Datasheet 85
Boxed Processor Specifications
NOTES:
1. Diagram does not show the attached hardware for the clip design and is provided only as a mechanical
representation.
Figure 7-3. Space Requirements for the Boxed Processor (Top View)
BdP TVi
95.0
[3.74]
95.0
[3.74]
Figure 7-4. Space Requirements for the Boxed Processor (Overall View)
