Land Listing and Signal Descriptions
60 Datasheet
AH22 VCC Power/Other —
AH23 VSS Power/Other —
AH24 VSS Power/Other —
AH25 VCC Power/Other —
AH26 VCC Power/Other —
AH27 VCC Power/Other —
AH28 VCC Power/Other —
AH29 VCC Power/Other —
AH30 VCC Power/Other —
AJ1 BPM1# Common Clock Input/Output
AJ2 BPM0# Common Clock Input/Output
AJ3 ITP_CLK1 TAP Input
AJ4 VSS Power/Other —
AJ5 A34# Source Synch Input/Output
AJ6 A35# Source Synch Input/Output
AJ7 VSS Power/Other —
AJ8 VCC Power/Other —
AJ9 VCC Power/Other —
AJ10 VSS Power/Other —
AJ11 VCC Power/Other —
AJ12 VCC Power/Other —
AJ13 VSS Power/Other —
AJ14 VCC Power/Other —
AJ15 VCC Power/Other —
AJ16 VSS Power/Other —
AJ17 VSS Power/Other —
AJ18 VCC Power/Other —
AJ19 VCC Power/Other —
AJ20 VSS Power/Other —
AJ21 VCC Power/Other —
AJ22 VCC Power/Other —
AJ23 VSS Power/Other —
AJ24 VSS Power/Other —
AJ25 VCC Power/Other —
AJ26 VCC Power/Other —
AJ27 VSS Power/Other —
AJ28 VSS Power/Other —
AJ29 VSS Power/Other —
AJ30 VSS Power/Other —
AK1 THERMDC Power/Other —
AK2 VSS Power/Other —
AK3 ITP_CLK0 TAP Input
AK4 VID4 Power/Other Output
AK5 VSS Power/Other —
Table 4-2. Numerical Land Assignments
Land
#
Land Name
Signal Buffer
Type
Direction
AK6 RESERVED — —
AK7 VSS Power/Other —
AK8 VCC Power/Other —
AK9 VCC Power/Other —
AK10 VSS Power/Other —
AK11 VCC Power/Other —
AK12 VCC Power/Other —
AK13 VSS Power/Other —
AK14 VCC Power/Other —
AK15 VCC Power/Other —
AK16 VSS Power/Other —
AK17 VSS Power/Other —
AK18 VCC Power/Other —
AK19 VCC Power/Other —
AK20 VSS Power/Other —
AK21 VCC Power/Other —
AK22 VCC Power/Other —
AK23 VSS Power/Other —
AK24 VSS Power/Other —
AK25 VCC Power/Other —
AK26 VCC Power/Other —
AK27 VSS Power/Other —
AK28 VSS Power/Other —
AK29 VSS Power/Other —
AK30 VSS Power/Other —
AL1 THERMDA Power/Other —
AL2 PROCHOT# Asynch GTL+ Input/Output
AL3 VSS Power/Other —
AL4 VID5 Power/Other Output
AL5 VID1 Power/Other Output
AL6 VID3 Power/Other Output
AL7 VSS Power/Other —
AL8 VCC Power/Other —
AL9 VCC Power/Other —
AL10 VSS Power/Other —
AL11 VCC Power/Other —
AL12 VCC Power/Other —
AL13 VSS Power/Other —
AL14 VCC Power/Other —
AL15 VCC Power/Other —
AL16 VSS Power/Other —
AL17 VSS Power/Other —
AL18 VCC Power/Other —
AL19 VCC Power/Other —
Table 4-2. Numerical Land Assignments
Land
#
Land Name
Signal Buffer
Type
Direction
