Specification Update

Identification Information
Specification Update 31
S-Spec
Processor
number
Product
Stepping
L2 Cache
Size
(bytes)
CPU
Signature
Core
Frequency
Bus
Frequency
Voltage
Package Micro-
FCBGA-Pb= Micro-
FCBGA Lead Free
SL7DB n/a B-1 512 K 0695h 800 MHz 400 MHz 1.004 V Micro-FCBGA
SL7DH n/a B-1 512 K 0695h 900 MHz 400 MHz 1.004 V Micro-FCBGA
SL7F7 353 B-1 512 K 06D6h 900 MHz 400 MHz 0.940 V Micro-FCBGA
SL7QX 353 B-1 512 K 06D6h 900 MHz 400 MHz 0.940 V Micro-FCBGA-Pb
NOTES:
1. These are optimized Voltage ID (VID) values. Individual processor VID values may be
calibrated during manufacturing such that two devices at the same speed may have
different VID settings.
Component Marking Information
Figure 1. Intel Celeron M Processor (Micro-FCPGA/FCBGA) S-Spec Markings
