Installation Manual

Part number IS1200

2002-06 Subaru WRX 2.0L

Recommended for Turbo upgrades

2004-07 Subaru STi 2.5L STi

1- Injen Intake (SR)

1- 3” Injen filter (#1014)

1- 2 7/8” Straight hose (#3050)

2- Power-Bands (.048)(.362) (#4004)

1- 3 Page instruction

Note: Use only Injen replacement

parts when making any changes

to this intake system.

Parts and accessories are now

available on-line at:

“injenonline.com”

Congratulations! You have just purchased the best engineered,

dyno-proven air intake system available.

Please check the contents of this box immediately.

Report any defective or missing parts to the Authorized Injen

Technology dealer you purchased this product from.

Before installing any parts of this system, please read the instructions

thoroughly. If you have any questions regarding installation please

contact the dealer you purchased this product from.

Installation DOES require some mechanical skills. A qualified

mechanic is always recommended.

*Do not attempt to install the intake system while the engine is hot.

The installation may require removal of radiator fluid line that may

be hot.

Injen Technology offers a limited lifetime warranty to the original

purchaser against defects in materials and workmanship. Warranty

claims must be handled through the dealer from which the item was

purchased.

Injen Technology 244 Pioneer Place Pomona, CA 91768 USA

Please check the contents of this box immediately.

Note: This intake system was Dyno-tested with an Injen filter and

Injen parts the use of any other filter or part will void the

warranty and CARB exemption number.

Parts and accessories are available on line at “Injenonline.com”

Figure 1

Note: The last page shows a list of after market products now available and made by Injen Technology.

All parts are made to be straight bolt-on products that give you added power and performance. For

Dyno-graphs be sure to log on to www.injen.com.

PAGE 1
Part number IS1200 2002-06 Subaru WRX 2.0L Recommended for Turbo upgrades 2004-07 Subaru STi 2.5L STi 1- Injen Intake 1- 3” Injen filter 1- 2 7/8” Straight hose 2- Power-Bands (.048)(.362) 1- 3 Page instruction (SR) (#1014) (#3050) (#4004) Note: Use only Injen replacement parts when making any changes to this intake system. Parts and accessories are now available on-line at: “injenonline.com” Congratulations! You have just purchased the best engineered, dyno-proven air intake system available.
PAGE 2
Figure 2 Figure 3 Take the short ram intake system and air filter and assemble them together. Press the filter over the 3” side of the intake and tighten the clamp on the filter neck. The stock air intake box and air intake duct has been removed from the engine compartment. (B) >> >> (A) Figure 4 Figure 5 Press the 2 7/8” straight hose over the throttle body and use two clamps but only tighten the clamp on the throttle body. >> Remove this m6 nut where the bracket on the intake will be located(A).
PAGE 3
Figure 10 Figure 11 Press the harness clip into the mass air flow sensor until you hear it snap firmly in place. Congratulations! The installation is now complete. 1. Once the installation is complete, reconnect the negative battery terminal before you start the engine. 2. Align the entire intake system for the best possible fit. Once the intake has been properly fitted continue to tighten all nuts, bolts and clamps. 3.
