Specifications Sheet

EX609-15F-64-37
InSinkErator Division
Suite 6, Building 6
Hatters Lane
Croxley Green Business Park
Watford HERTS WD18 8YH
United Kingdom
Sales Tel: [phone]
Service Tel: [phone]
www.insinkerator.co.uk
Category Benefits
• Food waste is ground into particles
and flushed away in seconds
• Clean, hygienic, convenient and
simple to use
• Easy method to manage food waste
in the home, saving you time and
helping to minimise trips to the
outside dustbin
• Permanent in-house solution that
is compact and sits under the sink
without taking up valuable storage
• Easy to install into new or existing
kitchens and can be fitted to
most sinks
• Environmentally responsible, helping
reduce the amount of waste that
goes to landfill sites
Features
• 1-stage grind technology
• High-torque Dura-Drive
®
induction motor
• 2 Year guarantee
• Standard grind chamber
• Continuous feed
• Overload protection
• Quick Lock
®
mounting
assembly for faster, easier
installation
• Air switch accessory available
Sample Specification
Food waste disposer(s) shall be InSinkErator
®
Model 46 with 1-stage grind
technology and .55 hp motor.
Guarantee: 2 Year parts and service.
The complete InSinkErator guarantee is included in the Care & Use Booklet packed with each unit.
Model 46
Specifications
Volts/Hz HP RPM Average Load
120V, 60 Hz .55 1725 7.1 A
220-240V, 50 Hz .55 1425 380 W
220-240V, 60 Hz .55 1725 380 W
Type of Feed Continuous
On/Off Control Wall Switch
Motor Single Phase
Time Rating Intermittent
Lubrication Permanently
Lubricated Upper
& Lower Bearings
Shipping Weight 7.7 kg
(Approx.)
Overall Height 318 mm
Grind Technology 1-Stage Grind Technology
Dimensions (mm)
Model 46
A
B
C
318
168
64
D
E
159
131
InSinkErator reserves the right to change product specifications
without prior notice. The disposer described in this leaflet
is for household use: usage in commercial situations is not
covered by warranty.
Grind Chamber 980 ml
Capacity
Motor Protection Manual Reset Overload
Average Water Approximately 4.0 L
Usage per Person per Day
Average Electrical 3-4 KWH per Annum
Usage
Drain Connection 1-1/2” (3.81 cm)
Dishwasher Drain Yes
Connection
The Emerson logo is a trademark and a service mark of Emerson Electric Co.
The mounting collar configuration is a trademark of Emerson Electric Co.
InSinkErator may make improvements and/or changes in the specifications
at any time, in its sole discretion, without notice or obligation and further
reserves the right to change or discontinue models.
© 2015 InSinkErator, InSinkErator® is a business unit of Emerson Electric Co.
All Rights Reserved.
