User Guide 5 MP High Definition Digital Camcorder with 3.
Insignia NS-DCC5HB09 5 MP High Definition Digital Camcorder with 3.0" LCD Monitor Contents Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Insignia NS-DCC5HB09 5 MP High Definition Digital Camcorder with 3.0" LCD Monitor Setting the time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24 Displaying or hiding camcorder status information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25 Turning sound effects on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Insignia NS-DCC5HB09 5 MP High Definition Digital Camcorder with 3.0" LCD Monitor Safety information • • • • • • • • • • Front Do not drop, puncture, or disassemble your camcorder. This voids your warranty. Avoid contact with water, and make sure that your hands are dry before using your camcorder. Do not expose your camcorder to high temperature or leave it in direct sunlight. High temperature or the heat from direct sunlight may damage your camcorder.
Insignia NS-DCC5HB09 5 MP High Definition Digital Camcorder with 3.0" LCD Monitor Back Side 1 2 1 3 4 OK 5 6 7 8 9 2 TV 10 # 1 2 Component Description Movie shutter button Press to record a movie. For more information, see “Recording a movie” on page 6. Picture shutter button Press to take a picture. For more information, see “Taking a picture” on page 6. 3 T (up) button In record mode, press to zoom in. In menu mode, press to move up or to make selections.
Insignia NS-DCC5HB09 5 MP High Definition Digital Camcorder with 3.0" LCD Monitor Setting up your camcorder Record mode icons Photo Frame mode Installing the battery Multi-Snap mode To install the battery: 1 Slide the battery cover off your camcorder. Night mode Backlight mode LCD icons # Icon 1 Number of images that can still be taken at the current resolution.
Insignia NS-DCC5HB09 5 MP High Definition Digital Camcorder with 3.0" LCD Monitor To remove a memory card: 1 Slide the battery cover off of your camcorder. 2 Push in on the memory card. The card pops out slightly. 3 Pull the card out of the slot. 4 Replace the battery cover. 2 Rotate the LCD panel 90° counter-clockwise so you can view pictures and movies. Protecting an SD memory card OK You can “protect” an SD memory card to prevent the recording or deletion of pictures or movies.
Insignia NS-DCC5HB09 5 MP High Definition Digital Camcorder with 3.0" LCD Monitor Recording sound To record sound: 1 Press OK to open the record menu. 5 Press T (up) or W (down) to select HD, D1, VGA, or QVGA, then press OK to save your selection and close the menu. To exit without changing the resolution, select Exit or press (Record/Play). Using digital zoom You can zoom on scenes to get close up when recording movies movies.The zoom selection are from 1× to 8×.
Insignia NS-DCC5HB09 5 MP High Definition Digital Camcorder with 3.0" LCD Monitor 3 Press or to select Movie Mode. 4 Press T (up) or W (down) to select Light, then press OK. 4 Press T (up) or W (down) to select Night Mode, then press OK. 5 Press T (up) or W (down) to select On or Off, then press OK to save your selection and close the menu. Adjusting the sharpness for movies You can use the sharpness to soften or sharpen images to achieve different effects.
Insignia NS-DCC5HB09 5 MP High Definition Digital Camcorder with 3.0" LCD Monitor Adjusting the white balance for movies 3 Press or to select Movie Mode. You camcorder adjusts the color balance automatically. You can manually adjust the color balance for special movie effects. To adjust the white balance for movies: 1 Press (Record/Play) to switch to record mode. 2 Press OK. The record menu opens. 3 Press or to select Movie Mode. 4 Press T (up) or W (down) to select Stabilization, then press OK.
Insignia NS-DCC5HB09 5 MP High Definition Digital Camcorder with 3.0" LCD Monitor 4 Press T (up) or W (down) to select Motion Detect, then press OK. 5 Press T (up) or W (down) to select On or Off, then press OK to save your selection and close the menu. Selecting an effect for movies You can select a visual effect for movies. To select an effect for movies: 1 Press (Record/Play) to switch to record mode. 2 Press OK. The record menu opens. 3 Press or to select Effect. 3 Press OK.
Insignia NS-DCC5HB09 5 MP High Definition Digital Camcorder with 3.0" LCD Monitor 4 Press or Using movie thumbnails to select Delete. To use movie thumbnails: 1 Press (Record/Play) to switch to playback mode. 2 Press or to select Movie. 5 Press OK to open the delete menu. 3 Press OK twice to open the movie option menu. 6 Press or to select the movie you want to delete. 7 Press W (down) to delete the movie. If you want to delete all movies, press T (up). A confirmation message appears.
Insignia NS-DCC5HB09 5 MP High Definition Digital Camcorder with 3.0" LCD Monitor Locking or unlocking movies Repeating movies You can lock movies to prevent them from being deleted. You can play a single movie or all movies repeatedly. To lock or unlock movies: 1 Press (Record/Play) to switch to playback mode. 2 Press or to select Movie. To repeat movies: 1 Press (Record/Play) to switch to playback mode. 2 Press or to select Movie. 3 Press OK twice to open the movie option menu.
Insignia NS-DCC5HB09 5 MP High Definition Digital Camcorder with 3.0" LCD Monitor Watching movies on a PC Viewing pictures or movies on a non-HDTV To watch movies on a PC: 1 Connect the mini-USB cable to the USB port on your camcorder, then connect the other end to a USB port on a PC. 2 Start the computer’s video player, such as Windows Media Player. 3 Use the Windows Media Player controls to locate and play movies. Movies on a memory card are located at My Computer\Removable Disk\DCIM\200MOVIE.
Insignia NS-DCC5HB09 5 MP High Definition Digital Camcorder with 3.0" LCD Monitor To take close up pictures: 1 Slide the Macro switch to the Macro or Portrait position. 2 Press (Picture Shutter) to take the picture. Note Make sure that you set the Macro switch to (Normal) when you finish taking close-up pictures. Using digital zoom Selecting the exposure for pictures Your camcorder adjusts the image exposure automatically. You can manually adjust the exposure for special pictures.
Insignia NS-DCC5HB09 5 MP High Definition Digital Camcorder with 3.0" LCD Monitor 3 Press or to select Camera Mode. 4 Press T (up) or W (down) to select Night Mode, then press OK. 4 Press T (up) or W (down) to select Sharpness, then press OK. 5 Press T (up) or W (down) to select a sharpness level. The new sharpness setting is previewed. 6 Press OK to save your selection and close the menu. Adjusting the white balance for pictures You camcorder adjusts the color balance automatically.
Insignia NS-DCC5HB09 5 MP High Definition Digital Camcorder with 3.0" LCD Monitor Combining two pictures into one You can combine two pictures into one picture. 8 Press (Record/Play) to view the two-in-one picture. To combine two pictures into one: 1 Press (Record/Play) to switch to record mode. 2 Press OK. The record menu opens. 3 Press or to select Camera Mode. Adding photo frames to pictures 1 Press (Record/Play) to switch to record mode. 2 Press OK. The record menu opens.
Insignia NS-DCC5HB09 5 MP High Definition Digital Camcorder with 3.0" LCD Monitor Selecting the flash setting for pictures Your camcorder has four flash settings. The flash setting icon appears on the LCD. A Auto-flash—The flash fires automatically depending on the light conditions. Use this mode for general photography. On—The flash fires for every picture. Off—Use this mode when flash photography is prohibited or when the subject is beyond the range of the flash.
Insignia NS-DCC5HB09 5 MP High Definition Digital Camcorder with 3.0" LCD Monitor Adding the date to pictures 4 Press T (up) or W (down) to select Multi-snap, then press OK. When the Date Printing option is turned on, your camcorder adds the date to each picture you take. The date appears on pictures when you print them. 1 Press (Record/Play) to switch to record mode. 2 Press OK. The record menu opens. 3 Press or to select Camera Mode.
Insignia NS-DCC5HB09 5 MP High Definition Digital Camcorder with 3.0" LCD Monitor 3 Press or Deleting pictures to select Effect. Note If a memory card is in your camcorder, you can only delete pictures on the card. To delete pictures stored in built-in memory, remove the card. For instructions for removing a card, see “Inserting or removing a memory card” on page 5. If a memory card is protected, you cannot delete pictures from the card.
Insignia NS-DCC5HB09 5 MP High Definition Digital Camcorder with 3.0" LCD Monitor 6 Press W (down) to delete the picture. If you want to delete all pictures, press T (up). A confirmation message appears. 7 Press T (up) or W (down) to select Yes. If you want to cancel the deletion, select No. 8 Press OK to complete the deletion. Using picture thumbnails To use movie thumbnails: 1 Press (Record/Play) to switch to playback mode. 2 Press or to select Picture.
Insignia NS-DCC5HB09 5 MP High Definition Digital Camcorder with 3.0" LCD Monitor Working with voice recordings 5 Press OK to open the lock menu. Playing voice recordings To play voice recordings: 1 Press (Record/Play) to switch to playback mode. 2 Press or to select Voice. 6 Press or to select the picture you want to lock or unlock. 7 Press W (down) to lock or unlock the picture. If you want to lock or unlock all movies, press T (up). A confirmation message appears.
Insignia NS-DCC5HB09 5 MP High Definition Digital Camcorder with 3.0" LCD Monitor Deleting voice recordings 22 Repeating voice recordings To delete voice recordings: 1 Press (Record/Play) to switch to playback mode. 2 Press or to select Voice. To repeat voice recordings: 1 Press (Record/Play) to switch to playback mode. 2 Press or to select Voice. 3 Press OK to go to voice playback mode. 3 Press OK to go to voice playback mode. 4 Press or to select the recording you want to delete.
Insignia NS-DCC5HB09 5 MP High Definition Digital Camcorder with 3.0" LCD Monitor Transferring MP3s to your camcorder To transfer MP3s to your camcorder: 1 Connect the mini-USB cable to the USB port on your camcorder, then connect the other end to a USB port on a PC. The red LED lights when your camcorder is connected to the PC, and your camcorder is in Mass Storage mode. 2 Make sure that you have a memory card with enough memory inserted into your camcorder.
Insignia NS-DCC5HB09 5 MP High Definition Digital Camcorder with 3.0" LCD Monitor Using an earphone Setting the time You can use an earphone to listen to MP3s. To use an earphone: 1 Plug an earphone into the earphone jack on your camcorder. A menu pops up. 2 When the earphone/TV menu opens, press T or W to select . To set the time: 1 In record mode, press OK to open the record menu. 2 Press or to select Setting. The Setting menu opens. 3 Press OK to close the menu.
Insignia NS-DCC5HB09 5 MP High Definition Digital Camcorder with 3.0" LCD Monitor Displaying or hiding camcorder status information To display or hide camcorder status information: 1 In record mode, press OK to open the record menu. 2 Press or to select Setting. The Setting menu opens. 3 Press T (up) or W (down) to select Display, then press OK. The Display menu opens.
Insignia NS-DCC5HB09 5 MP High Definition Digital Camcorder with 3.0" LCD Monitor 3 Press or to select Setting. The Setting menu opens. Selecting the TV system type When you connect a TV, make sure that the correct TV system type is selected. If you select the wrong TV system type, the image may flicker. NTSC is the system type for U.S.A., Canada, and Mexico. To select the TV system type: 1 In record mode, press OK to open the record menu. 2 Press or to select Setting. The Setting menu opens.
Insignia NS-DCC5HB09 5 MP High Definition Digital Camcorder with 3.0" LCD Monitor Selecting the on-screen menu language 3 Press T (up) or W (down) to select Default Setting. The Default Setting menu opens. To select the on-screen menu language: 1 In record mode, press OK to open the record menu. 2 Press or to select Setting. The Setting menu opens. 4 Press T (up) or W (down) to select Yes. If you want to cancel the restoration, select No. 5 Press OK to restore settings and close the menu.
Insignia NS-DCC5HB09 5 MP High Definition Digital Camcorder with 3.0" LCD Monitor Troubleshooting Problem Solution Image Resolution • 3744 × 2808 (11M pixels) • 2592 × 1944 (5M pixels) • 1600 × 1200 (2M pixels) Movie Resolution • • • • HD: 1280 × 720 pixels 30 fps D1: 720 × 480 pixels 30 fps VGA: 640 × 480 pixels 30 fps QVGA: 320 × 240 pixels 30 fps The image on the LCD is not Try switching between Macro clear. mode, Portrait mode, or Normal mode to adjust the focus.
Insignia NS-DCC5HB09 5 MP High Definition Digital Camcorder with 3.0" LCD Monitor Legal notices FCC Part 15 This device complies with Part 15 of the FCC Rules. Operation of this product is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Insignia NS-DCC5HB09 5 MP High Definition Digital Camcorder with 3.0" LCD Monitor 30 www.insignia-products.
Insignia NS-DCC5HB09 5 MP High Definition Digital Camcorder with 3.0" LCD Monitor One-Year Limited Warranty Insignia Products (“Insignia”) warrants to you, the original purchaser of this new NS-DCC5HB09 (“Product”), that the Product shall be free of defects in the original manufacture of the material or workmanship for a period of one (1) year from the date of your purchase of the Product (“Warranty Period”).
TM www.insignia-products.com (877) 467-4289 Distributed by Best Buy Purchasing, LLC 7601 Penn Avenue South, Richfield, MN USA 55423-3645 © 2008 Best Buy Enterprise Services, Inc. All rights reserved. INSIGNIA is a trademark of Best Buy Enterprise Services, Inc. Registered in some countries. All other products and brand names are trademarks of their respective owners.
