DPS-6.7_En.book Page 1 Monday, July 31, 2006 3:12 PM Super Audio CD & DVD Audio/Video Player DPS-6.
DPS-6.7_En.book Page 2 Monday, July 31, 2006 3:12 PM WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
DPS-6.7_En.book Page 3 Monday, July 31, 2006 3:12 PM Precautions 1. Recording Copyright—Unless it’s for personal use only, recording copyrighted material is illegal without the permission of the copyright holder. 2. AC Fuse—The AC fuse inside the unit is not userserviceable. If you cannot turn on the unit, contact your Integra/Onkyo dealer. 3. Care—Occasionally you should dust the unit all over with a soft cloth.
DPS-6.7_En.book Page 4 Monday, July 31, 2006 3:12 PM Precautions—Continued 10. Region Numbers—The DVD standard uses region numbers to control how discs can be played around the world, the world being divided into six regions. This unit will only play DVD discs that match its region number, which can be found on its rear panel (e.g., 1 , ). 11. About this Manual—This manual explains how to use all of this unit’s functions.
DPS-6.7_En.book Page 5 Monday, July 31, 2006 3:12 PM Supplied Accessories Make sure you have the following accessories: RC-658DV Remote controller & 2 batteries (AA/R6) AV cable (RCA) (1.5 m) cable (1.8 m) This cable is used to connect the DVD player to other -compatible Integra/Onkyo components for (Remote Interactive) control. To use , in addition to an connection, you must make an analog audio connection (RCA) between the DVD player and your Integra/Onkyo AV receiver.
DPS-6.7_En.book Page 6 Monday, July 31, 2006 3:12 PM Contents Basic Operation Advanced Operation Overview Playback Techniques Important Safety Instructions...............................2 Precautions .........................................................3 Supplied Accessories ..........................................5 Introduction..........................................................8 Features ..........................................................8 Disc Notes ...............................
DPS-6.7_En.book Page 7 Monday, July 31, 2006 3:12 PM Contents—Continued Thank you for purchasing the Integra/ Onkyo DPS-6.7 Super Audio CD & DVD Audio/Video player. Read this manual carefully before using your new DVD player. A good understanding of its features and operation will allow you to achieve optimum performance and enjoyment. Keep this manual for future reference. Overview ..............................................2 Connections ......................................
DPS-6.7_En.book Page 8 Monday, July 31, 2006 3:12 PM Introduction Features Highlights • Dolby*1 Digital, DTS*2 • DVD-Video, Video CD, audio CD • MP3, WMA,*3 JPEG, DivX®*4 (not North American model) • DVD-Audio and Super Audio CD • CD-R/RW, DVD-R/RW, and DVD+R/RW compatible • HDMI*5 digital interface • 5.
DPS-6.7_En.book Page 9 Monday, July 31, 2006 3:12 PM Introduction—Continued Disc Notes Supported Discs The DVD player supports the following discs.
DPS-6.7_En.book Page 10 Monday, July 31, 2006 3:12 PM Introduction—Continued MP3/WMA/JPEG Compatibility About DivX • The DVD player can play/display MP3, WMA, and JPEG files recorded on CD-R, CD-RW, DVD-R, DVD-RW, DVD+R and DVD+RW discs. • Discs must be in ISO 9660 Level 2 or Joliet format (folders can be up to eight levels deep). Music files recorded on discs that use the HFS (hierarchical file system) cannot be played. • Discs must be finalized.
DPS-6.7_En.book Page 11 Monday, July 31, 2006 3:12 PM Introduction—Continued Handling Discs Copyright • Never touch the underside of a disc. Always hold discs by the edge, as shown. It is forbidden by law to copy, broadcast, show, broadcast on cable, play in public, or rent copyrighted material without permission. DVD-Video discs are copy-protected, and any recordings made from these discs will be distorted.
DPS-6.7_En.book Page 12 Monday, July 31, 2006 3:12 PM Before Using the DVD player Installing the Batteries 1 Open the battery compartment, as shown. Using the Remote Controller To use the remote controller, point it at the DVD player’s remote control sensor, as shown below. Remote control sensor DVD player ) 30˚ 2 3 Insert the two supplied batteries (AA/R6) in accordance with the polarity diagram inside the battery compartment. Close the battery compartment.
DPS-6.7_En.book Page 13 Monday, July 31, 2006 3:12 PM Front & Rear Panels For detailed information, refer to the pages in brackets. Front Panel 1 2 34 5 6 S R Q A Standby/On button [26] This button is used to set the DVD player to On or Standby. B Standby indicator [26] This indicator lights up when the DVD player is in Standby. C Resolution button [43] This button is used to select the video resolution for the HDMI output, and select progressive or interlaced scanning.
DPS-6.7_En.book Page 14 Monday, July 31, 2006 3:12 PM Front & Rear Panels—Continued Display 1 2 3 4 D E F G H 1 D PRO LOGIC indicator The D indicator appears when playing Dolby Digital material. The PRO LOGIC indicator appears when the DVD player’s Dolby Pro Logic decoder is on. 2 Disc type indicators These indicators show the type of disc loaded. 3 TITLE indicator While stopped, the total number of titles on the current DVD-Video disc is displayed here.
DPS-6.7_En.book Page 15 Monday, July 31, 2006 3:12 PM Front & Rear Panels—Continued Rear Panel 1 2 K 3 4 L A AUDIO OUTPUT [20, 22, 23] B C D E These jacks make up the multichannel analog audio output. The FRONT/D.MIX jacks can be connected to a stereo input on a TV, hi-fi amp, or other component. The 1 and 2 jacks output the same signals, so use either pair.
DPS-6.7_En.book Page 16 Monday, July 31, 2006 3:12 PM Front & Rear Panels—Continued Remote Controller A Standby button [26] This button is used to set the DVD player to Standby. B On button [26] 1 2 N This button is used to turn on the DVD player. Don’t turn on the DVD player until you’ve completed, and double checked all connections (pages 20–25).
DPS-6.7_En.book Page 17 Monday, July 31, 2006 3:12 PM Front & Rear Panels—Continued N Open/Close button [28] This button is used to open and close the disc tray. O Search button [34, 35] This button is used to search for titles, chapters, groups, folders, tracks, and specific points in time. P Memory button [38] This button is used with the Memory function. Q Repeat button [36] This button is used to set the Repeat function. R A-B button [36] This button is used to set the A-B Repeat function.
DPS-6.7_En.book Page 18 Monday, July 31, 2006 3:12 PM Connecting the DVD player AV Cables & Connectors Video Cable Jack Description HDMI connections can carry uncompressed, standard or high definition digital video and digital audio, for the best picture and sound quality. HDMI Y Component video Component video separates the luminance (Y) and color difference signals (PR, PB), providing the best picture quality. Some TV manufacturers label their component video inputs differently.
DPS-6.7_En.book Page 19 Monday, July 31, 2006 3:12 PM Connecting the DVD player—Continued Video Output/Video Setting Matrix The following matrix shows how the video outputs work in relation to the various video settings.
DPS-6.7_En.book Page 20 Monday, July 31, 2006 3:12 PM Connecting the DVD player—Continued Before Making Any Connections • Read the manuals supplied with your AV components. • Don’t connect the power cord until you’ve completed all audio and video connections. The supplied AV cable is made up of an analog audio cable and a composite video cable.
DPS-6.7_En.book Page 21 Monday, July 31, 2006 3:12 PM Connecting the DVD player—Continued Connecting Your TV (video only) • Connect the DVD player directly to your TV. If you connect the DVD player through a VCR, TV/VCR combination, or video selector, the picture may be distorted because DVD-Video discs are usually copy protected. Using S-Video If your TV (or other equipment) has an S-Video input, you can use this instead of the standard (composite) output for a better quality picture.
DPS-6.7_En.book Page 22 Monday, July 31, 2006 3:12 PM Connecting the DVD player—Continued Connecting to an AV Receiver Step 1: Audio Connection You can connect the DVD player to your AV receiver using the multichannel analog audio output or one of the digital audio outputs. In addition, you should also connect a 2-channel analog audio output for compatibility all certain discs. Connecting the Analog Output Connect the FRONT/D.
DPS-6.7_En.book Page 23 Monday, July 31, 2006 3:12 PM Connecting the DVD player—Continued Connecting the Multichannel Analog Output Connecting Components -compatible Connect the DVD player’s FRONT/D.MIX 1 or 2, SURR 1, CENTER, and SUBWOOFER jacks to the multichannel analog audio input on your AV receiver. You can use three stereo audio cables for this. FRONT/D. MIX REMOTE CONTROL 1 AUDIO OUTPUT ANALOG SURR1 CENTER 2 FRONT/D.
DPS-6.7_En.book Page 24 Monday, July 31, 2006 3:12 PM Connecting the DVD player—Continued Connecting your HDTV or AV receiver with an HDMI Input This section shows how to connect the DVD player to a AV receiver, HDTV, or projector that has an HDMI input socket. What is HDMI? HDMI (High Definition Multimedia Interface) is a new connection format that can carry uncompressed, standard or high definition digital video and digital audio.
DPS-6.7_En.book Page 25 Monday, July 31, 2006 3:12 PM Connecting the DVD player—Continued Using the Multiroom Control Kits To control the DVD player with the remote controller when DVD player is located in a cabinet, you’ll need a commercially available multiroom remote control kit. • Multiroom kits are made by Niles and Xantech. These kits can also be used when control other components.
DPS-6.7_En.book Page 26 Monday, July 31, 2006 3:12 PM Connecting the Power/Turning on the DVD player Before connecting • Make sure that all the connections on pages 18–25 are complete (the connection to a TV is required). • Before unplugging the player from the power outlet, make sure you first switch it into standby. • For the above reasons, do not plug this player into a switched power supply found on some amplifiers and AV receivers.
DPS-6.7_En.book Page 27 Monday, July 31, 2006 3:12 PM Initial Setup This chapter explains the settings you need to make the very first time the DVD player is turned on. 2 Remote controller Use the Up and Down [ ]/[ ] buttons to select “On” or “Off” for “HDMI Output Setting.” Select “On” to use the HDMI output.
DPS-6.7_En.book Page 28 Monday, July 31, 2006 3:12 PM Playing Discs This chapter covers basic playback. Advanced playback functions are covered in the next chapter. Important: • Throughout this manual, the term DVD refers to DVDVideo, DVD-Audio, DVD-R/RW, and DVD+R/RW discs. When a function is specific to a particular type of DVD disc, it will be specified. 3 Press Open/Close . The disc tray closes and the relevant disc type indicator appears on the display.
DPS-6.7_En.book Page 29 Monday, July 31, 2006 3:12 PM Playing Discs—Continued ■ Stop Remote controller To stop playback, press the Stop [ ] button. Playback stops and the Play indicator disappears. • When you stop playback of a DVD-Video disc or VCD, the DVD player remembers the point at which playback was stopped and “Resume” appears onscreen. To resume playback from that point, press the Play [ ] button. To cancel the Resume function, press the Stop [ ] button again.
DPS-6.7_En.book Page 30 Monday, July 31, 2006 3:12 PM Playing Discs—Continued Forward Frame-by-Frame Playback DVD-V Pause Slow Slow FR Play FF DVD-VR ■ Forward Press the Pause [ ] button. frame-by- Press it repeatedly to view subframe sequent frames. SACD DVD-VR VCD CD MP3 DivX The North American model does not support DivX. This section explains how to fast forward and reverse. ■ Fast forward Remote controller During playback, press the FF [ ] button to start fast forward.
DPS-6.7_En.book Page 31 Monday, July 31, 2006 3:12 PM Playing Discs—Continued Top Menu / / / , Enter / Menu Number buttons Down To set VCD’s PBC on and off PBC menus can turned on or off by pressing the [Top Menu] button. Up Enter / / Tep Menu / Menu Navigating DVD & VCD Disc Menus DVD-V DVD-A Notes: • Not all DVDs and VCDs have menus. • Menu operation varies from disc-to-disc. See the disc’s sleeve notes for details. • On some DVDs, to display the disc menu, press the [Menu] button.
DPS-6.7_En.book Page 32 Monday, July 31, 2006 3:12 PM Playing Discs—Continued 3 Remote controller Play Enter / / / Return 4 Remote controller Navigating MP3, WMA & DivX Discs MP3 WMA DivX or The North American model does not support DivX. This section explains how to play MP3, WMA, and DivX files with the Disc Navigator. 1 Load an MP3, WMA, or DivX disc. The Disc Navigator appears. Stop Disc DATA 1/3 -/5 /mp3 001. ROOT Repeat 002. mp3 Random 003. MP3 music 001. Track01 002. Track02 003.
DPS-6.7_En.book Page 33 Monday, July 31, 2006 3:12 PM Playing Discs—Continued Viewing a Slideshow of JPEG Images Use the Left and Right [ ]/[ ] buttons to display other folders that contain JPEG images. JPEG This section explains how to display a slideshow of JPEG images on your TV. 1 4 Remote controller Load a JPEG disc. The Disc Navigator appears. Disc DATA Stop 1/17 -//jpg 001. jpg Repeat 002. image0 Random 003. image1 004. image2 005. image3 001. 001 002. 002 003.
DPS-6.7_En.book Page 34 Monday, July 31, 2006 3:12 PM Advanced Playback 2 Remote controller Search Number buttons Use the number buttons to specify a title, chapter, or track number. To enter, for example, “12,” press the [1] button followed by the [2] button.
DPS-6.7_En.book Page 35 Monday, July 31, 2006 3:12 PM Advanced Playback—Continued 3 Remote controller Press the Play [ ] or [Enter] button to start playback of the specified time. Search Number buttons or Play Enter Searching by Time DVD-V DVD-A SACD DVD-VR VCD CD Notes: • In some cases, playback may start from a slightly different point to the one that you specify. • Time search may not work with some discs.
DPS-6.7_En.book Page 36 Monday, July 31, 2006 3:12 PM Advanced Playback—Continued Notes: • Repeat playback may not work with some discs. • The Repeat function can be used in combination with the Random function (see page 37). • If the Memory function is on (see page 38), the selectable options are Memory Repeat, which plays the playlist repeatedly, and Repeat Off. Repeat A–B A-B Repeat Playback DVD-V Play SACD DVD-VR VCD CD MP3 DivX The North American model does not support DivX.
DPS-6.7_En.book Page 37 Monday, July 31, 2006 3:12 PM Advanced Playback—Continued 2 Remote controller Random Play 3 Remote controller Press the Play [ ] button to start random playback. If you set the Random function during playback, random playback begins after the current chapter or track has finished. Random playback stops automatically when all of the items have been played once. If the Repeat function is on (see page 36), random playback starts all over again when all items have been played.
DPS-6.7_En.book Page 38 Monday, July 31, 2006 3:12 PM Advanced Playback—Continued 3 Repeat step 2 to add more items to the memory list. You can add up to 32 items to the memory list. 4 To play the memory list, press the Play [ ] button. The Memory Play Setup window must be open when you press the Play [ ] button.
DPS-6.7_En.book Page 39 Monday, July 31, 2006 3:12 PM Advanced Playback—Continued Deleting Items from the List Remote controller Use the Up/Down [ ]/[ ] buttons to select it, and then press the [CLR] button. The item is deleted and subsequent items move up the list. Editing Steps 1 Remote controller Last Memory DVD-V With the Last Memory function you can resume playback from where you left off even if the disc has been removed and the DVD player has been set to Standby.
DPS-6.7_En.book Page 40 Monday, July 31, 2006 3:12 PM Advanced Playback—Continued Selecting Camera Angles DVD-V Some DVDs feature multiple camera angles that allow you to view scenes from different angles. When a DVD features multiple camera angles, the camera indicator appears on the display. Such discs usually have the camera angle logo ( ) printed on the sleeve. Angle Play Stop / / / Zoom Zooming DVD-V DVD-VR VCD JPEG With the Zoom function you can enlarge any part of the picture.
DPS-6.7_En.book Page 41 Monday, July 31, 2006 3:12 PM Advanced Playback—Continued Selecting Subtitles DVD-V DivX The North American model does not support DivX. Some DVD-Video discs feature subtitles in several languages. See the disc’s sleeve notes for details. Audio Subtitle Selecting Soundtracks DVD-V DVD-A VCD SACD Some DVD-Video discs feature soundtracks in several languages or audio formats (e.g., Dolby Digital or DTS).
DPS-6.7_En.book Page 42 Monday, July 31, 2006 3:12 PM Advanced Playback—Continued Displaying Information You can display various information about the current disc, title, chapter, or track as follows. 1 Remote controller During playback, press the [Display] button repeatedly to cycle though the information. Various information appears onscreen. The operating status (e.g., Stop, Play, Resume) and disc type information is displayed along the top of the screen.
DPS-6.7_En.book Page 43 Monday, July 31, 2006 3:12 PM HDMI and Progressive Settings Resolution HDMI Resolution Setting the HDMI This section explains how to turn on the HDMI OUT and change the video resolution when your TV or projector is connected to the HDMI OUT. 1 Press the DVD player’s [HDMI] button to turn on HDMI. 2 Remote controller Press the [Resolution] button repeatedly to change the HDMI resolution. The first button press displays the current resolution onscreen.
DPS-6.7_En.book Page 44 Monday, July 31, 2006 3:12 PM Configuring the DVD player This chapter explains the various functions and settings of the onscreen setup menus. Functions and settings are arranged into six menus: Picture, Audio, Language, Display, Operation Setting, and Initial. The following table lists all the functions and settings, with a brief description and page number where you can find full details. Menu Picture Setting Description TV Shape Select the aspect ratio that matches your TV.
DPS-6.7_En.book Page 45 Monday, July 31, 2006 3:12 PM Configuring the DVD player—Continued Menu Operation Setting Initial Setup Setting Description Parental Lock Set the Parental Lock function. 53 Security Code Change the security code for use with parental lock. 53 DVD Priority Contents Determines what's played on DVD-Audio discs with DVD-Video contents. 54 SACD Priority Contents Determines how the SACD multichannel and 2-channel area and the CD area are played.
DPS-6.7_En.book Page 46 Monday, July 31, 2006 3:12 PM Configuring the DVD player—Continued Picture Menu TV Shape With this setting you can select a picture format to match the aspect ratio of your TV. 4:3 Letter box (default): Choose this option if you have a standard TV (4:3 aspect ratio). When you watch widescreen DVD-Video movies, the entire picture will be visible and there will be black bars at the top and bottom of the screen, as shown.
DPS-6.7_En.book Page 47 Monday, July 31, 2006 3:12 PM Configuring the DVD player—Continued HD Resolution Brightness With this setting you can set the video resolution for the HDMI OUT. See page 43 for more information. With this setting you can adjust the picture brightness. Auto: The resolution is automatically set to the native resolution of the TV connected to the HDMI OUT. Level 1-7: 1 is the darkest. 7 is the brightest. The default brightness is 4 (standard).
DPS-6.7_En.book Page 48 Monday, July 31, 2006 3:12 PM Configuring the DVD player—Continued Audio Menu ■ Subwoofer On (default): Select if a subwoofer is connected. Digital/HDMI Audio Out With this setting you can configure the optical, coaxial, and HDMI digital outputs. All (default): Dolby Digital and DTS signals are output as they are. PCM: Dolby Digital and DTS signals are down mixed to 2 channels and output as PCM. Off: No digital signals are output.
DPS-6.7_En.book Page 49 Monday, July 31, 2006 3:12 PM Configuring the DVD player—Continued Center Delay and Surr. Delay With these settings, you can adjust the multichannel output signals relative to the listening position. For 5.1-channel surround playback, ideally your speakers should all be the same distance away from the listening position, but this isn’t always practical.
DPS-6.7_En.book Page 50 Monday, July 31, 2006 3:12 PM Configuring the DVD player—Continued Downmix Setting Audio With this setting you can configure the FRONT/D.MIX AUDIO OUT jacks and AV CONNECTOR for use with a 2-channel stereo amp or an amp with a built-in Dolby Pro Logic decoder. It determines how multichannel audio sources are down mixed. In the Speaker Configuration, set the Subwoofer, Center Speaker, and Surround Speaker settings to Off.
DPS-6.7_En.book Page 51 Monday, July 31, 2006 3:12 PM Configuring the DVD player—Continued ■ Selecting Other Languages This section explains how to select other languages for disc menus, audio, and subtitles. 1 Remote controller 2 Remote controller 3 Remote controller Select “Others” from the Disc Menu Language, Audio Language, or Subtitle menu, and then press [Enter]. Use the remote controller’s Left/ Right [ ]/[ ] buttons to select the code.
DPS-6.7_En.book Page 52 Monday, July 31, 2006 3:12 PM Configuring the DVD player—Continued DivX Subtitle (Not North American model) Some DivX video discs include subtitles in one or more languages. The disc packaging will usually inform you about which subtitle languages are available. With this setting you can select your preferred language for DivX subtitles. When you play a DivX disc with multiple language subtitles, your preferred language will be selected automatically.
DPS-6.7_En.book Page 53 Monday, July 31, 2006 3:12 PM Configuring the DVD player—Continued Operation Setting Menu Setting the Parental Lock With the Parental Lock function you can block access to certain scenes that the authors have flagged as being unsuitable for children. 1 Select “Operation Setting” menu in the setup. 2 Use the Up/Down [ ]/[ ] buttons to select “Parental Lock,” and then press the [Enter] button. The security code input screen appears.
DPS-6.7_En.book Page 54 Monday, July 31, 2006 3:12 PM Configuring the DVD player—Continued DVD Priority Contents DVD-A This setting determines what is played when a DVD-Audio disc also contains DVD-Video material. DVD-AUDIO (default): The DVD-Audio material is played. DVD-VIDEO: The DVD-Video material is played. SACD Priority Contents SACD SACDs have two separate areas for storing audio tracks—one for multichannel audio, the other for 2channel stereo audio.
DPS-6.7_En.book Page 55 Monday, July 31, 2006 3:12 PM Additional information Resetting the player Disc Content Organization Use this procedure to reset all the player’s settings to the factory default. 1 Turn on the DVD player. Wait until “INTEGRA” has disappeared from the display. 2 Using the front panel buttons, hold down the Stop [ ] button and press [Standby/On] button. “INITIALIZE” appears on the display.
DPS-6.7_En.book Page 56 Monday, July 31, 2006 3:12 PM Additional information—Continued ■ Audio CD Format Audio CDs contain tracks. Track 1 Track 2 Track 3 Track 4 Track 5 ■ MP3, WMA & JPEG Files MP3, WMA, and JPEG files are typically organized into folders. The DVD player handles MP3, WMA, and JPEG files as tracks. Folder 1 Track 1 Audio CD Track 2 Folder 2 Track 3 Track 1 Track 2 MP3/WMA/JPEG (CD-R/CD-RW) Glossary Analog audio DRM An electrical signal that directly represents sound.
DPS-6.7_En.book Page 57 Monday, July 31, 2006 3:12 PM Glossary—Continued HDMI*1 Regions (DVD-Video only) HDMI (High-Definition Multimedia Interface) is a highspeed digital interface which has the capability to support standard, enhanced, or high-definition video plus standard to multichannel surround-sound audio on a single digital connection. HDMI features include uncompressed digital video, a bandwidth of up to 5 gigabytes per second and communication between the AV source and AV devices such as DTVs.
DPS-6.7_En.book Page 58 Monday, July 31, 2006 3:12 PM Troubleshooting Symptom Can’t turn on the DVD player? The DVD player turns itself off when it’s not being used? Possible cause Remedy The power cord is not connected. Connect the power cord to a suitable wall outlet (page 26). External interference is affecting the DVD player’s digital circuitry. Turn off the DVD player, wait five seconds, then try turning it on again.
DPS-6.7_En.book Page 59 Monday, July 31, 2006 3:12 PM Troubleshooting—Continued Symptom Possible cause Remedy No Sound from the HDMI OUT? The Digital/HDMI Audio Out setting is set to Off. Change the Digital/HDMI Audio Out setting to either All or PCM (page 48). The DVD player is connected to the DVI jack on your TV or AV receiver. You won’t hear any sound from the HDMI OUT if your TV or AV receiver only supports DVI. The HDMI setting on your TV or AV receiver is set to DVI.
DPS-6.7_En.book Page 60 Monday, July 31, 2006 3:12 PM Troubleshooting—Continued Symptom Can’t select MP3 files? Can’t play WMA files? Can’t view JPEG files? Buttons on the DVD player and remote controller don’t work? Buttons on the DVD player work OK but those on the remote controller don’t? Possible cause Remedy MP3 files without a “.mp3” or “.MP3” filename extension are not recognized. Use the correct filename extension (page 10). The MP3 disc is a multisession disc.
DPS-6.7_En.book Page 61 Monday, July 31, 2006 3:12 PM Troubleshooting—Continued ■ HDMI Status Mode If you’re using an HDMI connection and there’s no picture or sound, you can check the status of the HDMI connection by pressing and holding down the DVD player’s [Display] button for 10 seconds until a message ID appears on the display. Look up the message ID in the following tables and check the HDMI connections and settings on both the DVD player and the connected component.
DPS-6.7_En.book Page 62 Monday, July 31, 2006 3:12 PM Specifications Signal System North American model: NTSC Other model: PAL/NTSC Composite Video Output/Impedance 1.0 V (p-p)/75Ω negative sync, RCA S-Video Output/Impedance Y: 1.0 V (p-p)/75Ω negative sync, 4-pin mini DIN C: 0.286 V (p-p)/75Ω Component Video Output/Impedance Y: 1.0 V (p-p)/75Ω PB/PR: 0.
DPS-6.7_En.
DPS-6.7_En.book Page 64 Monday, July 31, 2006 3:12 PM Integra Division of ONKYO U.S.A. CORPORATION 18 park Way, Upper Saddle River, N.J. 07458, U.S.A. Tel: 201-785-2600 Fax: 201-785-2650 http://www.integrahometheater.com Integra Division of ONKYO CORPORATION Sales & Product Planning Div.: 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN Tel: 072-831-8023 Fax: 072-831-8124 En I0608-1 SN 29344215 (C) Copyright 2006 ONKYO CORPORATION Japan. All rights reserved.
