Specifications
Infinity Systems, 250 Crossways Park Drive, Woodbury, NY 11797 USA
www.infinitysystems.com
© 2007 Harman International Industries, Incorporated. All rights reserved. Part No. REFAMPOM1/07
Infinity is a trademark of Harman International Industries, Incorporated, registered in the United States and/or other countries.
Declaration of Conformity
We, Harman Consumer Group International
2, route de Tours
72500 Château du Loir
France
declare in own responsibility that the products described in this
owner
’
s manual are in compliance with technical standards:
EN 55013:2001
EN 55020:2002
Klaus Lebherz
Harman Consumer Group International
Château du Loir, France 1/07
SPECIFICATIONS
4
75a
• 75W RMS x 4 channels at 4 ohms and ≤ 1% THD + N
• Signal-to-noise ratio: 85dBA (reference 1W into 4 ohms)
• 90W RMS x 4 channels at 2 ohms, 14.4V supply and ≤ 1% THD + N
• Dynamic power: 117W at 2 ohms
• Effective damping factor: 6.3 at 4 ohms
• Frequency response: 10Hz – 100kHz (–3dB)
• Maximum input signal: 6V
• Maximum sensitivity: 100mV
• Output regulation: 0.21dB at 4 ohms
• Dimensions (L x W x H): 14-3/16" x 9" x 2-11/16" (361mm x 229mm x 69mm)
• Fuse rating: 2 x 35A
• Included:
4 mounting screws, 2 spare 35A fuses, owner’s manual, warranty card
1300a
• 200W RMS x 1 channel at 4 ohms and ≤ 1% THD + N
• Signal-to-noise ratio: 85dBA (reference 1W into 4 ohms)
• 300W RMS x 1 channel at 2 ohms, 14.4V supply and ≤ 1% THD + N
• Dynamic power: 342W at 2 ohms
• Effective damping factor: 6.364 at 4 ohms
• Frequency response: 11Hz – 330Hz (–3dB)
• Maximum input signal: 6V
• Maximum sensitivity: 100mV
• Output regulation: 0.11dB at 4 ohms
• Dimensions (L x W x H): 14-3/16" x 9" x 2-11/16" (361mm x 229mm x 69mm)
• Fuse rating: 3 x 20A
• Included:
4 mounting screws, 3 spare 20A fuses, 1 remote level control,
1 remote level control cable (RJ11), owner’s manual, warranty card
5
350a
• 50W RMS x 4 channels plus 150W RMS x 1 channel at 4 ohms and ≤ 1% THD + N
• Signal-to-noise ratio: 85dBA (reference 1W into 4 ohms)
• 60W RMS x 4 channels plus 300W RMS x 1 channel at 2 ohms, 14.4V supply and ≤1% THD + N
• Dynamic power: 89W x 4 and 332W x 1 at 2 ohms
• Effective damping factor: 6.3 at 4 ohms
• Frequency response: 10Hz – 100kHz (–3dB)
• Maximum input signal: 6V
• Maximum sensitivity: 100mV
• Output regulation: 0.12dB at 4 ohms
• Dimensions (L x W x H): 16-9/16" x 9" x 2-11/16" (421mm x 229mm x 69mm)
• Fuse rating: 2 x 40A
• Included:
4 mounting screws, 2 spare 40A fuses, 1 remote level control,
1 remote level control cable (RJ11), owner’s manual, warranty card
1600a
• 400W RMS x 1 channel at 4 ohms and ≤ 1% THD + N
• Signal-to-noise ratio: 80dBA (reference 1W into 4 ohms)
• 600W RMS x 1 channel at 2 ohms, 14.4V supply and ≤ 1% THD + N
• Dynamic power: 894W at 2 ohms
• Effective damping factor: 6.3 at 4 ohms
• Frequency response: 11Hz – 330Hz (–3dB)
• Maximum input signal: 6V
• Maximum sensitivity: 100mV
• Output regulation: 0.12dB at 4 ohms
• Dimensions (L x W x H): 14-3/16" x 9" x 2-11/16" (361mm x 229mm x 69mm)
• Fuse rating: 3 x 25A
• Included:
4 mounting screws, 3 spare 25A fuses, 1 remote level control,
1 remote level control cable (RJ11), owner’s manual, warranty card
A valid serial number is required for warranty coverage.
Featur
es, specifications and appearance ar
e subject to change without notice.
These products are designed for mobile applications and are not intended for connection to the mains.
