Views of Projector Parts
Front-right View
1 34 5 6 72
ITEM LABEL DESCRIPTION SEE PAGE:
1.
Height-adjuster button Push to release height adjuster
2.
Height adjuster Adjust level of projector
12
3.
Lens Projection Lens
4.
IR receiver Receive IR signal from remote control
6
5.
Focus ring Focus the projected image
6.
Zoom ring Enlarge the projected image
13
7.
Function keys
See
Top view—On-screen Display (OSD) buttons
and LEDs
.
3
Important:
Ventilation openings on the projector allow for good air circulation, which keeps the projector lamp
cool. Do not obstruct any of the ventilation openings.
