Land Listing and Signal Descriptions
Datasheet 49
VCC W23 Power/Other —
VCC W24 Power/Other —
VCC W25 Power/Other —
VCC W26 Power/Other —
VCC W27 Power/Other —
VCC W28 Power/Other —
VCC W29 Power/Other —
VCC W30 Power/Other —
VCC W8 Power/Other —
VCC Y23 Power/Other —
VCC Y24 Power/Other —
VCC Y25 Power/Other —
VCC Y26 Power/Other —
VCC Y27 Power/Other —
VCC Y28 Power/Other —
VCC Y29 Power/Other —
VCC Y30 Power/Other —
VCC Y8 Power/Other —
VCC_MB_
REGULATION
AN5 Power/Other Output
VCCA A23 Power/Other —
VCCIOPLL C23 Power/Other —
VCC_SENSE AN3 Power/Other Output
VID_SELECT AN7 Power/Other Output
VID0 AM2 Power/Other Output
VID1 AL5 Power/Other Output
VID2 AM3 Power/Other Output
VID3 AL6 Power/Other Output
VID4 AK4 Power/Other Output
VID5 AL4 Power/Other Output
VID6 AM5 Power/Other Output
VID7 AM7 Power/Other Output
VSS A12 Power/Other —
VSS A15 Power/Other —
VSS A18 Power/Other —
VSS A2 Power/Other —
VSS A21 Power/Other —
VSS A24 Power/Other —
VSS A6 Power/Other —
VSS A9 Power/Other —
VSS AA23 Power/Other —
VSS AA24 Power/Other —
VSS AA25 Power/Other —
VSS AA26 Power/Other —
Table 4-1. Alphabetical Land
Assignments
Land Name
Land
#
Signal Buffer
Type
Direction
VSS AA27 Power/Other —
VSS AA28 Power/Other —
VSS AA29 Power/Other —
VSS AA3 Power/Other —
VSS AA30 Power/Other —
VSS AA6 Power/Other —
VSS AA7 Power/Other —
VSS AB1 Power/Other —
VSS AB23 Power/Other —
VSS AB24 Power/Other —
VSS AB25 Power/Other —
VSS AB26 Power/Other —
VSS AB27 Power/Other —
VSS AB28 Power/Other —
VSS AB29 Power/Other —
VSS AB30 Power/Other —
VSS AB7 Power/Other —
VSS AC3 Power/Other —
VSS AC6 Power/Other —
VSS AC7 Power/Other —
VSS AD4 Power/Other —
VSS AD7 Power/Other —
VSS AE10 Power/Other —
VSS AE13 Power/Other —
VSS AE16 Power/Other —
VSS AE17 Power/Other —
VSS AE2 Power/Other —
VSS AE20 Power/Other —
VSS AE24 Power/Other —
VSS AE25 Power/Other —
VSS AE26 Power/Other —
VSS AE27 Power/Other —
VSS AE28 Power/Other —
VSS AE29 Power/Other —
VSS AE30 Power/Other —
VSS AE5 Power/Other —
VSS AE7 Power/Other —
VSS AF10 Power/Other —
VSS AF13 Power/Other —
VSS AF16 Power/Other —
VSS AF17 Power/Other —
VSS AF20 Power/Other —
VSS AF23 Power/Other —
VSS AF24 Power/Other —
Table 4-1. Alphabetical Land
Assignments
Land Name
Land
#
Signal Buffer
Type
Direction
