Specifications

Page 13 of 16 2342-232/2444A2WH4, 2342-432, 2342-532 Rev: 1/21/2014 7:14 AM
Fast-Off
Red Blink for ~3 Seconds
Scene Acknowledge Missing
LED
Always used for setup, default On during use
Setup Button
Yes
On/Off Switch
Yes
Beeper
Yes, configurable
Battery Charging LED
Yes, Embedded (shines red through case during charge)
RF Range
50’ Line-of-Sight
RF Frequency
915MHz (US)
869MHz (EU)
921MHz (AUS/NZ)
Retains all settings without power
Yes, all saved in Non-volatile EEPROM
Mechanical
Color
White
Plastic
UV Stabilized ABS
Dimensions
2.6" H x 1.3" W x 0.39" D
Weight
1 Oz.
Button Style
Plastic Paddles over Contact Switches
Optional Hardware
Wall Mount
Tabletop Stand
Visor Clip
Operating Environment
Indoors, 32°F to 104°F, up to 85% relative humidity
Electrical
Battery type
3.7 VDC Lithium Polymer, Rechargeable, non-replaceable
Battery life (between charges)
9-12 months under standard usage
Battery Re-charging cycles
> 500 recharging cycles
Recharging jack
Standard, Micro-USB, 5VDC
Recharging time
1 hour
Troubleshooting
Problem
Possible Cause
Solution
Mini Remote won’t add a
scene responder
Mini Remote may be out of range of
nearest dual-band INSTEON device
(hopper)
Try moving an access point or other dual-band
plug-in module closer to Mini Remote
The INSTEON signal may not be
getting to the “vicinity” of Responder
Make sure phases are bridged, add additional
INSTEON devices and/or move around existing
INSTEON devices
