Specification Update

Identification Information
Specification Update 29
Identification Information
The Celeron M processor can be identified by the following values:
NOTES:
1. The Family corresponds to bits [11:8] of the EDX register after Reset, bits [11:8] of the
EAX register after the CPUID instruction is executed with a 1 in the EAX register.
2. The Model corresponds to bits [7:4] of the EDX register after Reset, bits [7:4] of the
EAX register after the CPUID instruction is executed with a 1 in the EAX register.
3. The Brand ID corresponds to bits [7:0] of the EBX register after the CPUID instruction
is executed with a 1 in the EAX register.
Table 1. Intel Celeron M Processor Identification
S-Spec
Processor
number
Product
Stepping
L2 Cache
Size
(bytes)
CPU
Signature
Core
Frequency
Bus
Frequency
Voltage
Package Micro-
FCBGA-Pb= Micro-
FCBGA Lead Free
SL9WN 520 A-1 1 M 10011b 1.60 533 MHz 1.30 V-0.95 V Micro-FCPGA
SL9VA 530 B-2 1 M 06F6h 1.73 533 MHz 1.30 V- 0.95 V Micro-FCPGA
SL9WT 520 B-2 1 M 06F6h 1.60 533 MHz 1.30 V-0.95 V Micro-FCPGA
SL9KX 450 D-0 1 M 06ECh 2.00 533 MHz 1.30 V-1.00 V Micro-FCPGA
SL9KW 440 D-0 1 M 06ECh 1.86 533 MHz 1.30 V-1.00 V Micro-FCPGA
SL8W2 410 C-0 1 M 06E8h 1.46 533 MHz 1.30-1.00 V Micro-FCPGA
SL92F 430 C-0 1 M 06E8h 1.73 533 MHz 1.30-1.00 V Micro-FCPGA
SL8VZ 420 C-0 1 M 06E8h 1.60 533 MHz 1.30-1.00 V Micro-FCPGA
SL9KV 430 D-0 1 M 06ECh 1.73 533 MHz 1.30-1.00 V Micro-FCPGA
SL8XW 423 C-0 1 M 06E8h 1.06 533 MHz 1.10-0.85 V Micro-FCBGA
SL8MH 390 C-0 1 M 06D8h 1.7 GHz 400 MHz 1.004 V – 1.292 V
1
Micro-FCBGA
SL8MP 390 C-0 1 M 06D8h 1.7 GHz 400 MHz 1.004 V – 1.292 V
1
Micro-FCBGA
SL8MV 390 C-0 1 M 06D8h 1.7 GHz 400 MHz 1.004 V – 1.292 V
1
Micro-FCBGA-Pb
SL8LP 383 C-0 1 M 06D8h 1.00 GHz 400 MHz 0.876 V – 0.956 V
1
Micro-FCBGA
SL8LV 383 C-0 1 M 06D8h 1.00 GHz 400 MHz 0.876 V – 0.956 V
1
Micro-FCBGA-Pb
SL8BP 383 C-0 1 M 06D8h 1.00 GHz 400 MHz 0.940 V Micro-FCBGA
SL8BN 383 C-0 1 M 06D8h 1.00 GHz 400 MHz 0.940 V Micro-FCBGA-Pb
SL8LQ 373 C-0 512 K 06D8h 1.00 GHz 400 MHz 0.876 V – 0.956 V
1
Micro-FCBGA
Family
1
Model
2
Model
2
(Celeron® M on 90-nm process)
Brand ID
3
0110 1001 1101 00010010
