Land Listing and Signal Descriptions
56 Datasheet
J30 VCC Power/Other —
K1 LINT0 Asynch GTL+ Input
K2 VSS Power/Other —
K3 A20M# Asynch GTL+ Input
K4 REQ0# Source Synch Input/Output
K5 VSS Power/Other —
K6 REQ3# Source Synch Input/Output
K7 VSS Power/Other —
K8 VCC Power/Other —
K23 VCC Power/Other —
K24 VCC Power/Other —
K25 VCC Power/Other —
K26 VCC Power/Other —
K27 VCC Power/Other —
K28 VCC Power/Other —
K29 VCC Power/Other —
K30 VCC Power/Other —
L1 LINT1 Asynch GTL+ Input
L2 TESTHI13 Power/Other Input
L3 VSS Power/Other —
L4 A6# Source Synch Input/Output
L5 A3# Source Synch Input/Output
L6 VSS Power/Other —
L7 VSS Power/Other —
L8 VCC Power/Other —
L23 VSS Power/Other —
L24 VSS Power/Other —
L25 VSS Power/Other —
L26 VSS Power/Other —
L27 VSS Power/Other —
L28 VSS Power/Other —
L29 VSS Power/Other —
L30 VSS Power/Other —
M1 VSS Power/Other —
M2 THERMTRIP# Asynch GTL+ Output
M3 STPCLK# Asynch GTL+ Input
M4 A7# Source Synch Input/Output
M5 A5# Source Synch Input/Output
M6 REQ2# Source Synch Input/Output
M7 VSS Power/Other —
M8 VCC Power/Other —
M23 VCC Power/Other —
M24 VCC Power/Other —
M25 VCC Power/Other —
Table 4-2. Numerical Land Assignments
Land
#
Land Name
Signal Buffer
Type
Direction
M26 VCC Power/Other —
M27 VCC Power/Other —
M28 VCC Power/Other —
M29 VCC Power/Other —
M30 VCC Power/Other —
N1 PWRGOOD Power/Other Input
N2 IGNNE# Asynch GTL+ Input
N3 VSS Power/Other —
N4 RESERVED — —
N5 RESERVED — —
N6 VSS Power/Other —
N7 VSS Power/Other —
N8 VCC Power/Other —
N23 VCC Power/Other —
N24 VCC Power/Other —
N25 VCC Power/Other —
N26 VCC Power/Other —
N27 VCC Power/Other —
N28 VCC Power/Other —
N29 VCC Power/Other —
N30 VCC Power/Other —
P1 TESTHI11 Power/Other Input
P2 SMI# Asynch GTL+ Input
P3 INIT# Asynch GTL+ Input
P4 VSS Power/Other —
P5 RESERVED — —
P6 A4# Source Synch Input/Output
P7 VSS Power/Other —
P8 VCC Power/Other —
P23 VSS Power/Other —
P24 VSS Power/Other —
P25 VSS Power/Other —
P26 VSS Power/Other —
P27 VSS Power/Other —
P28 VSS Power/Other —
P29 VSS Power/Other —
P30 VSS Power/Other —
R1 COMP3 Power/Other Input
R2 VSS Power/Other —
R3 FERR#/PBE# Asynch GTL+ Output
R4 A8# Source Synch Input/Output
R5 VSS Power/Other —
R6 ADSTB0# Source Synch Input/Output
R7 VSS Power/Other —
Table 4-2. Numerical Land Assignments
Land
#
Land Name
Signal Buffer
Type
Direction
