction in the cruise control system. When the ignition switch is pushed to the OFF position, the system is also automatically turned off.
(380,1) To cancel the preset speed, use one of the following methods: . Push the CANCEL button. The SET indicator will go out. . Tap the brake pedal. The SET indicator will go out. . Turn the MAIN switch off. Both the CRUISE indicator and SET indicator will go out. To reset at a faster cruising speed, use one of the following methods: SSD0906 To set cruising speed, accelerate your vehicle to the desired speed, push the COAST/SET switch and release it. (The SET indicator will come on in the display.
(381,1) DISTANCE CONTROL ASSIST (DCA) SYSTEM (if so equipped) GUID-AAD93081-BC7C-48D7-8AB6-56C3A6C02B1E retailer. PREVIEW FUNCTION (for Intelligent Cruise Control system equipped models) GUID-97601226-8036-42E9-8A3B-4A97D4E915A0 JVS0626X Warning light GUID-932DDDAC-29B1-48A5-B67A-64C40A20D0FE When the system is not operating properly, the chime sounds and the system warning light (orange) will come on.
(382,1) depressing the brake pedal, depending on the distance to the vehicle ahead and the surrounding circumstances in order to maintain a safe distance between vehicles. . Always pay attention to the operation of the vehicle and be ready to manually decelerate to maintain the proper following distance. The DCA system may not be able to decelerate the vehicle under some circumstances. .
(383,1) DCA SYSTEM OPERATION GUID-2A3A796B-DDD2-4B0E-A18A-B772475513DB WARNING Failure to follow the warnings and instructions for proper use of the DCA system could result in serious personal injury or death. JVS0627X 1 * 2 * 3 * 4 * Indicators (on the vehicle information display) Center display Dynamic driver assistance switch Center multi-function control panel . When the vehicle ahead detection indicator light is not illuminated, system will not control or warn the driver. .
(384,1) a vehicle moves into the traveling lane ahead or if a vehicle traveling ahead rapidly decelerates, the distance between vehicles may become closer because the DCA system cannot decelerate the vehicle quickly enough. If this occurs, the DCA system will sound a warning chime and blink the system display to notify the driver to take necessary action. See “Approach warning” (P.5-67).
(385,1) When brake operation by driver is required: The system alerts the driver by a warning chime and blinking the vehicle ahead detection indicator. If the driver’s foot is on the accelerator pedal after the warning, the system moves the accelerator pedal upward to assist the driver to switch to the brake pedal. The stoplights of the vehicle come on and the brake pedal depresses when braking is performed by the DCA system. When the brake operates, a noise may be heard. This is not a malfunction.
(386,1) Also, the sensor sensitivity can be affected by vehicle operation (steering maneuver or driving position in the lane) or traffic or vehicle condition (for example, if a vehicle is being driven with some damage).
(387,1) TURNING THE DCA SYSTEM ON/OFF GUID-2A3B16C5-21B7-4211-80BC-FB23940D7397 To turn on the DCA system, push the 3 on dynamic driver assistance switch * the steering wheel after starting the engine. The DCA system switch indicator 1 in the vehicle information display will * appear. Push the dynamic driver assis3 again to turn off the DCA tance switch * system. The DCA system switch indicator 1 will turn off. * will not operate.
(388,1) HOW TO ENABLE/DISABLE THE DCA SYSTEM GUID-7A6539D4-1D92-4CCB-B486-CF728DAF490A The light comes on if there is a malfunction in the DCA system. DCA SYSTEM LIMITATIONS GUID-C4BA45D1-3B4B-475A-AC1D-47766D9D44CA 1 button on the 1. Push the SETTING * center multi-function control panel and highlight the “Driver Assistance” key on the center display using the INFINITI controller. (See “How to use INFINITI controller” (P.4-5).) Then push the 2 button. ENTER * 2.
(389,1) etc.) to maintain a safe distance between vehicles. . . . — When strong light (for example, at sunrise or sunset) is directly shining on the front of the vehicle Always pay attention to the operation of the vehicle and be ready to manually decelerate to maintain the proper following distance. The DCA system may not be able to decelerate the vehicle under some circumstances.
(390,1) SSD0252 The detection zone of the sensor is limited. A vehicle ahead must be in the detection zone for the system to operate. away from vehicle traveling ahead. A vehicle ahead may move outside of the detection zone due to its position within the same lane of travel. Motorcycles may not be detected in the same lane ahead if they are traveling offset from the centerline of the lane. A vehicle that is entering the lane ahead may not be detected until the vehicle has completely moved into the lane.
(391,1) SSD0253 When driving on some roads, such as winding, hilly, curved, narrow roads, or roads which are under construction, the sensor may detect vehicles in a different lane, or may temporarily not detect a vehicle traveling ahead. This may cause the system to work inappropriately. vehicle traveling ahead. The detection of vehicles may also be affected by vehicle operation (steering maneuver or traveling position in the lane, etc.) or vehicle condition.
(392,1) SSD0771 SYSTEM TEMPORARILY UNAVAILABLE GUID-139D3B92-1D72-4141-9F07-7022B56DDCCA Condition A: JVS0630X 1 * 2 * Warning light and indicators Dynamic driver assistance switch Under the following conditions, the DCA system is automatically canceled. The chime will sound and the DCA system switch indicator will blink. The system will not be able to be set. . When the VDC system is off (To use the DCA system, turn on the VDC, then push the dynamic driver assistance switch.
(393,1) tem” (P.5-102). . When the VDC or ABS (including the traction control system) operates . When the SNOW mode switch is ON (To use the DCA system, turn off the SNOW mode switch, then turn on the dynamic 2 .) driver assistance switch * For details about the SNOW mode switch, see “SNOW mode switch” (P.242). . When driving into a strong light (for example, sunlight) Action to take: When the conditions listed above are no longer present, turn the system off with the 2 .
(394,1) To keep the DCA system operating properly, be sure to observe the following: If it is not possible to set the system or the indicator stays on, it may indicate that the system is malfunctioning. Although the vehicle is still driveable under normal conditions, have the vehicle checked at an INFINITI retailer. JVS0636X SENSOR MAINTENANCE GUID-E21DBA00-CD1D-4D88-A016-1968F9602270 The sensor for the DCA system located below the front bumper. A * is . Always keep the sensor clean.
(395,1) FORWARD COLLISION WARNING (FCW) SYSTEM (if so equipped) GUID-AC14265D-4B04-45A1-930E-06F725DFD0E5 WARNING Failure to follow the warnings and instructions for proper use of the FCW system could result in serious personal injury or death. . The FCW system is intended to warn the driver before a collision but it will not intervene to avoid a collision. It is the driver’s responsibility to stay alert, drive safely and be in control of the vehicle at all times. .
(396,1) FCW SYSTEM OPERATION GUID-06F558BB-90CF-4FEB-A46F-17920DEFA839 The FCW system will function at speeds of approximately 10 MPH (15 km/h) and above, when the system turns on. When the system judges that your vehicle is getting close to the vehicle ahead in the travel lane, the vehicle ahead detection 1 indicator * on the vehicle information display blinks and a warning chime sounds.
(397,1) TURNING THE FCW SYSTEM ON/OFF GUID-6FECEFFF-0252-4BB0-B068-0631D4547EA5 The FCW system is automatically turned on when the engine is started and the warning 4 illuminates systems ON indicator light * on the switch. You can turn the FCW system off by pushing the warning systems switch 3 on the instrument panel. This switch * will turn on and off the FCW, LDW and BSW systems at the same time.
(398,1) FCW SYSTEM LIMITATIONS GUID-E6CD8DCD-7100-4AD2-9117-4702A2FEFF68 WARNING Listed below are the system limitations of the FCW system. Failure to operate the vehicle in accordance with these system limitations could result in serious injury or death. . The system will not detect the following objects: — Pedestrians, animals or obstacles in the roadway — Oncoming vehicles in the same lane .
(399,1) window is dirty. If the sensor window is dirty, clean it with a soft cloth and restart the engine. If the sensor window is not dirty, restart the engine. If the IBA OFF A continues to illuminate indicator light * even if the IBA system is turned on with the B , have the system IBA OFF switch * checked by an INFINITI retailer. warn the driver properly. Be sure to check and clean the sensor regularly. . Excessive noise will interfere with the warning chime sound, and the chime may not be heard. .
(400,1) INFINITI retailer. . Do not attach a sticker (including transparent material) or install an accessory near the sensor. This could cause failure or malfunction. JVS0636X SENSOR MAINTENANCE GUID-30EA2ED9-FA16-42FB-91EB-D3D9FFA3A929 A The sensor * for the FCW system is located below the front bumper. To keep the FCW system operating properly, be sure to observe the following: . Always keep the sensor clean. Wipe with a soft cloth carefully so as not to damage the sensor. .
(401,1) INTELLIGENT BRAKE ASSIST (IBA) SYSTEM (if so equipped) GUID-465533BA-D780-4D07-81DD-B7EB63B1E55B WARNING Failure to follow the warnings and instructions for proper use of the IBA system could result in serious personal injury or death. . The IBA system is not a collision avoidance system. It is the driver’s responsibility to stay alert, drive safely and be in control of the vehicle at all times. .
(402,1) IBA SYSTEMGUID-92F759FC-FBC9-426A-88A8-24B9155C86EA OPERATION The IBA system will function when your vehicle is driven at speeds of approximately 10 MPH (15 km/h) or above, and when the vehicle’s speed is approximately 10 MPH (15 km/h) faster than that of the vehicle ahead. When the system judges that your vehicle is getting close to the vehicle ahead in the traveling lane, the vehicle ahead detection 1 indicator * on the vehicle information display blinks and a warning chime sounds.
(403,1) TURNING THE IBA SYSTEM ON/OFF GUID-179AF1E6-DD05-4E11-A12C-67C8DB064B12 The IBA system will be turned on/off by 2 . The IBA OFF pushing the IBA OFF switch * 1 will illuminate when the indicator light * system is turned off. To turn the system off/on, push and hold 2 for more than 1 the IBA OFF switch * second after starting the engine.
(404,1) . — When the reflectors of the vehicle ahead are covered with dirt, snow or road spray. — Pedestrians, animals or obstacles in the roadway — Oncoming vehicles in the same lane . — When visibility is low (such as rain, fog, snow, etc.). The system will not detect another vehicle under the following conditions: — When the sensor gets dirty and it is impossible to detect the distance from the vehicle ahead. — When driving into a strong light (for example, sunlight) . .
(405,1) system may not detect them. In these instances the system may not be able to warn the driver properly. Be sure to check and clean the sensor regularly. SSD0782 Reflectors on the road WARNING . The system may detect highly reflective objects such as reflectors, signs, white markers and other stationary objects on the road or near the traveling lane. In extreme conditions, detection of these objects may cause the system to activate. .
(406,1) INFINITI retailer. . Do not attach a sticker (including transparent material) or install an accessory near the sensor. This could cause failure or malfunction. The system will be cancelled automatically with a beep sound and the IBA OFF A indicator light * will illuminate under the following conditions: . When the sensor window is dirty .
(407,1) BREAK-IN SCHEDULE GUID-10D0AD70-6379-4FE2-9B74-B78AAFF5A249 CAUTION During the first 1,200 miles (2,000 km), follow these recommendations to obtain maximum engine performance and ensure the future reliability and economy of your new vehicle. Failure to follow these recommendations may result in shortened engine life and reduced engine performance. . Avoid driving for long periods at constant speed, either fast or slow. Do not run the engine over 4,000 rpm. .
(408,1) INCREASING FUEL ECONOMY GUID-51AEC030-65C9-47EF-B6A3-8493FD8D8CF2 6. Plan for the shortest route. . Utilize a map or navigation system to determine the best route to save time. 7. Avoid idling. . Shutting off your engine when safe for stops exceeding 30-60 seconds saves fuel and reduces emissions. 8. Buy an automated pass for toll roads. . Automated passes permit drivers to use special lanes to maintain cruising speed through the toll and avoid stopping and starting. .
(409,1) ALL-WHEEL DRIVE (AWD) (if so equipped) GUID-2AFF35EE-62A6-4333-8128-74208A7BC8F6 system while the engine is running, the warning light will come on. The warning light may blink rapidly (about twice per second) while trying to free a stuck vehicle due to high power train oil temperature. The driving mode may change to two-wheel drive. If the warning light blinks rapidly during operation, stop the vehicle with the engine idling in a safe place immediately.
(410,1) PARKING/PARKING ON HILLS GUID-EAE9EBBF-502A-4AAE-9C1A-14AAF7397509 and have your vehicle checked by an INFINITI retailer as soon as possible. . If the warning light remains on after the above operation, have your vehicle checked by an INFINITI retailer as soon as possible. . The power train may be damaged if you continue driving with the warning light blinking. SD1006MA WARNING . Do not stop or park the vehicle over flammable materials such as dry grass, waste paper or rags.
(411,1) cause the vehicle to move unexpectedly or roll away and result in an accident. . Make sure the automatic transmission shift lever has been pushed as far forward as it can go and cannot be moved without depressing the foot brake pedal. away from the center of the road if it moves. 4. Push the ignition switch to the OFF position. 1. Firmly apply the parking brake. 2. Move the shift lever to the P (Park) position. 3.
(412,1) SONAR SYSTEM (if so equipped) GUID-A813D745-B0C6-4233-BC8B-EAE744FD23DA stacles or false alarms. CAUTION Keep the interior of the vehicle as quiet as possible to hear the tone clearly. SSD0622 WARNING . . The sonar system is a convenience but it is not a substitute for proper parking. Always look around and check that it is safe to do so before parking. Always move slowly. Read and understand the limitations of the sonar system as contained in this section.
(413,1) SONAR INDICATOR GUID-0A70A675-477A-4B18-A72E-37D543708D03 the rate of the tone increases. When the obstacle is less than 11.8 in (30 cm) away, the tone will sound continuously. With the “Sonar Display” key ON in the “Sonar” settings, when the corner/center sonar detects obstacles near the bumper, a tone will sound and the sonar indicator will 1 . When the appear in the center display * RearView Monitor is displayed, the sonar indicator will appear in the upper corner of 2 .
(414,1) the OFF position to the ON position. . When the shift lever is in the R (Reverse) position. . When the vehicle speed is less than 6 MPH (10 km/h). The automatic turning on function can be turned on and off by pushing the switch for more than 4 seconds. SONAR setting display. (See “How to use SETTING button” (P.4-13) for the “Sonar” settings.) When the sonar indicator is off, only a tone sounds when the sonar detects obstacles.
(415,1) POWER STEERING GUID-7365CD83-D7CC-403B-ABCC-17F78FCE9580 WARNING If the engine is not running or is turned off while driving, the power assist for the steering will not work. Steering will be harder to operate. The power assisted steering uses a hydraulic pump, driven by the engine, to assist steering. If the engine stops or the drive belt breaks, you will still have control of the vehicle. However, much greater steering effort is needed, especially in sharp turns and at low speeds.
(416,1) BRAKE ASSIST GUID-F2D40397-D9A6-45A1-B8FA-87F8507C40C9 and could result in loss of vehicle control. WARNING . . While driving on a slippery surface, be careful when braking, accelerating or downshifting. Abrupt braking or accelerating could cause the wheels to skid and result in an accident. If the engine is not running or is turned off while driving, the power assist for the brakes will not work. Braking will be harder.
(417,1) all times. SSD0338 . The sensor will not detect: — Pedestrians or objects in the roadway — Oncoming vehicles in the same lane — Motorcycles traveling offset in the travel lane as illustrated WARNING . This system is only an aid to assist braking operation and is not a collision warning or avoidance device. It is the driver’s responsibility to stay alert, drive safely and be in control of the vehicle at .
(418,1) an INFINITI retailer. ANTI-LOCK GUID-85380D8A-4BD0-498F-B350-7DE5284287C5 BRAKING SYSTEM (ABS) How to handle the sensor GUID-5FE596BC-1477-47BB-A996-5C1CADB0AE49 The sensor for the Preview Function is common with Intelligent Cruise Control and is located below the front bumper. WARNING . The Anti-lock Braking System (ABS) is a sophisticated device, but it cannot prevent accidents resulting from careless or dangerous driving techniques.
(419,1) and Loading Information label” (P.911). — For detailed information, see “Wheels and tires” (P.8-29). The Anti-lock Braking System (ABS) controls the brakes so the wheels do not lock during hard braking or when braking on slippery surfaces. The system detects the rotation speed at each wheel and varies the brake fluid pressure to prevent each wheel from locking and sliding.
(420,1) VEHICLE DYNAMIC CONTROL (VDC) SYSTEM GUID-A482E96B-B301-4220-AB3C-3EEB8EFE301F The Vehicle Dynamic Control (VDC) system uses various sensors to monitor driver inputs and vehicle motion. Under certain driving conditions, the VDC system helps to perform the following functions. . Controls brake pressure to reduce wheel slip on one slipping drive wheel so power is transferred to a non slipping drive wheel on the same axle. .
(421,1) COLD WEATHER DRIVING GUID-F2C4EA30-5567-4530-A6B1-9F439C2AFBBE bars, bushings and wheels are not INFINITI recommended for your vehicle or are extremely deteriorated, the VDC system may not operate properly. This could adversely affect vehicle handling performance, and the VDC warning light may illuminate. .
(422,1) TIRE EQUIPMENT GUID-1CA8DAE2-704C-45E1-ADDE-12FEC45C20DC SPECIAL WINTER EQUIPMENT GUID-6B7C470C-F2FB-4473-B3CE-1FBF3ECC08A9 SUMMER tires have a tread designed to provide superior performance on dry pavement. However, the performance of these tires will be substantially reduced in snowy and icy conditions. If you operate your vehicle on snowy or icy roads, INFINITI recommends the use of MUD & SNOW or ALL SEASON tires on all four wheels.
(423,1) To use the GUID-FE2553FE-DFD1-42C9-9A07-482D598D2FD8 engine block heater . Disconnect and properly store the engine block heater cord before starting the engine. Damage to the cord could result in an electrical shock and can cause serious injury. . Use a heavy-duty 3-wire, 3-pronged extension cord rated for at least 10A. Plug the extension cord into a Ground Fault Interrupt (GFI) protected, grounded 110-VAC outlet.
(424,1) MEMO 5-106 Condition: Starting and driving [ Edit: 2015/ 6/ 12 Model: J50-D ]
(425,1) 6 In case of emergency Hazard warning flasher switch ............................. ... Roadside assistance program .............................. ... Emergency engine shut off .................................. ... Flat tire ............................................................... ... Tire Pressure Monitoring System (TPMS) ........ ... Changing a flat tire ......................................... ... Condition: 6-2 6-2 6-3 6-3 6-3 6-4 Jump starting .......................................
(426,1) HAZARD WARNING FLASHER SWITCH ROADSIDE ASSISTANCE PROGRAM GUID-96DA9402-0531-4A66-9368-B7490B9A9A99 GUID-ACF6D47C-7AAA-4B7A-B02A-0F1F6CF62D6C . Turn signals do not work when the hazard warning flasher lights are on. The flasher can be actuated with the ignition switch in any position. In the event of a roadside emergency, Roadside Assistance Service is available to you. Please refer to your Warranty Information Booklet (U.S.
(427,1) EMERGENCY ENGINE SHUT OFF FLAT TIRE GUID-5912370E-3E34-4B63-8EC8-9A6325763C2F GUID-A5119E02-3046-4764-81FF-DBF30CEB2EC3 To shut off the engine in an emergency situation, while driving perform the following procedure: TIRE PRESSURE MONITORING SYSTEM (TPMS) GUID-7478345F-A7C3-427E-ABAB-5ADEB0DD4ED3 . Rapidly push the push-button ignition switch 3 consecutive times in less than 1.5 seconds, or . Push and hold the push-button ignition switch for more than 2 seconds.
(428,1) sensors. CHANGING GUID-0E0B2B4B-9FED-4F60-A0A7-865CEFB88E8F A FLAT TIRE If you have a flat tire, follow the instructions below. Stopping the vehicle GUID-463EF4D0-F1DC-4747-8B03-C6AC4E8440C0 . Never change tires when the vehicle is on a slope, ice or slippery areas. This is hazardous. . Never change tires if oncoming traffic is close to your vehicle. Wait for professional road assistance. 1. Safely move the vehicle off the road and away from traffic. 2. Turn on the hazard warning flashers.
(429,1) jack provided with your vehicle on other vehicles. The jack is designed for lifting only your vehicle during a tire change. SCE0724 Getting theGUID-547B9146-5878-4C5B-90AE-22C6052BC712 spare tire and tools Raise using edge using 1 the luggage room floor cover * A , then hang it on the the handle * 2 of the luggage room opening * B . the hook * . Use the correct jack-up points. Never use any other part of the vehicle for jack support. . Never jack up the vehicle more than necessary. .
(430,1) SCE0731 Jack-up point 1. Place the jack directly under the jack-up point as illustrated so the top of the jack contacts the vehicle at the jack-up point. Align the jack head between the two notches in the front or the rear as shown. Also fit the groove of the jack head between the notches as shown. The jack should be used on level firm ground. 6-6 SCE0504 2. Loosen each wheel nut one or two turns by turning counterclockwise with the wheel nut wrench.
(431,1) 4. Lower the vehicle slowly until the tire touches the ground. Then, with the wheel nut wrench, tighten the wheel nuts securely in the sequence as illustrated. Lower the vehicle completely. . COLD pressure: After the vehicle has been parked for three hours or more or driven less than 1 mile (1.6 km). WARNING . Incorrect wheel nuts or improperly tightened wheel nuts can cause the wheel to become loose or come off. This could cause an accident. .
(432,1) JUMP STARTING GUID-865DD09C-2BA7-4ADC-98A7-EFEF8BF85E15 . 6-8 The T-type spare tire and small size spare tire are designed for emergency use. See specific instructions under the heading “Wheels and tires” (P.8-29). To start your engine with a booster battery, the instructions and precautions below must be followed. .
(433,1) . Make sure the jumper cables do not touch moving parts in the engine compartment and that clamps do not contact any other metal. 5. Start the engine of the booster vehicle A and let it run for a few minutes. * 6. Keep the engine speed of the booster A at about 2,000 rpm, and vehicle * start the engine of the vehicle being B . jump started * SCE0734 WARNING Always follow the instructions below. Failure to do so could result in damage to the charging system and cause personal injury. 1.
(434,1) PUSH STARTING IF YOUR VEHICLE OVERHEATS GUID-E9436C03-8944-4BBB-9DB3-5DC6B05F4B7F 9. Put the battery cover on. GUID-5BE5A797-E982-43FD-B1E6-C7F76A46462E Do not attempt to start the engine by pushing. CAUTION . Automatic transmission models cannot be push-started or tow-started. Attempting to do so may cause transmission damage. . Three way catalyst equipped models should not be started by pushing since the three way catalyst may be damaged. .
(435,1) TOWING YOUR VEHICLE GUID-CF7740E5-F31C-4AC9-BD8B-87B8B432DD7A speed. 3. If engine overheating is caused by climbing a long hill on a hot day, run the engine at a fast idle (approximately 1,500 rpm) until the temperature gauge indication returns to normal. 4. Get out of the vehicle. Look and listen for steam or coolant escaping from the radiator before opening the hood. (If steam or coolant is escaping, turn off the engine.) Do not open the hood further until no steam or coolant can be seen. 5.
(436,1) used. . Always attach safety chains before towing. For information about towing your vehicle behind a recreational vehicle (RV), see “Flat towing” (P.9-15). SCE0860 Two-wheel drive models TOWING RECOMMENDED BY INFINITI GUID-BB74F24E-A3EE-4B73-8BB7-1AE2CF01B7EC backward), as this may cause serious and expensive damage to the transmission. If it is necessary to tow the vehicle with the front wheels raised, always use towing dollies under the rear wheels.
(437,1) SCE0736 All-wheel drive models All-Wheel Drive (AWD) models GUID-F2D8776D-5A6E-4520-8F5C-3BBA6D56DC39 INFINITI recommends that towing dollies be used when towing your vehicle or the vehicle be placed on a flat bed truck as illustrated. JVE0266X CAUTION Never tow AWD models with any of the wheels on the ground as this may cause serious and expensive damage to the powertrain.
(438,1) Pulling a stuck vehicle GUID-F892B344-7115-42FE-AB6E-2CBEBE7F56E6 If your vehicle is stuck in sand, snow, mud, etc., use a tow strap or other device designed specifically for vehicle recovery. Always follow the manufacturer’s instructions for the recovery device. Remove the recovery hook cover from the front bumper using a suitable tool. JVE0267X VEHICLE RECOVERY (freeing a stuck vehicle) GUID-6F0F0FB0-43A7-4522-9A0A-23DD884C809F WARNING . Stand clear of a stuck vehicle. .
(439,1) . . motion. Release the accelerator pedal before shifting between R and D. Do not spin the tires above 35 MPH (55 km/h). 5. If the vehicle cannot be freed after a few tries, contact a professional towing service to remove the vehicle.
(440,1) MEMO 6-16 In case of emergency Condition: [ Edit: 2015/ 6/ 12 Model: J50-D ]
(441,1) 7 Appearance and care Cleaning exterior ................................................. ... Washing.......................................................... ... Waxing............................................................ ... Removing spots .............................................. ... Underbody ...................................................... ... Glass .............................................................. ... Wheels......................................................
(442,1) CLEANING EXTERIOR GUID-7F4AA201-20C6-490D-A61B-595B195E20BC In order to maintain the appearance of your vehicle, it is important to take proper care of it. To protect the paint surface, wash your vehicle as soon as you can: . after a rainfall to prevent possible damage from acid rain . after driving on coastal roads . when contaminants such as soot, bird droppings, tree sap, metal particles or bugs get on the paint surface .
(443,1) washing. Follow the instructions supplied with the wax. . Do not use a wax containing any abrasives, cutting compounds or cleaners that may damage the vehicle finish. Machine compound or aggressive polishing on a base coat/clear coat paint finish may dull the finish or leave swirl marks. REMOVING GUID-8F8DB17E-6F06-4A94-B5DB-301459DF8353 SPOTS Remove tar and oil spots, industrial dust, insects, and tree sap as quickly as possible from the paint surface to avoid lasting damage or staining.
(444,1) CLEANING INTERIOR GUID-24528D5D-B84E-4C6F-BFBD-878C7BB6A3ED ambient temperature. . Rinse the wheel to completely remove the cleaner within 15 minutes after the cleaner is applied. CHROME PARTS GUID-BB65BA92-9AB1-4959-BA1B-3D6978C7DE45 Clean chrome parts regularly with a nonabrasive chrome polish to maintain the finish. TIRE DRESSING GUID-C4834CAA-6AB9-4461-8146-49C833439B94 INFINITI does not recommend the use of tire dressings.
(445,1) CAUTION . Never use benzine, thinner, or any similar material. . For cleaning, use a soft cloth, dampened with water. Never use a rough cloth, alcohol, benzine, thinner or any kind of solvent or paper towel with a chemical cleaning agent. They will scratch or cause discoloration to the lens. . Do not spray any liquid such as water on the meter lens. Spraying liquid may cause the system to malfunction. .
(446,1) is properly positioned. 3. Make sure the floor mat does not interfere with pedal operation. With the ignition in the OFF position and the shift lever in the P (Park) position, fully apply and release all pedals. The floor mat must not interfere with pedal operation or prevent the pedal from returning to its normal position. See an INFINITI retailer for details about installing the floor mats in your vehicle.
(447,1) CORROSION PROTECTION GUID-F4B174F5-C232-4777-9AC2-6DAD58C9AD98 cal solvents to clean the seat belts, since these materials may severely weaken the seat belt webbing. MOST COMMON FACTORS CONTRIBUTING TO GUID-406961BB-308F-4E16-932A-C4321769713C VEHICLE CORROSION Temperature GUID-F7936E48-9F77-4961-AC71-40591166C8EB . The accumulation of moisture-retaining dirt and debris in body panel sections, cavities, and other areas. .
(448,1) CAUTION . NEVER remove dirt, sand or other debris from the passenger compartment by washing it out with a hose. Remove dirt with a vacuum cleaner. . Never allow water or other liquids to come in contact with electronic components inside the vehicle as this may damage them. Chemicals used for road surface deicing are extremely corrosive. They accelerate corrosion and deterioration of underbody components such as the exhaust system, fuel and brake lines, brake cables, floor pan and fenders.
(449,1) 8 Maintenance and do-it-yourself Maintenance requirement .................................... ... 8-2 Scheduled maintenance .................................. ... 8-2 General maintenance ...................................... ... 8-2 Where to go for service ................................... ... 8-2 General maintenance........................................... ... 8-2 Explanation of maintenance items ................... ... 8-2 Maintenance precautions .................................... ...
(450,1) MAINTENANCE REQUIREMENT GENERAL MAINTENANCE GUID-90DCD6DC-D7BF-403F-9A47-6BEC1FA978E4 GUID-E43F9B1C-55D3-48FD-9183-3E5AFC77C6BC Some day-to-day and regular maintenance is essential to maintain your vehicle good mechanical condition, as well as its emission and engine performance. It is the owner’s responsibility to make sure that the scheduled maintenance, as well as general maintenance, is performed.
(451,1) is released. When driving in areas using road salt or other corrosive materials, check lubrication frequently. Lights*: Clean the headlights on a regular basis. Make sure that the headlights, stop lights, tail lights, turn signal lights, and other lights are all operating properly and installed securely. Also check headlight aim. Road wheel nuts (lug nuts)*: When checking the tires, make sure no wheel nuts are missing, and check for any loose wheel nuts. Tighten if necessary.
(452,1) Seats: Check seat position controls such as seat adjusters, seatback recliner, etc. to ensure they operate smoothly and that all latches lock securely in every position. Check that the head restraint/headrest moves up and down smoothly and that the locks (if so equipped) hold securely in all latched positions. Steering wheel: Check for changes in the steering conditions, such as excessive free play, hard steering or strange noises.
(453,1) MAINTENANCE PRECAUTIONS GUID-08893066-B796-43B7-B60D-9768B1E34FB5 those used on icy roads or to control dust. It is very important to remove these substances, otherwise rust will form on the floor pan, frame, fuel lines and around the exhaust system. At the end of winter, the underbody should be thoroughly flushed with plain water, being careful to clean those areas where mud and dirt may accumulate. For additional information, see “Cleaning exterior” (P.7-2).
(454,1) are under high pressure even when the engine is off. that it be done by an INFINITI retailer. CAUTION . Do not work under the hood while the engine is hot. Turn the engine off and wait until it cools down. . Avoid direct contact with used engine oil and coolant. Improperly disposed engine oil, coolant, and/or other vehicle fluids can damage the environment. Always conform to local regulations for disposal of vehicle fluid. This “8.
(455,1) ENGINE COMPARTMENT CHECK LOCATIONS ENGINE COOLING SYSTEM GUID-242FCEEB-F960-49BA-AA46-1FF7A9A29EB7 GUID-322FC0CD-1857-4918-A8CD-01894CD8502C The engine cooling system is filled at the factory with a pre-diluted mixture of 50% Genuine NISSAN Long Life Antifreeze/Coolant (blue) and 50% water to provide yearround anti-freeze and coolant protection. The antifreeze solution contains rust and corrosion inhibitors. Additional engine cooling system additives are not necessary. WARNING .
(456,1) clog the cooling system and cause damage to the engine, transmission and/or cooling system. . . 8-8 When adding or replacing coolant, be sure to use only Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent. Genuine NISSAN Long Life Antifreeze/Coolant (blue) is pre-diluted to provide antifreeze protection to −348F (−378C).
(457,1) ENGINE OIL GUID-63D00A88-F5C4-4696-BDD6-0AA535102386 This vehicle contains Genuine NISSAN Long Life Antifreeze/Coolant (blue). The life expectancy of the factory-fill coolant is 105,000 miles (168,000 km) or 7 years. Mixing any other type of coolant or the use of non-distilled water will reduce the life expectancy of the factory-fill coolant. Refer to the INFINITI Service and Maintenance Guide for more details.
(458,1) recommended oil through the opening. 3 . Do not overfill * CHANGING GUID-390F081D-1DEF-4917-BAD6-B8787196BB70 ENGINE OIL AND FILTER 6. Recheck oil level with the dipstick. Vehicle set-up GUID-BB087937-D7A9-4CC6-A836-698D655D7827 It is normal to add some oil between oil maintenance intervals or during the breakin period, depending on the severity of operating conditions. 2. Run the engine until it reaches operating temperature. CAUTION Oil level should be checked regularly.
(459,1) Engine oil and filter GUID-E069CA0B-FE37-4891-BF0D-7B9903CFD493 1. Place a large drain pan under the drain plug. 2. Remove the oil filler cap. 1 3. Remove the drain plug * with a wrench and completely drain the oil. CAUTION Be careful not to burn yourself, as the engine oil is hot. Waste oil must be disposed of properly. . Check your local regulations. 4. (Perform steps 4 to 7 only when the engine oil filter change is needed.) . 2 with an oil filter Loosen the oil filter * wrench.
(460,1) AUTOMATIC TRANSMISSION FLUID (ATF) GUID-413C56D8-DE7D-40F7-B952-EAB4F90EE777 WARNING . Prolonged and repeated contact with used engine oil may cause skin cancer. . Try to avoid direct skin contact with used oil. If skin contact is made, wash thoroughly with soap or hand cleaner as soon as possible. . Keep used engine oil out of reach of children.
(461,1) BRAKE FLUID GUID-0B2F196B-6B90-4B95-8D39-C84837E22F15 CAUTION . Do not overfill. . Use Genuine NISSAN PSF or equivalent. For further brake fluid specification information, see “Capacities and recommended fluids/lubricants” (P.9-2). WARNING . Use only new fluid from a sealed container. Old, inferior or contaminated fluid may damage the brake system. The use of improper fluids can damage the brake system and affect the vehicle’s stopping ability. .
(462,1) WINDOW WASHER FLUID GUID-FB6F6692-515D-48E4-BCF1-0CBC5C24ED24 Add a washer solvent to the washer for better cleaning. In the winter season, add a windshield washer antifreeze. Follow the manufacturer’s instructions for the mixture ratio. Do not use the window washer reservoir tank to mix the washer fluid concentrate and water. Refill the reservoir more frequently when driving conditions require an increased amount of window washer fluid.
(463,1) BATTERY GUID-39010BA6-A973-4930-B557-1C6529970EEF . Keep the battery surface clean and dry. Clean the battery with a solution of baking soda and water. . Make certain the terminal connections are clean and securely tightened. . If the vehicle is not to be used for 30 days or longer, disconnect the negative (−) battery terminal cable to prevent discharging it. NOTE: ated by the battery is explosive. Do not allow battery fluid to contact your skin, eyes, fabrics, or painted surfaces.
(464,1) VARIABLE VOLTAGE CONTROL SYSTEM GUID-FC5633A2-FD59-4507-B12A-58F793B8DABB JUMP STARTING GUID-2817327F-6E21-4AC8-B820-117364796C79 If jump starting is necessary, see “Jump starting” (P.6-8). If the engine does not start by jump starting, the battery may have to be replaced. Contact an INFINITI retailer. SDI1480C 1. Remove the cell plugs A . * 2. Add distilled water up to the UPPER 1 line. LEVEL * CAUTION . Do not ground accessories directly to the battery terminal.
(465,1) DRIVE BELTS SPARK PLUGS GUID-3686748E-2EEC-429B-BEFA-78191D702FA3 GUID-AE6B98B2-820E-46ED-892B-D3D84FBE5412 ess. If the belt is in poor condition or loose, have it replaced or adjusted by an INFINITI retailer. 2. Have the belts checked regularly for condition and tension in accordance with the maintenance schedule in your “INFINITI Service and Maintenance Guide”. WARNING Be sure the engine and the ignition switch are off and that the parking brake is engaged securely. CAUTION SDI2119 1. 2.
(466,1) AIR CLEANER GUID-A762655D-D645-4C3F-90D2-925E81145437 Always replace spark plugs with recommended or equivalent ones. SDI2020 REPLACINGGUID-49D7E044-4B04-40E9-BA4E-CF0EA30A67B9 SPARK PLUGS If replacement is required, see an INFINITI retailer for servicing. Iridium-tipped spark plugs GUID-ABA7DB7D-1A21-4B85-B69C-EE7F4C61EADF It is not necessary to replace the iridiumtipped spark plugs as frequently as the conventional type spark plugs since they will last much longer.
(467,1) WINDSHIELD WIPER BLADES GUID-A37555B3-A7CF-470C-A82F-6EB00C4A167F wipe the inside of the air cleaner housing and the cover with a damp cloth. WARNING . . Operating the engine with the air cleaner removed can cause you or others to be burned. The air cleaner not only cleans the air, it stops flame if the engine backfires. If it isn’t there, and the engine backfires, you could be burned.
(468,1) SDI2359 REPLACINGGUID-CC33F076-5352-485A-B942-6483BE320C2B CAUTION Replace the wiper blades if they are worn. 1. Pull the wiper arm. A , and then 2. Push the release tab * move the wiper blade down the wiper 1 while pushing the release tab arm * to remove. . 3. Insert the new wiper blade onto the wiper arm until a click sounds. . 4. Rotate the wiper blade so the dimple is in the groove.
(469,1) REAR WINDOW WIPER BLADES GUID-649120FF-FDF1-4DE9-947A-89118AE5CBB4 Contact an INFINITI retailer if checking or replacement is required. BRAKES GUID-B4BBC954-08ED-4C93-8847-EF9C238168ED If the brakes do not operate properly, have the brakes checked by an INFINITI retailer. SELF-ADJUSTING BRAKES GUID-A78AA7B3-D599-4BB3-98D6-72D1452BE948 Your vehicle is equipped with self-adjusting brakes. The disc-type brakes self-adjust every time the brake pedal is applied.
(470,1) FUSES GUID-3EB9B00A-4215-4CA4-B686-FCBB27683237 1. Open the engine hood and remove the battery cover. 2. Remove the fuse/fusible link holder cover. 3. Remove the fuse with the fuse puller. SDI1479A ENGINE COMPARTMENT GUID-2567A0EE-46EB-453B-A8E4-EC8A4F7728D6 CAUTION Never use a fuse of a higher or lower amperage rating than that specified on the fuse box cover. This could damage the electrical system or cause a fire. If any electrical equipment does not operate, check for an open fuse.
(471,1) INTELLIGENT KEY BATTERY REPLACEMENT GUID-9FFA03F0-C83F-4B1D-9108-39826EA4E1EE CAUTION Be careful not to allow children to swallow the battery and removed parts. SDI2034 PASSENGERGUID-7BE21C6E-2FB4-4826-A46E-0409496E1464 COMPARTMENT CAUTION Never use a fuse of a higher or lower amperage rating than that specified on the fuse box cover. This could damage the electrical system or cause a fire. 2. Open the fuse box lid. 3. Remove the fuse with the fuse puller A . * 4.
(472,1) 5. Push the buttons two or three times to check its operation. See an INFINITI retailer if you need any assistance for replacement. FCC Notice: For USA: SPA1875 Replace the battery as follows: 1. Release the lock knob at the back of the Intelligent Key and remove the mechanical key. A 2. Insert a flat-blade screwdriver * B wrapped with a cloth into the slit * of the corner and twist it to separate the upper part from the lower part. SDI2285 3. Replace the battery with a new one.
(473,1) LIGHTS 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12. 13. 14. 15. GUID-291CD2E0-8289-4BC3-BECF-D76791F5156C 16. 17. 18. 19.
(474,1) HEADLIGHTS GUID-36F0AB26-21DD-4A1C-84D5-06F4EA057FB4 Replacing GUID-B9E8FCF7-3625-4F7A-8B7D-8F21B4367EB7 Fog may temporarily form inside the lens of the exterior lights in the rain or in a car wash. A temperature difference between the inside and the outside of the lens causes the fog. This is not a malfunction. If large drops of water collect inside the lens, contact an INFINITI retailer.
(475,1) EXTERIOR AND INTERIOR LIGHTS GUID-8AAA340C-465D-4E14-ACD2-28F3F2FB7DD3 Item Replacement procedures GUID-22006E72-6F91-466D-BA1A-ED0ABA7DA150 Wattage (W) Bulb No.
(476,1) SDI1500B SDI2030 Cargo light Map light SDI1679 SDI1839 SDI2031 Rear personal light Vanity mirror light 8-28 Maintenance and do-it-yourself Condition: [ Edit: 2015/ 6/ 12 Model: J50-D ]
(477,1) WHEELS AND TIRES GUID-32E73463-7DBE-43B0-9ABF-D8632B560633 If you have a flat tire, see “Flat tire” (P.6-3). TIRE PRESSURE GUID-2E2973B3-1F58-4E90-94BE-B397517A7184 Tire Pressure Monitoring System (TPMS) GUID-9CC8D220-8196-4362-9950-C494673884D4 This vehicle is equipped with the Tire Pressure Monitoring System (TPMS). It monitors tire pressure of all tires except the spare.
(478,1) at the specified level. . For additional information regarding tires, refer to “Important Tire Safety Information” (US) or “Tire Safety Information” (Canada) in the Warranty Information Booklet. SDI2703 Tire and Loading Information label GUID-45A97E94-F4F1-4D47-B7D4-863C0A39D3DE * 1 Seating capacity: The maximum number of occupants that can be seated in the vehicle. * 2 Vehicle load limit: See “Vehicle loading information” (P.9-12).
(479,1) ered COLD after the vehicle has been parked for 3 or more hours, or driven less than 1 mile (1.6 km) at moderate speeds. The recommended cold tire inflation is set by the manufacturer to provide the best balance of tire wear, vehicle handling, driveability, tire noise, etc., up to the vehicle’s GVWR. * 5 Tire size — see “Tire labeling” (P.8-33).
(480,1) SDI1949 Checking the tire pressure GUID-0E510B4C-5A57-43DD-B375-2BF4468D6DA6 1. Remove the valve stem cap from the tire. 2. P r e s s t h e p r e s s u r e g a u g e squarely onto the valve stem. Do not press too hard or force the valve stem sideways, or air will escape. If the hissing sound of air escaping from the tire is heard while checking the pressure, reposition the gauge to eliminate this leakage. 3. Remove the gauge. 4.
(481,1) 4. 5. 6. SDI1575 Example TIRE LABELING GUID-1315CF90-2235-421A-BA3D-3C92FBA7C3A3 Federal law requires tire manufacturers to place standardized information on the sidewall of all tires. This information identifies and describes the fundamental characteristics of the tire and also provides the tire identification number (TIN) for safety standard certification. The TIN can be used to identify the tire in case of a recall. SDI1606 * 1 Example Tire size (example: P215/60R16 94H) 1.
(482,1) SDI1607 * 2 Example TIN (Tire Identification Number) for a new tire (example: DOT XX XX XXX XXXX) 1. DOT: Abbreviation for the “Department of Transportation”. The symbol can be placed above, below or to the left or right of the Tire Identification Number. 2. Two-digit code: Manufacturer’s identification mark 3. Two-digit code: Tire size 4. Three-digit code: Tire type code (Optional) 5. Three-digit code: Date of Manufacture 6. Four numbers represent the week and year the tire was built.
(483,1) Intended Outboard Sidewall is (1) the sidewall that contains a whitewall, bears white lettering or bears manufacturer, brand and/or model name molding that is higher or deeper than the same molding on the other sidewall of the tire, or (2) the outward facing sidewall of an asymmetrical tire that has a particular side that must always face outward when mounted on a vehicle. TYPES OF TIRES GUID-ACC87B05-3863-431B-A812-CA6571A0EB69 WARNING . .
(484,1) TIRE CHAINS GUID-9B415C38-B945-4085-A67C-E611501D539F Use of tire chains may be prohibited according to location. Check the local laws before installing tire chains. When installing tire chains, make sure they are the proper size for the tires on your vehicle and are installed according to the chain manufacturer’s suggestions. Use only SAE Class S chains. Class “S” chains are used on vehicles with restricted tire to vehicle clearance.
(485,1) The wheel nuts must be kept tightened to the specification at all times. It is recommended that wheel nuts be tightened to the specification at each tire rotation interval. WARNING . After rotating the tires, check and adjust the tire pressure. . Retighten the wheel nuts when the vehicle has been driven for 600 miles (1,000 km) (also in cases of a flat tire, etc.). . Do not include the T-type spare tire or any other small size spare tire in the tire rotation. .
(486,1) Replacing wheels and tires GUID-27266141-6C17-4AC5-BD67-2552EEED79D9 When replacing a tire, use the same size, tread design, speed rating and load carrying capacity as originally equipped. (See “Specifications” (P.9-7) for recommended types and sizes of tires and wheels.) accident and personal injury. . WARNING . .
(487,1) All-Wheel Drive (AWD) models GUID-AC9D99CD-71D3-4E51-9256-4414AC4B0562 CAUTION . . Always use tires of the same type, size, brand, construction (bias, bias-belted or radial), and tread pattern on all four wheels. Failure to do so may result in a circumference difference between tires on the front and rear axles which will cause excessive tire wear and may damage the transmission, transfer case and differential gears. ONLY use spare tires specified for the AWD model.
(488,1) . Tire tread of the TEMPORARY USE ONLY spare tire will wear at a faster rate than the standard tire. Replace the spare tire as soon as the tread wear indicators appear. . Do not use the spare tire on other vehicles. . Do not use more than one spare tire at the same time. CAUTION . Do not use tire chains on a TEMPORARY USE ONLY spare tire. Tire chains will not fit properly and may cause damage to the vehicle. .
(489,1) 9 Technical and consumer information Capacities and recommended fluids/lubricants.... ... 9-2 Fuel information .............................................. ... 9-3 Engine oil and oil filter recommendation ......... ... 9-5 Air conditioning system refrigerant and lubricant recommendations ............................. ... 9-6 Specifications...................................................... ... 9-7 Engine ............................................................ ... 9-7 Wheels and tires ....
(490,1) CAPACITIES AND RECOMMENDED FLUIDS/ LUBRICANTS GUID-B7F1B3E4-4805-446C-BA09-882A8B6534AE The following are approximate capacities. The actual refill capacities may be a little different. When refilling, follow the procedure instructed in the “8. Maintenance and do-it-yourself” section to determine the proper refill capacity. Fluid type Capacity (Approximate) US measure Imp measure 20 gal 16-5/8 gal Fuel Recommended specifications Liter 76 . See “Fuel information” (P.9-3).
(491,1) FUEL INFORMATION GUID-B1ED9AC6-0900-4A78-BC9C-5651942113E7 Use unleaded premium gasoline with an octane rating of at least 91 AKI (Anti-Knock Index) number (Research octane number 96). damage the three-way catalyst. Gasoline specifications GUID-2DC86A18-DBCC-43CE-B5AB-6E82BC6CB234 . Do not use E-15 or E-85 fuel in your vehicle. Your vehicle is not designed to run on E-15 or E-85 fuel.
(492,1) please take the following precautions as the usage of such fuels may cause vehicle performance problems and/or fuel system damage. . The fuel should be unleaded and have an octane rating no lower than that recommended for unleaded gasoline. . If an oxygenate-blend, excepting a methanol blend, is used, it should contain no more than 10% oxygenate. (MTBE may, however, be added up to 15%.) . E-15 fuel contains more than 10% oxygenate.
(493,1) Octane rating tips GUID-4D085589-81ED-499D-9F14-D3BD8B8AF9DF Using unleaded gasoline with an octane rating lower than recommended above can cause persistent, heavy spark knock. (Spark knock is a metallic rapping noise.) If severe, this can lead to engine damage. If you detect a persistent heavy spark knock even when using gasoline of the stated octane rating, or if you hear steady spark knock while holding a steady speed on level roads, have an INFINITI retailer correct the condition.
(494,1) Oil which may contain foreign matter or has been previously used should not be used. filter quality and/or viscosity is not covered by the new INFINITI vehicle limited warranties. Oil viscosityGUID-77F9E284-28E9-463C-B950-9F5EE57C9710 Your engine was filled with a high quality engine oil when it was built. You do not have to change the oil before the first recommended change interval. Oil and filter change intervals depend upon how you use your vehicle.
(495,1) SPECIFICATIONS GUID-AF123535-077E-4954-B40D-7B7867FA3FF2 ENGINE GUID-E2721A7A-A52A-49AD-8B0F-74CF80798DE3 Model VQ37VHR Type Gasoline, 4-cycle 6-cylinder, V-slanted at 608 3.760 6 3.385 (95.5 6 86.0) 225.54 (3,696) 1-2-3-4-5-6 Cylinder arrangement Bore 6 Stroke in (mm) Displacement Firing order cu in (cm3) Idle speed Ignition timing (B.T.D.C.) rpm Spark plug Standard FXE24HR-11 Spark plug gap (Normal) in (mm) 0.043 (1.
(496,1) WHEELS AND TIRES GUID-156A4A86-2C83-4FAF-83B4-86E6214B2D57 Road wheelGUID-FA2A9FD7-D8C5-43A8-9CA5-43D06AB3D9A4 Type Size Offset in (mm) 18 6 8J Conventional 1.85 (47) 19 6 8J 17 6 4T Spare Tire 1.
(497,1) WHEN TRAVELING OR REGISTERING IN ANOTHER COUNTRY GUID-4F85AFE9-A53D-415A-A8B9-CABE556010A7 VEHICLE IDENTIFICATION GUID-E633176C-80BE-431A-966D-A3B2BE9638EA If you plan to travel in another country, you should first find out if the fuel available is suitable for your vehicle’s engine. Using fuel with too low an octane rating may cause engine damage. All gasoline vehicles must be operated with unleaded gasoline. Therefore, avoid taking your vehicle to areas where appropriate fuel is not available.
(498,1) STI0509 ENGINE SERIAL NUMBER GUID-ECC32CF8-AB9D-49B6-8673-A299713870E8 The number is stamped on the engine as shown. STI0493 F.M.V.S.S./C.M.V.S.S. CERTIFICATION LABELGUID-924DD608-E217-44EA-9F95-0DE84D29E5AA The Federal/Canadian Motor Vehicle Safety Standards (F.M.V.S.S./C.M.V.S.S.) certification label is affixed as shown.
(499,1) INSTALLING FRONT LICENSE PLATE GUID-BA7A7E2B-FED9-4B05-95A2-63F0F924904F STI0567 TIRE AND LOADING INFORMATION LABEL GUID-5560E6CE-0473-4838-8716-5DCDF0EF1759 The cold tire pressure is shown on the Tire and Loading Information label affixed to the pillar as illustrated. JVT0407X STI0495 AIR CONDITIONER SPECIFICATION LABEL GUID-26756EE6-382F-4B8B-8561-150FCAF0E8CD The air conditioner specification label is attached as shown.
(500,1) VEHICLE LOADING INFORMATION GUID-18653710-1214-4878-BD7C-98ECC07D66CA WARNING . It is extremely dangerous to ride in a cargo area inside the vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed. . Do not allow people to ride in any area of vehicle that is not equipped with seats and seat belts. . Be sure everyone in your vehicle is in a seat and using a seat belt properly.
(501,1) STI0365 VEHICLE LOAD CAPACITY GUID-6B30F71E-CCCD-42A5-93C6-95AD0B91DCBE Do not exceed the load limit of your vehicle shown as “The combined weight of occupants and cargo” on the Tire and Loading Information label. Do not exceed the number of occupants shown as “Seating Capacity” on the Tire and Loading Information label. To get “the combined weight of occupants and cargo”, add the weight of all occupants, then add Condition: the total luggage weight. Examples are shown in the illustration.
(502,1) cargo and luggage load capacity of your vehicle. Before driving a loaded vehicle, confirm that you do not exceed the Gross Vehicle Weight Rating (GVWR) or the Gross Axle Weight Rating (GAWR) for your vehicle. (See “Measurement of weights” (P.9-14).) Also check tires for proper inflation pressures. See the Tire and Loading Information label. LOADING TIPS GUID-95340E9C-C2F7-4446-AC3D-82107148AB45 . The GVW must not exceed GVWR or GAWR as specified on the F.M.V. S.S./C.M.V.S.S. certification label. .
(503,1) TOWING A TRAILER UNIFORM TIRE QUALITY GRADING GUID-DA0DE293-1C52-4CDF-8C9C-0B9CB98EED8B GUID-C48839AE-6BDD-41E8-A04F-DC1947F88599 Do not tow a trailer with your vehicle. DOT (Department Of Transportation) Quality Grades: All passenger car tires must conform to federal safety requirements in addition to these grades. FLAT TOWING GUID-D5642553-EB9C-4F05-970D-4770E8C563C0 Towing your vehicle with all four wheels on the ground is sometimes called flat towing.
(504,1) EMISSION CONTROL SYSTEM WARRANTY GUID-5CF09C37-7F18-4845-843E-7BE97156D2EC TRACTION AA, A, B AND C GUID-11E202BE-8709-41D2-AB2D-8DF54B60782B The traction grades, from highest to lowest, are AA, A, B and C. Those grades represent the tire’s ability to stop on wet pavement as measured under controlled conditions on specified government test surfaces of asphalt and concrete. A tire marked C may have poor traction performance.
(505,1) REPORTING SAFETY DEFECTS GUID-6AC517C5-1F85-4627-8E4E-976C99F3B7A4 . Nissan Canada Inc. 5290 Orbitor Drive Mississauga, Ontario, L4W 4Z5 For USA If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying INFINITI.
(506,1) READINESS FOR INSPECTION/ MAINTENANCE (I/M) TEST GUID-C0D3B30B-8808-40FC-9140-F3FC65694121 defects online at: https://wwwapps.tc.gc.ca/Saf-SecSur/7/ PCDB-BDPP/Index.aspx. Additional information concerning motor vehicle safety may be obtained from Transport Canada’s Road Safety Information Centre at 1-800-3330371 or online at www.tc.gc.ca/roadsafety (English speakers) or www.tc. gc.ca/securiteroutiere (French speakers).
(507,1) OWNER’S MANUAL/SERVICE MANUAL ORDER INFORMATION EVENT DATA RECORDERS (EDR) GUID-00421227-094B-4488-927F-5F574CFEA15A This vehicle is equipped with an Event Data Recorder (EDR). The main purpose of an EDR is to record, in certain crash or near crash-like situations, such as an air bag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle’s systems performed.
(508,1) MEMO 9-20 Technical and consumer information Condition: [ Edit: 2015/ 6/ 12 Model: J50-D ]
(509,1) MEMO Technical and consumer information Condition: [ Edit: 2015/ 6/ 12 Model: J50-D ] 9-21
(510,1) MEMO 9-22 Technical and consumer information Condition: [ Edit: 2015/ 6/ 12 Model: J50-D ]
(511,1) 10 Index A ABS (Anti-lock Braking System) ....................... ... 5-100 Adaptive front lighting system (AFS) .................. ... 2-37 Advanced air bag system .................................. ... 1-47 Aiming control, Adaptive front lighting system (AFS) ..................................................... ... 2-37 Air bag system Advanced air bag system ............................ ... 1-47 Front passenger air bag and status light ..... ...
(512,1) Cargo cover ...................................................... ... 2-49 Cargo light ........................................................ ... 2-58 Catalytic converter, Three way catalyst ................ ... 5-4 CD/CF/USB memory care and cleaning .............. ... 4-95 Center multi-function control panel ..................... ... 4-3 Checking lights/instrument panel ..................... ... 2-10 Child restraints ................................................. ... 1-21 Booster seats .....
(513,1) Starting the engine ..................................... ... 5-14 Entry/exit function, Automatic drive positioner ................................................ ... 3-25 Event Data Recorders (EDR) ............................... ... 9-19 Exhaust gas (carbon monoxide) .......................... ... 5-4 F F.M.V.S.S./C.M.V.S.S. certification label ............. ... 9-10 Filter Air cleaner housing filter ............................. ... 8-18 Changing engine oil and filter ..................... ...
(514,1) Vehicle information display ......................... ... 2-20 INFINITI Vehicle Immobilizer System .................. ... 2-30 INFINITI voice recognition system .................... ... 4-124 INFO button ........................................................ ... 4-9 Inside mirror ..................................................... ... 3-22 Inspection/maintenance (I/M) test .................... ... 9-18 Instrument brightness control ........................... ... 2-38 Instrument panel .........
(515,1) Low washer fluid warning ................................. ... 2-23 Luggage hooks ................................................. ... 2-48 M Maintenance Battery ........................................................ ... 8-15 General maintenance .................................... ... 8-2 Indicators for maintenance ......................... ... 2-24 Inside the vehicle ......................................... ... 8-3 Maintenance precautions .............................. ...
(516,1) Push-button ignition switch ..................... ... 5-10, 5-11 S R Safety, Child seat belts ..................................... ... 1-18 Satellite radio operation ................................... ... 4-76 Seat adjustment Front power seat adjustment ......................... ... 1-3 Front seats ................................................... ... 1-3 Seat belt(s) Child safety ................................................ ... 1-18 Infants ..............................................
(517,1) Tilting telescopic steering column ................ ... 3-20 Storage ............................................................. ... 2-45 Sun visors ........................................................ ... 3-21 Sunglasses holder ............................................ ... 2-46 Supplemental air bag warning labels ................ ... 1-55 Supplemental air bag warning light ......... ... 1-55, 2-16 Supplemental restraint system .......................... ...
(518,1) Voice command (Bluetooth® Hands-Free Phone System) ................................................ ... Voice command (INFINITI voice recognition system) ............................. ... 4-130, Voice recognition system ................................ ... Voice recognition, Alternate command mode ... Voice recognition, Standard mode ................... ... 4-116 4-138 4-124 4-136 4-124 W Warning Hazard warning flasher switch ...................... ... 6-2 Lights .................................
(519,1) MEMO 10-9 Condition: [ Edit: 2015/ 6/ 12 Model: J50-D ]
(521,1) 11 Gas station information GAS STATION INFORMATION GUID-C63456DA-B5C6-4D61-8C3D-DA604EE5FE35 FUEL INFORMATION: GUID-7D216F09-8C16-40A9-AA84-99793D29E3B5 Use unleaded premium gasoline with an octane rating of at least 91 AKI (Anti-Knock Index) number (Research octane number 96). . Under no circumstances should a leaded gasoline be used, because this will damage the three-way catalyst. . Do not use E-15 or E-85 fuel in your vehicle. Your vehicle is not designed to run on E-15 or E-85 fuel.
Printing: November 2015 (18) / OM16E0 0J50U1 / Printed in U.S.A. 2016 Infiniti QX50 For your safety, read carefully and keep in this vehicle.
