Intel® Server Board S1200BT family

Intel® Server System R1304BT family

Intel® Server System P4304BT family

Intel® Server Chassis P4304 family

Product Brief

An entry-level family of general-purpose server products designed for small to medium-

sized business applications, including 1U rack systems supporting advanced management

features and rich I/O.

Key Features

l

Supports Intel® Xeon® processor E3 1200 product family

(including lower power processors)

l

Highly-scalable DDR3 memory (up to 4 DIMMs)

l

Up to 5 slots high-speed PCI Express* 2.0 I/O

(optional I/O module for 6 total I/O slots)

l

Highly-flexible network and storage



configurations

l

Upgradable Intel® Remote Management Module

supporting remote KVM, and dedicated NIC module

Target Applications: Small and medium-sized business applications including web

servers, file and print servers, e-mail servers, storage servers and vertical-specific

business applications. Also suitable for High Performance Computing (HPC) and

embedded applications.

Summary of content (8 pages)

PAGE 1
Product Brief Intel® Server Board S1200BT family Intel® Server System R1304BT family Intel® Server System P4304BT family Intel® Server Chassis P4304 family An entry-level family of general-purpose server products designed for small to mediumsized business applications, including 1U rack systems supporting advanced management features and rich I/O.
PAGE 2
Features and Benefits • Supports Intel® Xeon® processor E3 1200 product family Delivers increased, intelligent and energy-efficient performance on demand • Fast, scalable and energy-efficient DDR3 memory Up to 4 DIMMs unbuffered DDR3 ensure ample capability and energyefficient performance for any application For S1200BTL models • Expandable I/O architecture Up to 5 I/O slots, including up to four high-speed PCI Express* 2.
PAGE 3
Intel® Server Board S1200BT Technical Specifications Order Code S1200BTL S1200BTS Form Factor ATX (12” x 9.6”) uATX (9.6” x 9.
PAGE 4
Value priced 1U system with features previously found only on higher end servers • BMC fully supporting IPMI 2.0 with Remote Management option • Upgrades for SAS and Intel® TPM modules available • Supports up to 4 Hot Swap HDDs R1304BTLSHBN Intel® Server System R1304BTLSHBN Technical Specifications Order Code R1304BTLSHBN R1304BTLSHBNNA Form Factor 1U Rack Server Board S1200BTL Drive Bays Four hot-swap 2.5” or 3.
PAGE 5
1U servers that are the lowest priced rack systems ever offered by Intel • Optional SAS or Remote Management module for R1304BTL model only • Supports up to 4 fixed HDDs R1304BTLSFAN R1304BTSSFAN Intel® Server System R1304BTLSFAN/ R1304BTSSFAN Technical Specifications Order Code R1304BTLSFAN R1304BTLSFANNA R1304BTSSFAN R1304BTSSFANNA Form Factor 1U Rack 1U Rack Server Board S1200BTL S1200BTS Drive Bays Four fixed 2.5” or 3.5’’ SATA HDDs Optional slim-line optical drive Four fixed 2.5” or 3.
PAGE 6
Entry pedestal servers designed for small businesses • Preconfigured options save time and money • Server efficiency and reliability improve performance over desktop platforms Intel® Server System P4304BT Technical Specifications Order Code P4304BTLSFCN P4304BTLSHCN P4304BTSSFCN Form Factor 4U Pedestal 4U Pedestal 4U Pedestal Server Board S1200BTL S1200BTL S1200BTS Drive Bays Up to four 2.5” or 3.5’’ fixed SATA HDDs Up to four 2.5” or 3.
PAGE 7
Designed for office environments • Variable fan speed control enables ultra quiet system • Flexible and expandable chassis options Intel® Server Chassis P4304 Technical Specifications Order Code P4304XXSFCN Form Factor 4U Pedestal Drive Bays Up to four 3.5’’ fixed SAS/SATA HDDs Peripheral Bay(s) Media Bays (3 x 5.
PAGE 8
Safety and EMC Regulatory Compliance Regulatory compliance for an Intel host system is based on the use of an Intel server base board that was tested in the host chassis and found compliant. Intel server base boards and host chassis are tested to Class A EMC requirements. Intel server products comply with RoHS (Restriction of Hazardous Substances).
